DRAGON™ D131/M131
Reference Manual

Advertisement

Table of Contents
loading

Related Manuals for Datalogic DRAGON D131

Summary of Contents for Datalogic DRAGON D131

  • Page 1 DRAGON™ D131/M131 Reference Manual...
  • Page 3 Dragon™ D131/M131 REFERENCE MANUAL...
  • Page 4 ALL RIGHTS RESERVED Datalogic reserves the right to make modifications and improvements without prior notification. Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the use of this material.

  • Page 5: Table Of Contents

    Master OM-3000 Network Troubleshooting ..........15 CONFIGURATION..................16 Configuration Methods ................16 4.1.1 Reading Configuration Barcodes ..............16 4.1.2 Using Datalogic Aladdin™ ................16 4.1.3 Copy Command ..................16 4.1.4 Sending Configuration Strings from Host............ 17 Setup Procedures ..................17 Dragon™...
  • Page 6 OM-3000 STAR-System™ Network Setup ..........25 Interface Selection ..................27 USB Reader Configuration................31 4.10 Changing Default Settings ................33 RS232 PARAMETERS ................34 Baud Rate ....................35 Parity......................35 Data Bits ..................... 36 Stop Bits...................... 36 Handshaking ....................36 Ack/Nack Protocol..................
  • Page 7 Output Level....................56 Idle Level..................... 56 Inter-Block Delay..................56 NETWORK PARAMETERS ............... 57 RS485 Network................... 58 Network Baud Rate..................58 Slave Address Range ................. 59 Network Warning Message ................. 59 Reception Warning Message ..............59 Master Cradle Header................. 60 Master Cradle Terminator ................61 DATA FORMAT..................
  • Page 8 Cradle Beeper Intensity ................81 DECODING PARAMETERS............... 82 Ink Spread....................83 Overflow Control ..................83 Interdigit Control..................83 Decoding Safety..................84 Puzzle Solver™ ..................84 CODE SELECTION ..................85 Auto-configuration..................86 EAN/UPC Family ..................88 2/5 Family ....................94 Code 39 Family................... 95 Code 128 Family..................
  • Page 9 5.1.1 Handshaking ..................... 131 5.1.2 ACK/NACK Protocol ................. 132 5.1.3 FIFO......................133 5.1.4 RX Timeout ....................134 Pen Parameters ..................134 5.2.1 Minimum Output Pulse................134 5.2.2 Conversion to Code 39 and Code 128............134 5.2.3 Overflow....................135 5.2.4 Output and Idle Levels ................135 5.2.5 Inter-Block Delay..................
  • Page 10 5.11 Custom Default Configuration ..............155 5.12 Code Type Recognition ................155 5.13 Configuration Copying Commands ............156 5.13.1 Copy Dragon™ D131 Series ..............156 5.13.2 Copy Dragon™ M131 Series ..............157 5.13.3 Copy OM-30X0 ..................158 5.14 Default Parameters for POS Terminals............. 159 5.15 Firmware Upgrade ..................

  • Page 11: General View

    GENERAL VIEW DRAGON™ D131/M131 READERS LEDs DRAGON™ D131 Cable Connector DRAGON™ M131 Battery Cover Laser Output Trigger Window Figure A – DRAGON™ D131 and M131 Series Readers LEDs Keypad Display Laser Output Window Figure B – DRAGON™ M131 Series Readers with Display...
  • Page 12 OM-30X0 / C-3000 CRADLES LEDs Figure C – OM-3000 LEDs Figure D – C-3000...

  • Page 13: Introduction

    INTRODUCTION INTRODUCTION Datalogic renews its range of industrial laser scanners introducing the Dragon™ family: Dragon™ Desk and Dragon™ Mobile. Robustness and ergonomics remain unsurpassed: clearly audible beeper and bright "good read" LEDs for areas where noise levels are normally high; the aim mode, which helps point to the right code, has now been extended to the whole Dragon™...

  • Page 14: Installation

    DRAGON™ D131/M131 INSTALLATION Connections should always be made with power OFF! CAUTION DRAGON™ D131 INTERFACE CABLE CONNECTIONS The Dragon™ D131 reader incorporates a multi-standard interface which can be onnected to a Host by plugging the correct interface cable into the connector and osing the cable cover.
  • Page 15 INSTALLATION Follow the given procedure for correct cable insertion: Align Align Slip the cover over the cable. Push the rubber boot completely over the connector. Take care that the rubber boot ma rk is aligned to the connector clip. Pull the rubber boot towards the connector until it covers and is flush with the connector moulding.

  • Page 16: Om-30X0 Interface Cable Connections

    DRAGON™ D131/M131 OM-30X0 INTERFACE CABLE CONNECTIONS Interface Cable OM-30X0 Connectors The OM-30X0 incorporates a mu lti-standard interface which can be connected to a ost by simply pluggin g the correct interface cable into the Host connector, placed on e base of the cradle. In addition the cradle must be connected to an external power supp To disconnect the cable, insert a paper clip or other similar...

  • Page 17: Rs232 Connection

    INSTALLATION RS232 CONNECTION (if required) IBM USB POS (if required) WEDGE CONNECTION (if required) PEN EMULATION CONNECTION (if required)

  • Page 18: Network Connections

    DRAGON™ D131/M131 NETWORK CONNECTIONS The OM-3000 provides an RS485 multidrop connection to link up to 16 base stations together in a network layout. .8.1 Network Cabling The RJ45 connector on the re ar panel of the OM-3000 cradle allows propagating the S485 multidrop network from one cradle to another.
  • Page 19 INSTALLATION The custom cables have the following specifications: • twisted pair AWG 24 wires • 120 Ω impedance • maximum network cable length 1200 meters Function Multidrop Cables RS485 + Pin 1 Data RS485 - N.C. Power Supply VDC – VDC –...

  • Page 20: Network Termination

    DRAGON™ D131/M131 2.8.2 Network Termination The first and last cradles of the chain (the two ends of the bus) must be properly terminated. The cradle has an internal terminator that can be selected via jumper. For this selection you must open the device. No Termination Static Dynamic...

  • Page 21: Dragon™ M131 Battery Maintenance

    INSTALLATION DRAGON™ M131 BATTERY MAINTENANCE 2.9.1 Battery Charging Once the system is connected and powered, you can place the Dragon™ M131 into the cradle to charge the battery. When the reader is correctly inserted in the cradle, the "Reader" red LED on the cradle goes on to indicate that the battery is charging.

  • Page 22: Dragon™ M131 System And Network Layouts

    DRAGON™ D131/M131 DRAGON™ M131 SYSTEM NETWORK LAYOUTS There are two basic system layouts that can be employed: Stand Alone systems (including Point-to-Point layouts) and Multidrop STAR-System™ Networks. STAND ALONE LAYOUTS 3.1.1 Point-to-Point Reader Layout Dragon™ M BIND Host OM-30X0 3.1.2 Stand Alone Layout with Multiple Readers Dragon™...

  • Page 23: Multiple Stand Alone Layouts

    DRAGON™ M131 SYSTEM AND NETWORK LAYOUTS 3.1.3 Multiple Stand Alone Layouts Many stand alone connections can operate in the same physical area without interference, provided all readers and cradles in the system have different addresses. Dragon™ M JOIN gon™ M JOIN Host Host...

  • Page 24: C-Box Layout

    DRAGON™ D131/M131 3.1.4 C-BOX Layout Dragon™ M JOIN Scanner BIND C-Box OM-30X0 System cables to Host In this layout the OM-30X0 cradle is connected by a dedicated cable using the RS232 interface to a C-BOX connection box as part of a fixed scanner network. This allows the flexibility of a hand-held reading station integrated into a variety of fixed scanning applications so that all readers (both fixed and hand-held), in the system provide communications to the Host.

  • Page 25: Multidrop Star-System™ Network Layouts

    The Slaves at the ends of the network must be terminated (see the STARGATE™ and STAR-Box™ Installation Manuals and par. 2.8.2). See par. 4.6 and 4.7 or the Datalogic Aladdin™ Help On-Line for system configuration specifications.

  • Page 26: Om-3000 Master Layout

    STARGATE™ base stations can also be used as slaves in this network. The devices at the ends of the network must be terminated (see par. 2.8.2). See pars. 4.6 and 4.7 or the Datalogic Aladdin™ Help On-Line for system configuration specifications.

  • Page 27: Master Om-3000 Network Troubleshooting

    DRAGON™ M131 SYSTEM AND NETWORK LAYOUTS 3.2.3 Master OM-3000 Network Troubleshooting Two diagnostic strings can be sent via RS232 from the Host to the Master cradle in order to have feedback about the network itself. #+LSlave Returns a list of all the Slaves recognized at boot up. Example: In a network where the Master cradle has address 0188 and one Slave cradle with address 0001, the response is:...

  • Page 28: Configuration

    Using Datalogic Aladdin™ Datalogic Aladdin™ is a multi-platform utility program providing a quick and user- friendly configuration method via the RS232/USB-COM interface. It also allows upgrading the software of the connected device (see the Datalogic Aladdin™ Help On-Line for more details). 4.1.3...

  • Page 29: Sending Configuration Strings From Host

    CONFIGURATION 4.1.4 Sending Configuration Strings from Host An alternative configuration method is provided in Appendix A using the RS232 interface. This method is particularly useful when many devices need to be configured with the same settings. Batch files containing the desired parameter settings can be prepared to configure devices quickly and easily.

  • Page 30: Dragon™ D131 Setup

    DRAGON™ D131/M131 DRAGON™ D131 SETUP Read the restore default parameters code below. Restore Dragon™ D131 Default Ì$+$*oÎ After reading the above code, go to par. 4.8 Interface Selection. DRAGON™ M131/OM-30X0 POINT-TO-POINT SETUP A rapid configuration procedure has been devised for point-to-point applications where a single reader is associated exclusively with its own OM-30x0 base station and where it is not necessary to set the Date and Time parameters.

  • Page 31: Dragon™ M131/Om-30X0 Stand Alone Setup

    CONFIGURATION DRAGON™ M131/OM-30X0 STAND ALONE SETUP Read the restore default parameters code below. Restore Dragon™M131 Default Ì$+$*oÎ Follow the procedure below to set the radio address and bind Dragon™ M131 to the OM-30X0 cradle. Enter Configuration Ì$+;Î Set Date ÌIA%Î six digits for Day, Month and Year (DDMMYY) Set Time ÌIB'Î...
  • Page 32 DRAGON™ D131/M131 Set Radio Address ÌRA0RFHÎ four digits for the Dragon™ M131 Address (from 0000 to 1999). All readers used in the same area must have different addresses. Exit and Save Configuration Ì$-?Î Read the Bind code to pair the Dragon™ M131 to the OM-30X0 cradle. The reader is dedicated to the cradle.

  • Page 33: Using Multiple M-Series Readers With Same Cradle

    CONFIGURATION Read the OM-30X0 restore default code: Restore OM-30X0 Default Ì$+RX0$-qÎ Go to par. 4.8 Interface Selection. 4.5.1 Using Multiple M-Series Readers With Same Cradle If you want to use several M-Series readers with the same OM-30X0 cradle, you must first Bind the cradle with one of the readers (see previously described configuration procedure).

  • Page 34: Dragon™ M131/Star-Modem™ In Stand Alone Mode

    DRAGON™ D131/M131 4.5.2 Dragon™ M131/STAR-Modem™ in Stand Alone Mode To configure a Dragon™ M131 reader to communicate with STAR-Modem™ in Stand Alone Mode, follow the procedure in par. 4.5 substituting steps 6 and 7 with those below: STAR-Modem™ Address ÌRSRÎ Read the code above and the four-digit address of the STAR-Modem™.

  • Page 35: Dragon™ M/Star-System™ Setup

    CONFIGURATION DRAGON™ M/STAR-SYSTEM™ SETUP The following procedure allows configuring a Dragon™ M131 reader to communicate with various STAR-System™ devices such as STARGATE™ RF base stations. Restore DRAGON™ M131 Default Ì$+$*oÎ Enter Configuration Ì$+;Î Set Date ÌIA%Î six digits for Day, Month and Year (DDMMYY) Set Time ÌIB'Î...
  • Page 36 DRAGON™ D131/M131 Set Radio Address ÌRA0RFHÎ four digits from the Numeric Table in the range 0000-1999. All readers must have different addresses. First STAR-System™ Address ÌRSRÎ Read the code above and the four-digit address of the First STAR-System™ device in the system. Set Last STAR-System™...

  • Page 37: Om-3000 Star-System™ Network Setup

    CONFIGURATION OM-3000 STAR-SYSTEM™ NETWORK SETUP When the OM-3000 cradle model is used in an RS485 network, it must be initially configured. To do this using configuration barcodes, follow the procedure below using any Dragon™ M131 reader. Set OM-3000 Address Ì$+RF4Î four digits for the OM-3000 Address (from 0000 to 1999).
  • Page 38 For OM-3000 Master Network Layouts (see par. 3.2), The network configuration parameters can be changed either through the Datalogic Aladdin™ configuration software running on the PC or by reading the barcode selections in the Network section of this manual starting on page 57. If using configuration barcodes, it is advised to completely configure the cradles before reconfiguring the Dragon™...

  • Page 39: Interface Selection

    CONFIGURATION INTERFACE SELECTION Read the interface selection code for your application. RS232 Standard Ì$+CP0$-$Î POS TERMINALS Nixdorf Mode A Ì$+CM2EC0$->Î Fujitsu Ì$+CM1$-ÈÎ ICL Mode Ì$+CM0$-ÃÎ For POS terminal default settings refer to par. 5.14. Ì$+CP6$-BÎ...
  • Page 40 DRAGON™ D131/M131 WEDGE IBM AT or PS/2 PCs Ì$+CP500$-aÎ IBM XT Ì$+CP503$-vÎ PC Notebook Ì$+CP505$-ÈÎ IBM SURE1 Ì$+CP506$-$Î IBM Terminal 3153 Ì$+CP504$-}Î IBM Terminals 31xx, 32xx, 34xx, 37xx: To select the interface for these IBM Terminals, read the correct KEY TRANSMISSION code. Select the KEYBOARD TYPE if necessary (default = advanced keyboard).
  • Page 41 CONFIGURATION WEDGE (CONTINUED) ALT MODE The ALT-mode selection allows barcodes sent to the PC to be interpreted correctly independently from the Keyboard Nationality used. You do not need to make a Keyboard Nationality selection. (default = Num Lock Unchanged). Make sure the Num Lock key on your keyboard is ON.
  • Page 42 DRAGON™ D131/M131 WEDGE (CONTINUED) DIGITAL TERMINALS VT2xx/VT3xx/VT4xx Ì$+CP512$-uÎ APPLE APPLE ADB Bus Ì$+CP513$-|Î...

  • Page 43: Usb Reader Configuration

    CONFIGURATION USB READER CONFIGURATION The USB interface is available for Dragon D131, OM-30x0 and C-3000 devices and is compatible with the following Operating Systems: Windows 98 (and later) IBM POS for Windows Mac OS 8.0 (and later) 4690 Operating System...
  • Page 44 USB-KBD Ì$+UA03$-:Î USB-KBD-ALT-MODE Ì$+UA04$-@Î USB-KBD-APPLE Ì$+UA05$-FÎ USB-COM* Ì$+UA02$-4Î USB-IBM-Table Top Ì$+UA00$-(Î USB-IBM-Hand Held Ì$+UA01$-.Î When configuring USB-COM, the relevant files and drivers must be installed from the USB Device Installation software which can be downloaded from the web site http://www.datalogic.com.

  • Page 45: 4.10 Changing Default Settings

    CONFIGURATION 4.10 CHANGING DEFAULT SETTINGS Once your reader is setup, you can change the default parameters to meet your application needs. Refer to the preceding paragraphs for initial configuration in order to set the default values and select the interface for your application. In this manual, the configuration parameters are divided into logical groups making it easy to find the desired function based on its reference group.

  • Page 46: Rs232 Parameters

    RS232 PARAMETERS All Dragon™ D131 Series readers Dragon™ M131/OM-30X0 configurations only ARITY ANDSHAKING ROTOCOL NTER CHARACTER ELAY IMEOUT ERIAL RIGGER Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of...

  • Page 47: Baud Rate

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS232 300 baud ÌCD1XÎ 600 baud ÌCD2[Î 1200 baud ÌCD3^Î 2400 baud ÌCD4aÎ 4800 baud ÌCD5dÎ 9600 baud ÌCD6gÎ 19200 baud ÌCD7jÎ 38400 baud ÌCD8mÎ ARITY none ÌCC0SÎ even parity ÌCC1VÎ odd parity ÌCC2YÎ...

  • Page 48: Data Bits

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS232 7 bits ÌCA0OÎ 8 bits ÌCA1RÎ 9 bits ÌCA2UÎ 1 stop bit ÌCB0QÎ 2 stop bits ÌCB1TÎ ANDSHAKING disable ÌCE0WÎ hardware (RTS/CTS) ÌCE1ZÎ software (XON/XOFF) ÌCE2]Î RTS always ON ÌCE3`Î See par. 5.1.1 for details.

  • Page 49: Ack/Nack Protocol

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS232 ROTOCOL disable ÌER0sÎ enable ÌER1vÎ See par. 5.1.2 for details, particularly on implementing this parameter with Dragon™ M131. FIFO disable ÌEC0UÎ enable ÌEC1XÎ See par. 5.1.3 for details. NTER CHARACTER ELAY delay between characters transmitted to Host ÌCK3Î...

  • Page 50: Rx Timeout

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RS232 IMEOUT timeout control in reception from Host ÌCL5Î Read 2 numbers from the table where: 00 = TIMEOUT disabled 01-99 = TIMEOUT from .1 to 9.9 seconds rx timeout 5 seconds See par.

  • Page 51: Usb Parameters

    USB PARAMETERS USB-COM Handshaking, Ack/Nack protocol, FIFO, Inter-character delay, Rx timeout, Serial trigger lock USB-KBD Keyboard nationality, FIFO, Inter-character delay, Inter-code delay, USB keyboard speed USB-IBM No parameter selection required. Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups.

  • Page 52: Handshaking

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-COM ANDSHAKING disable ÌCE0WÎ hardware (RTS/CTS) ÌCE1ZÎ software (XON/XOFF) ÌCE2]Î RTS always ON ÌCE3`Î See par. 5.1.1 for details. ROTOCOL disable ÌER0sÎ enable ÌER1vÎ See par. 5.1.2 for details, particularly on implementing this parameter with Dragon™ M131. FIFO disable ÌEC0UÎ...

  • Page 53: Inter-Character Delay

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-COM NTER CHARACTER ELAY delay between characters transmitted to Host ÌCK3Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from 1 to 99 milliseconds delay disabled IMEOUT timeout control in reception from Host ÌCL5Î...

  • Page 54: Keyboard Nationality

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-KBD EYBOARD ATIONALITY Not Available for USB-KBD-ALT-MODE Interface This parameter default value is restored through the Interface Selection code and not Restore Default. Belgian ÌFJ7yÎ English ÌFJ4pÎ French ÌFJ2jÎ German ÌFJ3mÎ Italian ÌFJ1gÎ...

  • Page 55: Fifo

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-KBD The Japanese and Eastern Block Keyboard Nationality selections are valid only for IBM AT compatible PCs. Japanese ÌFJ8|Î Russian (Latin) ÌFJ9ÃÎ Russian (Cyrillic) ÌFJA0Î Hungarian ÌFJB3Î Slovenian, Croatian, Serbian (Latin) ÌFJC6Î Romanian ÌFJD9Î...

  • Page 56: Inter-Character Delay

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î USB-KBD NTER CHARACTER ELAY delay between characters transmitted to Host ÌCK3Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from 1 to 99 milliseconds delay disabled NTER CODE ELAY...

  • Page 57: Wedge Parameters

    WEDGE PARAMETERS All Dragon™ D131 Series readers Dragon™ M131/OM-30X0 configurations only EYBOARD ATIONALITY RECOGNITION NTER CHARACTER ELAY NTER CODE ELAY EYBOARD ETTING EDGE ONTROL HARACTER MULATION Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of...

  • Page 58: Keyboard Nationality

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE EYBOARD ATIONALITY Belgian ÌFJ7yÎ English ÌFJ4pÎ French ÌFJ2jÎ German ÌFJ3mÎ Italian ÌFJ1gÎ Spanish ÌFJ6vÎ Swedish ÌFJ5sÎ ÌFJ0dÎ...

  • Page 59: Caps Lock

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE The Japanese and Eastern Block Keyboard Nationality selections are valid only for IBM AT compatible PCs. Japanese ÌFJ8|Î Russian (Latin) ÌFJ9ÃÎ Russian (Cyrillic) ÌFJA0Î Hungarian ÌFJB3Î Slovenian, Croatian, Serbian (Latin) ÌFJC6Î Romanian ÌFJD9Î...

  • Page 60: Caps Lock Auto-Recognition (Ibm At Compatible Only)

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE (IBM AT ECOGNITION COMPATIBLE ONLY disable ÌFP0pÎ enable ÌFP1sÎ toggle num lock ÌFL1kÎ num lock unchanged ÌFL0hÎ This selection is used together with the Alt Mode interface selection for AT or Notebook PCs. It changes the way the Alt Mode procedure is executed, therefore it should be set as follows: •...

  • Page 61: Inter-Code Delay

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE NTER CODE ELAY delay between codes transmitted to Host ÌFG.Î Read 2 numbers from the table where: 00 = DELAY disabled 01-99 = DELAY from 1 to 99 seconds delay disabled EYBOARD ETTING ALPHANUMERIC KEYBOARD SETTING...
  • Page 62 WEDGE Some ASCII characters may be missing as this depends on the type of keyboard: these are generally particular characters relative to the various national symbologies. In this case: • The first 4 characters (Shift, Alt, Ctrl, and Backspace) can only be substituted with keys not used, or substituted with each other.

  • Page 63: Control Character Emulation

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î WEDGE ONTROL HARACTER MULATION Ctrl + Shift + Key ÌFO0nÎ Ctrl + Key ÌFO1qÎ...

  • Page 64: Pen Emulation

    PEN EMULATION All Dragon™ D131 Series readers Dragon™ M131/OM-30X0 configurations only PERATING INIMUM UTPUT ULSE ONVERSION TO VERFLOW UTPUT EVEL EVEL NTER LOCK ELAY Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 65: Operating Mode

    PEN EMULATION The operating mode parameters are complete commands and do not require reading the Enter and Exit configuration codes. PERATING interpret mode Ì$]8Î Interprets commands without sending them to the decoder. transparent mode Ì$[4Î Sends commands to the decoder without interpreting them.

  • Page 66: Minimum Output Pulse

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î PEN EMULATION INIMUM UTPUT ULSE high resolution code emulation 200 µs ÌDG0\Î 400 µs ÌDG1_Î 600 µs ÌDG2bÎ 800 µs ÌDG3eÎ 1 ms ÌDG4hÎ 1.2 ms ÌDG5kÎ low resolution code emulation See par. 5.2.1 for details.

  • Page 67: Conversion To Code 39 (D131 Series Only)

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î PEN EMULATION 39 (D131 S ONVERSION TO ERIES disable conversion to Code 39 ÌDA0PÎ Transmits codes in their original format. enable conversion to Code 39 ÌDA1SÎ Converts codes read into Code 39 format. See par.

  • Page 68: Output Level

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î PEN EMULATION UTPUT EVEL normal ÌDD0VÎ (white = logic level 0) inverted ÌDD1YÎ (white = logic level 1) See par. 5.2.4 for details. EVEL normal ÌDE0XÎ (black level) inverted ÌDE1[Î (white level) See par.

  • Page 69: Network Parameters

    NETWORK PARAMETERS OM-3000 model configurations only RS485 N ETWORK ETWORK LAVE DDRESS ANGE ETWORK ARNING ESSAGE ECEPTION ARNING ESSAGE ASTER RADLE EADER ASTER RADLE ERMINATOR Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 70: Network Parameters

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î NETWORK PARAMETERS RS485 N ETWORK disable RS485 network ÌRZ0)Î enable RS485 slave ÌRZ1,Î enable RS485 master ÌRZ2/Î See par. 3.2 for details. If an OM-3000 cradle is errantly configured as a Slave but not connected to a network, it may not be able to receive further commands from the gun.

  • Page 71: Slave Address Range

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î NETWORK PARAMETERS LAVE DDRESS ANGE First Address ÌJB(Î Read the code above and the four-digit address of the First Slave device in the system. Last Address ÌJC*Î system. Read the code above and the four-digit address of the Last Slave device in the See par.

  • Page 72: Master Cradle Header

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î NETWORK PARAMETERS ASTER RADLE EADER no header ÌJA00/Î one character header ÌJA013Î two character header ÌJA027Î three character header ÌJA03;Î four character header ÌJA04?Î five character header ÌJA05CÎ six character header ÌJA06GÎ seven character header ÌJA07KÎ...

  • Page 73: Master Cradle Terminator

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î NETWORK PARAMETERS ASTER RADLE ERMINATOR no terminator ÌJA102Î one character terminator ÌJA116Î two character terminator ÌJA12:Î three character terminator ÌJA13>Î four character terminator ÌJA14BÎ five character terminator ÌJA15FÎ six character terminator ÌJA16JÎ seven character terminator ÌJA17NÎ...

  • Page 74: Data Format

    DATA FORMAT NOT FOR PEN INTERFACES DENTIFIER USTOM DENTIFIER EADER ERMINATOR PECIAL IELD DJUSTMENT IELD HARACTER ENGTH HARACTER EPLACEMENT DDRESS TAMPING DDRESS ELIMITER TAMPING ELIMITER Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of...

  • Page 75: Data Format

    (check digit tested or not, check digit tx or not, etc.). • When customizing the Datalogic Standard code identifiers, 1 or 2 identifier characters can be defined for each code type. If only 1 identifier character is required, the second character must be selected as FF (disabled).

  • Page 76: Code Identifier

    DENTIFIER define custom code identifier(s) ÌEH/Î Read the above code. (Code Identifiers default to Datalogic standard, see table on previous page). Select the code type from the code table in Appendix for the identifier you want to change. You can define 1 or 2 identifier characters for each code type. If only 1 identifier character is required, the second character must be selected as FF (disabled).

  • Page 77: Header

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT EADER no header ÌEA00*Î one character header ÌEA01.Î two character header ÌEA022Î three character header ÌEA036Î four character header ÌEA04:Î five character header ÌEA05>Î six character header ÌEA06BÎ seven character header ÌEA07FÎ...

  • Page 78: Terminator

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT ERMINATOR no terminator ÌEA10-Î one character terminator ÌEA111Î two character terminator ÌEA125Î three character terminator ÌEA139Î four character terminator ÌEA14=Î five character terminator ÌEA15AÎ six character terminator ÌEA16EÎ seven character terminator ÌEA17IÎ...

  • Page 79: Special Keys

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT PECIAL Available only for Wedge IBM AT-PS/2 and USB-KBD Interfaces It is necess ary to define each Special Key by following the procedure given in par. 5.4.2. NOTE Select one or more of the follo g Special Keys according to yo r...

  • Page 80: Field Adjustment

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT IELD DJUSTMENT disable field adjustment ÌEF0[Î Field adjustment allows a number of characters n, to be added to or subtracted from the barcode read. The adjustment can be different for each enabled code type. To define the field adjustment: Read the enable field adjustment code: enable field adjustment...

  • Page 81: Field Adjustment Character

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT IELD DJUSTMENT HARACTER Read the field adjustment character code: field adjustment character ÌEG-Î Read the hexadecimal value corresponding to the character you want to use for field adjustment. Valid characters are in the range 00-FE. For Wedge and USB-KBD interfaces, it is also possible to read the Special Key(s) on page 67.

  • Page 82: Character Replacement

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT HARACTER EPLACEMENT disable character replacement ÌEO0mÎ This parameter allows up to three characters to be replaced from the barcode read. These substitutions are stored in memory. To define each character replacement: Read one of the following character replacement codes: first character replacement ÌEO1pÎ...
  • Page 83 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT Example: The following strings define: First Character Replacement: substitution in Code 39 barcodes of all occurrences of the 0 character with the 1 character. Second Character Replacement: substitution in Code 39 barcodes of all occurrences of the A character with the B character.

  • Page 84: Address Stamping (M131 Series Only)

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT (M131 S DDRESS TAMPING ERIES disable reader address stamping ÌRU0ÊÎ disable cradle address stamping ÌRW0#Î enable reader address stamping ÌRU1"Î enable cradle address stamping ÌRW1&Î See par. 5.4.3 for details. (M131 S DDRESS ELIMITER...

  • Page 85: Time Stamping (M131 Series Only)

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DATA FORMAT (M131 S TAMPING ERIES disable ÌIL0kÎ hour/minutes/seconds month/day/year ÌIL1nÎ hour/minutes/seconds day/month/year ÌIL2qÎ hour/minutes/seconds ÌIL3tÎ month/day/year ÌIL4wÎ day/month/year ÌIL5zÎ See par. 5.4.5 for details. (M131 S TAMPING ELIMITER ERIES disable ÌIM0mÎ select delimiter ÌIM1pÎ...

  • Page 86: Power Save

    POWER SAVE LEEP TATE NTER LEEP IMEOUT Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 87: Power Save

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î POWER SAVE LEEP TATE disable ÌBQ0nÎ enable ÌBQ1qÎ See par. 5.5.1 for details. For M131 series readers, sleep state is entered immediately after reading a code and is not configurable. NTER LEEP IMEOUT enter sleep timeout ÌBR@Î...

  • Page 88: Reading Parameters

    READING PARAMETERS RIGGER RIGGER IGNAL RIGGER LICK RIGGER IMEOUT LASH EADS PER YCLE AFETY EEPER NTENSITY EEPER EEPER EEPER ENGTH URATION IMING YSTEM RADLE EEPER NTENSITY Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of...

  • Page 89: Trigger Type

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS RIGGER hardware trigger ÌBK1eÎ Restores TRIGGER MODE software trigger ÌBK0bÎ Enables FLASH MODE always on ÌBK3kÎ RIGGER IGNAL trigger active level ÌBA0NÎ trigger active pulse ÌBA1QÎ See par. 5.6.1 for details. RIGGER LICK disable...

  • Page 90: Trigger-Off Timeout

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS RIGGER IMEOUT trigger-off timeout ÌBD$Î Read 2 numbers in the range 00-99: 00 = disables the trigger-off timeout 01-99 = corresponds to a max. 99-sec. delay after the trigger press to allow the reader to turn off automatically. trigger-off timeout disabled See par.

  • Page 91: Safety Time

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS AFETY safety time ÌBE&Î Limits same code consecutive reading. Read 2 numbers in the range 00-99: 00 = no same code consecutive reading until reader is removed (no decoding) for at least 400 ms. 01-99 = timeout from .1 to 9.9 seconds before a consecutive read on same code.

  • Page 92: Beeper Tone

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS EEPER tone 1 ÌBH0\Î tone 2 ÌBH1_Î tone 3 ÌBH2bÎ tone 4 ÌBH3eÎ EEPER monotone ÌBJ0`Î bitonal ÌBJ1cÎ EEPER ENGTH long ÌBI0^Î short ÌBI1aÎ...

  • Page 93: Good Read Spot Duration

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î READING PARAMETERS URATION disable ÌBV0xÎ short ÌBV1{Î medium ÌBV2~Î long ÌBV3ÅÎ IMING YSTEM disabled ÌBj09Î enabled ÌBj1<Î RADLE EEPER NTENSITY disable ÌJI0fÎ low intensity ÌJI1iÎ medium intensity ÌJI2lÎ high intensity ÌJI3oÎ...

  • Page 94: Decoding Parameters

    DECODING PARAMETERS PREAD VERFLOW ONTROL NTERDIGIT ONTROL ECODING AFETY ™ UZZLE OLVER Before changing these parameter values read the descriptions in par. 5.7. CAUTION Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 95: Ink Spread

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DECODING PARAMETERS PREAD disable ÌAX0{Î enable ÌAX1~Î See par. 5.7.1 for details. VERFLOW ONTROL disable ÌAW1|Î enable ÌAW0yÎ See par. 5.7.2 for details. NTERDIGIT ONTROL disable ÌAV0wÎ enable ÌAV1zÎ See par. 5.7.3 for details.

  • Page 96: Decoding Safety

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DECODING PARAMETERS ECODING AFETY one read ÌED0WÎ (decoding safety disabled) two reads ÌED1ZÎ three reads ÌED2]Î four reads ÌED3`Î Required number of good reads before accepting code. ™ UZZLE OLVER disable ÌAU0uÎ enable ÌAU1xÎ...

  • Page 97: Code Selection

    CODE SELECTION CONFIGURATION EAN/UPC F AMILY 2/5 F AMILY 39 F AMILY 128 F AMILY ODABAR AMILY RSS C ODES Read the Enter Configuration code ONCE , available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE , available at the top of...

  • Page 98: Auto-Configuration

    Code selections may be performed according to two different procedures: Auto-configuration, allowing an automatic recognition and selection of the code families to be read; Manual configuration, requiring configuration and selection of each code family to be read. CONFIGURATION The following codes do not require reading the Enter and Exit configuration codes. In auto-configuration mode the reader enters a particular state, during which it reads, recognizes and saves all information received from the decoding of an existing code (with the exception of MSI, Code 49 and Code 16k code types).
  • Page 99 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION DISABLE ALL CODE FAMILIES ÌAZ0ÃÎ The reader allows up to 10 code selections. This does n ot limit the number of CODES enabled to 10, as it depends on the code family. NOTE SINGLE •...

  • Page 100: Ean/Upc Family

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION EAN/UPC F AMILY disable the family ÌAA0MÎ Read the desired family code Note: Since the EAN/UPC without ADD ON code selection is enabled by default, to correctly enable another selection, first disable the family. EAN 8/EAN 13/UPC A/UPC E with and without ADD ON ÌAA8eÎ...
  • Page 101 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION WITH ADD ON 2 ONLY EAN 8/EAN 13 ÌAAK7Î UPC A/UPC E ÌAAM=Î WITH ADD ON 5 ONLY EAN 8/EAN 13 ÌAAL:Î UPC A/UPC E ÌAAN@Î WITH AND WITHOUT ADD ON EAN/UPC with and without ADD ON no Autodiscrimination ÌAA8Ad03Î...
  • Page 102 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION SELECT EAN/UPC PREFIXES When scanning the following codes, barcodes starting with the selected prefixes will be read and transmitted only if the ADD ON is present. If no ADD ON is found, the barcode will not be read. Barcodes starting with different characters are read regardless of ADD ON presence and transmitted always NOTE without ADD ON.
  • Page 103 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION Example: The following string allows reading and transmitting with ADD ON all EAN/UPC starting with the 434/439, 977 and 978 prefixes: EAN/UPC Autodiscrimination ADD ON by Prefix. 434/439: enables reading and transmission with ADD ON of all EAN/UPC barcodes starting with 434/439 prefixes.
  • Page 104 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION EAN/UPC CHECK DIGIT TX SELECTIONS For each code type in this family you can choose to transmit the check digit or not CHECK DIGIT TRANSMISSION NO CHECK DIGIT TRANSMISSION EAN 8 ÌAAG1oÎ...
  • Page 105 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION CONVERSION OPTIONS UPC E to UPC A conversion ÌAAAÄÎ UPC E to EAN 13 conversion ÌAABÇÎ UPC A to EAN 13 conversion ÌAACÊÎ EAN 8 to EAN 13 conversion ÌAAD"Î Enable only ISBN conversion ÌAP1nÎ...

  • Page 106: 2/5 Family

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION 2/5 F AMILY disable the family ÌAC0QÎ Read the desired family code Read a check digit selection Interleaved 2/5 ÌAC1TÎ CHECK DIGIT TABLE no check digit control Ì12Î Normal 2/5 (5 Bars) ÌAC2WÎ...

  • Page 107: Code 39 Family

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION 39 F AMILY disables the family ÌAB0OÎ Read the desired family code Read a check digit selection CHECK DIGIT TABLE Standard Code 39 no check digit control ÌAB1RÎ Ì12Î check digit control Full ASCII Code 39 and transmission ÌAB2UÎ...

  • Page 108: Code 128 Family

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION 128 F AMILY disables the family ÌAI0]Î Read the desired family code Code 128 ÌAI11=Î control without transmission of check digit ISBT 128 ÌAI31CÎ Enabling ISBT 128 automatically disables EAN 128 Puzzle Solver™.

  • Page 109: Code 93

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION disables the code ÌAK0aÎ Code 93 ÌAK1dÎ control without transmission of check digit ODABAR AMILY disable the family ÌAD0SÎ Read the desired equality control code Read a start/stop transmission selection START/STOP CHARACTER TRANSMISSION Standard Codabar...
  • Page 110 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION Codabar ABC Forced Concatenation enable Codabar ABC with forced concatenation ÌAD2321Î non start/stop character equality control but transmission CODE LENGTH (optional) The code length selection is valid for the entire Codabar family set code length Read the code + 4 numbers for the code length where: ÌAD*AÎ...

  • Page 111: Msi

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION disable the family ÌAE0UÎ Enable the code by selecting one of the check digit selections. no check digit control ÌAE1XÎ MOD10 check digit control no check digit transmission ÌAE2[Î MOD10 check digit control check digit transmission ÌAE3^Î...

  • Page 112: Code 11

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION disable the family ÌAG0YÎ Enable the code by selecting one of the check digit selections. no check digit control ÌAG1\Î Type C check digit control check digit transmitted ÌAG21<Î Type C check digit control check digit not transmitted ÌAG22@Î...

  • Page 113: Code 16K

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION disable the code ÌAJ0_Î Code 16K ÌAJ1bÎ To read stacked codes, simply move the reader over the code so that each line of the code is scanned. During this process a series of brief “ticks” indicates that reading is proceeding correctly.

  • Page 114: Rss Codes

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î CODE SELECTION RSS C ODES disable the family ÌAQ0mÎ DISABLE CODE ENABLE CODE disable RSS Expanded Linear and Stacked ÌAQ10IÎ enable RSS Expanded Linear and Stacked ÌAQ11MÎ disable RSS Limited ÌAQ20LÎ enable RSS Limited ÌAQ21PÎ...

  • Page 115: Advanced Formatting

    ADVANCED FORMATTING NOT FOR PEN INTERFACES ONCATENATION DVANCED ORMATTING Please follow the setup procedure carefully for these parameters. NOTE The Advanced Formatting parameters may not be compatible with the IBM USB POS interface selection. NOTE Read the Enter Configuration code ONCE, available at the top of page . Read configuration codes precisely following the numbered procedure given.

  • Page 116: Concatenation

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î ADVANCED FORMATTING ONCATENATION disable ÌEI0aÎ enable ÌEI1dÎ Permits the concatenation of two codes defined by code type and length. It is possible to set a timeout for the second code reading and to define code transmission if the timeout expires. The order of transmission is CODE 1-CODE 2.
  • Page 117 Since you can concatenate codes from different families, you must select the Code ID character of the resulting code. The Code ID character will be sent in the output message only if it is enabled according to the Code Identifier selection (Datalogic, AIM, or Custom). Concatenation Timeout timeout ÌEJ3Î...
  • Page 118 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Transmission after Timeout no code transmitted after timeout ÌEM0iÎ only code 1 transmitted (if read) after timeout ÌEM1lÎ only code 2 transmitted (if read) after timeout ÌEM2oÎ either code 1 or code 2 transmitted after timeout ÌEM3rÎ...

  • Page 119: Advanced Formatting

    ADVANCED FORMATTING DVANCED ORMATTING Advanced formatting has been designed to offer you complete flexibility in changing the format of barcode data before transmitting it to the host system. This formatting will be performed when the barcode data meets certain criteria which you will define in the following procedure. Up to 4 advanced code management formats can be defined and saved in memory.
  • Page 120 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î ADVANCED FORMATTING Begin Format Definition begin Format 1 definition ÌHA0TÎ begin Format 2 definition ÌHA1WÎ begin Format 3 definition ÌHA2ZÎ begin Format 4 definition ÌHA3]Î Match Code Type match code type ÌHB&Î Read the above code + the code type to match from the Code Identifier Table in Appendix any code type ÌHB0VÎ...
  • Page 121 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Match with Predefined Characters no match ÌHD0HE00ÄÎ match with 1 character ÌHD1]Î match with a 2-character string ÌHD2`Î match with a 3-character string ÌHD3cÎ match with a 4-character string ÌHD4fÎ After selecting the predefined match code, read the character(s) from the HEX table. Range of characters = 00-FE.
  • Page 122 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Divide Code into Fields divide code into fields ÌHF.Î Read one number in the range 1 to 5 to divide the code into fields. Define Code Fields define code fields Each code field length can be set by either: a) defining a field separator character to be found in the code itself.
  • Page 123 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 1 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 00-FE. discard separator include separator Ì01Î Ì12Î match character ÌHG3iÎ Read the match character from the HEX table. Range of characters = 00-FE. field length ÌHG1cÎ...
  • Page 124 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 2 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 00-FE. discard separator include separator Ì01Î Ì12Î match character ÌHG3iÎ Read the match character from the HEX table. Range of characters = 00-FE. field length ÌHG1cÎ...
  • Page 125 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 3 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 00-FE. discard separator include separator Ì01Î Ì12Î match character ÌHG3iÎ Read the match character from the HEX table. Range of characters = 00-FE. field length ÌHG1cÎ...
  • Page 126 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 4 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 00-FE. discard separator include separator Ì01Î Ì12Î match character ÌHG3iÎ Read the match character from the HEX table. Range of characters = 00-FE. field length ÌHG1cÎ...
  • Page 127 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING DEFINE FIELD 5 BY: EITHER field separator ÌHG0`Î Read the field separator character from the HEX table. Range of characters = 00-FE. discard separator include separator Ì01Î Ì12Î match character ÌHG3iÎ Read the match character from the HEX table. Range of characters = 00-FE. field length ÌHG1cÎ...
  • Page 128 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING First Additional Fixed Field no fixed field ÌHI0dÎ 1 character fixed field ÌHI1gÎ 2 character fixed field ÌHI2jÎ 3 character fixed field ÌHI3mÎ 4 character fixed field ÌHI4pÎ 5 character fixed field ÌHI5sÎ 6 character fixed field ÌHI6vÎ...
  • Page 129 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Second Additional Fixed Field no fixed field ÌHJ0fÎ 1 character fixed field ÌHJ1iÎ 2 character fixed field ÌHJ2lÎ 3 character fixed field ÌHJ3oÎ 4 character fixed field ÌHJ4rÎ 5 character fixed field ÌHJ5uÎ 6 character fixed field ÌHJ6xÎ...
  • Page 130 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Field Transmission number of fields to transmit ÌHK8Î Read one number in the range 1 to 7 for the number of fields to transmit. Include only fields to be transmitted. Field Order Transmission Read the codes corresponding to the fields to transmit in the order in which they are to be transmitted.
  • Page 131 Exit and Save Configuration Ì$-?Î ADVANCED FORMATTING Standard Formatting do not apply standard formatting ÌHL0jÎ apply standard formatting ÌHL1mÎ After performing Advanced Formatting on the barcode read, Standard Formatting (Headers, Code Length, Code ID, Terminators) can be applied to the message to be transmitted. End Format Definition end Format 1 definition ÌHM0lÎ...
  • Page 132 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î ADVANCED FORMATTING Enable Advanced Format no Advanced Formats enabled ÌHN0nÎ Advanced Format 1 enable ÌHN11NÎ disable ÌHN10JÎ Advanced Format 2 enable ÌHN21QÎ disable ÌHN20MÎ Advanced Format 3 enable ÌHN31TÎ disable ÌHN30PÎ Advanced Format 4 enable ÌHN41WÎ...
  • Page 133 Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î ADVANCED FORMATTING No Match Result clear data - no transmission transmit data using standard ÌHO0pÎ format ÌHO1sÎ This selection determines the action to be taken when codes read do not conform to the advanced format requisites (no match).

  • Page 134: Radio Parameters

    RADIO PARAMETERS Dragon™ M131 Series readers only ADIO ROTOCOL IMEOUT OWER IMEOUT RANSMISSION EEPER ONTROL FOR ADIO ESPONSE INGLE TORE ATCH Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 135: Radio Protocol Timeout

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS ADIO ROTOCOL IMEOUT radio protocol timeout ÌRH<Î Read a number from the table where: 02-19 = timeout from 2 to 19 seconds 2 seconds See par. 5.8.1 for details. OWER IMEOUT power-off timeout ÌRPLÎ...

  • Page 136: Transmission Mode

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS RANSMISSION One Way ÌRI0nÎ Two-ways ÌRI1qÎ See par. 5.8.3 for details. EEPER ONTROL FOR ADIO ESPONSE normal ÌBF0XÎ only good decode ÌBF1[Î only good reception ÌBF2^Î ÌBF3aÎ See par. 5 .8.4 for details.

  • Page 137: Single Store

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS INGLE TORE disable ÌRO0zÎ one attempt ÌRO1}Î two attempts ÌRO2ÄÎ three attempts ÌRO3ÇÎ four attempts ÌRO4ÊÎ five attempts ÌRO5"Î six attempts ÌRO6%Î seven attempts ÌRO7(Î eight attempts ÌRO8+Î nine attempts ÌRO9.Î...

  • Page 138: Batch Mode

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î RADIO PARAMETERS ATCH disable batch ÌBZ0ÄÎ enable normal batch ÌBZ1ÇÎ enable automatic batch ÌBZ2ÊÎ See par. 5.8.6 for details. The following batch management parameters are complete commands and do not require reading the Enter and Exit configuration codes. start normal batch transmission Ì#+BFlush]Î...

  • Page 139: Display Parameters

    DISPLAY PARAMETERS Dragon™ M131 Series readers only ATE AND ONTRAST ACKLIGHT ISPLAY IMEOUT ISPLAY EYPAD Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 140: Date And Time

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DISPLAY PARAMETERS ATE AND set date ÌIA%Î set time ÌIB'Î Read 6 numbers for DDMMYY Read 4 numbers for HHMM ONTRAST lighter ÌIC0YÎ darker ÌIC1\Î Read the code until the desired contrast is reached. small ÌID0[Î...

  • Page 141: Display-Off Timeout

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DISPLAY PARAMETERS ISPLAY IMEOUT timeout ÌIF/Î Read 2 numbers in the range 00-99: 00 = disables display timeout (always on) 01 to 99 = timeout from 1 to 99 seconds. display-off after 8 seconds. delay disabled ISPLAY normal...

  • Page 142: Keypad

    Enter Configuration Exit and Save Configuration Ì$+;Î Ì$-?Î DISPLAY PARAMETERS EYPAD disable reader keypad ÌIK0iÎ enable reader keypad and select characters ÌIK1lÎ Read 3 HEX characters in the range 00-FE, corresponding to the left, center and right keys respectively. FF = KeyID disabled left = '<' center = '=' right = '>'...

  • Page 143: References

    REFERENCES REFERENCES RS232 PARAMETERS 5.1.1 Handshaking Hardware handshaking: (RTS/CTS) The RTS line is activated by the decoder before transmitting a character. Transmission is possible only if the CTS line (controlled by the Host) is active. Signals at EIA levels Transmitted data Transmitted data Host busy RTS/CTS handshaking...
  • Page 144 DRAGON™ D131/M131 5.1.2 ACK/NACK Protocol Dragon™ D131 Readers This parameter sets a transmission protocol in which the Host responds to the reader after every code transmitted. The Host sends an ACK character (06 HEX) in the case of good reception or the NACK character (15 HEX) requesting re-transmission, in the case of bad reception.
  • Page 145 REFERENCES Transmission Mode = Two-Ways data data cable NACK Host OM-30X0 DRAGON™ M good RX data beep ACK/NACK enabled When ACK/NACK is enabled (in Two-Way tx mode), the Host sends an ACK character (06 HEX) in the case of good reception or the NACK character (15 HEX) requesting re-transmission, in the case of bad reception.
  • Page 146 DRAGON™ D131/M131 5.1.4 RX Timeout When the RS232 interface is selected, the Host can be used to configure the device by sending it command strings (see Appendix A). This parameter can be used to automatically end data reception from the Host after the specified period of time.

  • Page 147: Overflow

    REFERENCES 5.2.3 Overflow This parameter generates a white space before the first bar and after the last bar of the code. The selections are as follows: narrow = space 10 times the minimum output pulse. medium = space 20 times the minimum output pulse. wide = space 30 times the minimum output pulse.
  • Page 148 DRAGON™ D131/M131 5.2.5 Inter-Block Delay For the PEN Emulation interface, data are sent to the Host in fixed size blocks of 20 characters each. The inter-block delay parameter allows setting a delay between each block sent to the Host. NETWORK PARAMETERS 5.3.1 Slave Address Range First/Last These parameters define the valid addresses for the Slave cradles on the network.
  • Page 149 REFERENCES The message is sent in the following format: "Message" CR LF 5.3.3 Reception Warning Message The Master cradle can transmit warning messages to the Host regarding wrong reception of data. Example: /*Two-Ways Out of Sequence!(..)*/ This message is transmitted to the Host by the Master cradle when the Master cradle receives a closing string from the Host for a Two-way tx communication, but this was either not open or already closed, therefore the data will be lost.
  • Page 150 DRAGON™ D131/M131 These default values are always restored through the reading of RS232 or WEDGE interface selection code, see chapter 2. For the WEDGE interface, the following extended keyboard values can also be configured: EXTENDED KEYBOARD TO HEX CONVERSION TABLE IBM AT IBM XT IBM 31xx, 32xx,...
  • Page 151 Enter Configuration Ì$+;Î 5.4.2 Define Special Key Sequence The Special Key(s) for Wedge IBM AT-PS/2 and USB-KBD interface users can be associated with a sequence of keyboard keys that otherwise could not be selected, i.e. ALT + F6, SHIFT + F1. These Special Keys can be used for: Headers/Terminators Character Replacement Field Adjustment...
  • Page 152 DRAGON™ D131/M131 Read only one code to be associated with the special key sequence: SHIFT Ì12Î CTRL Ì23Î Ì45Î CTRL + SHIFT Ì34Î ALT + SHIFT Ì56Î CTRL + ALT Ì67Î...
  • Page 153 Exit and Save Configuration Ì$-?Î Select the character to be associated with the Special Key sequence by reading the codes corresponding to the 3 character values from Appendix C. Then, read the Exit and Save Configuration code above to complete the Special Key sequence.
  • Page 154 DRAGON™ D131/M131 KEYB CHAR < > ’ (accent)
  • Page 155 REFERENCES KEYB CHAR To use upper case letters, it is necessary to read one of the SHIFT commands from step 2 before the value corresponding to the lower case letters. NOTE The following key values are common to all the keyboard nationalities. KEYB ENTER Home...
  • Page 156 DRAGON™ D131/M131 KEYB CHAR Up arrow 275 Down arrow Left arrow Right arrow Ctrl right € SPACE If Caps Lock Auto-Recognition is disabled, it is necessary to verify that the keyboard caps lock status matches the reader one. NOTE EXAMPLES - Defining Special Key Sequences - the following example allows defining Special Key 1 as SHIFT + F5: enter configuration...
  • Page 157 REFERENCES the following example allows defining Special Key 2 as CTRL + S (upper case): enter configuration define Special Key 2 CTRL + SHIFT Ì$+;Î ÌFQ9D2BÎ Ì34Î Read codes from Appendix C corresponding to exit & save configuration the character value for s (lower case) Ì$-?Î...
  • Page 158 DRAGON™ D131/M131 the following example allows setting Special Key 2 (defined in example 2 above) as header: enter configuration one character header special key 2 exit & save configuration Ì$+;Î ÌEA01.Î Ì9DÆÎ Ì$-?Î Read the following example allows setting Special Key 3 (defined in example 3 above) as header: enter configuration one character header...
  • Page 159 REFERENCES 5.4.5 Time Stamping Format The Time Stamping parameter sets the format for hour and date information. It consists of 1 or 2 groups of numbers, each one made up of 6 decimal digits. For example, setting the Hour/Minutes/Seconds/Month/Day/Year format, the information 17:03:16 on June 12, 2002 will be formatted as 170316061202.
  • Page 160 DRAGON™ D131/M131 5.5.2 Enter Sleep Timeout For readers that have the Sleep state enabled, this timeout determines when the reader will enter this state. READING PARAMETERS 5.6.1 Trigger Signal This mode determines how the reading phase is controlled when the hardware trigger operating mode is selected: •...

  • Page 161: Ink-Spread

    REFERENCES When one read per cycle is selected, the device decodes only one code during the ON period and immediately turns the reader OFF. It is only possible to read another code when the next ON time occurs. In multiple reads per cycle, the ON period is extended so that the device can continue decoding codes until an OFF event occurs.

  • Page 162: Interdigit Control

    DRAGON™ D131/M131 5.7.3 Interdigit Control The interdigit control parameter verifies the interdigit spacing for code families Code 39 and Codabar. RADIO PARAMETERS (M131 SERIES ONLY) 5.8.1 Radio Protocol Timeout This parameter sets the valid time to wait before transmission between the M131 series reader and OM-30X0 cradle is considered failed.

  • Page 163: Beeper Control For Radio Response

    REFERENCES With ACK/NACK disabled, the Host responds to the reader (through the cradle) with an answer message (message to reader display or command to reader), see par. and the following figure. Transmission Mode = Two-Ways data data cable Host OM-30X0 DRAGON™...

  • Page 164: Batch Mode

    DRAGON™ D131/M131 Conversely, if single store is disabled, and the user wants to retry transmission, the code must be read again, and therefore the attempt must be made from basically the same location. If the user gives up, he does not know if the transaction was successful.

  • Page 165: Find Me (Dragon M131 Only)

    REFERENCES In batch mode, the selected Transmission Mode determines the behavior of the gun at the time the list of codes is transmitted. If One-way mode is enabled, the codes are transmitted one after the other without interruption. In Two-way mode, after transmitting each code, the gun waits for the Host answer message to be shown on the display.

  • Page 166: 5.10 Configuration Editing Commands

    DRAGON™ D131/M131 5.10 CONFIGURATION EDITING COMMANDS The following commands carry out their specific function and then exit the configuration environment. Command Description Restore Dragon™ reader default configuration Ì$+$*oÎ (see the relative Quick Reference Manual for default settings) Ì$+$!KÎ Transmit Dragon™ D131 Dragon™...

  • Page 167: 5.11 Custom Default Configuration

    REFERENCES 5.11 CUSTOM DEFAULT CONFIGURATION Read the following code to set the reader user-defined configuration as custom default configuration: Save User-defined Configuration as Custom Default Ì$+$0ÂÎ Read the following code whenever you need to restore the custom default configuration: Restore Custom Default Configuration Ì$+$1$Î...

  • Page 168: 5.13 Configuration Copying Commands

    Connect the master (correctly configured reader) and the slave (reader to be configured) together through two RS232 serial interface cables and external power supply. Accessory cables and power supply are available from your Datalogic distributor to provide this connection. RS232 Cables: CAB363 & CAB364 or CAB320 & CAB328 Power Supply: PG5...

  • Page 169: Copy Dragon™ M131 Series

    REFERENCES 5.13.2 Copy Dragon™ M131 Series Procedure: Using the slave reader and its OM-30X0 cradle, follow the initialization procedure in chapter 4 of this manual or from the Quick Reference Manual. With the master Dragon™ M131 (correctly configured reader), read the Copy Configuration barcode below.

  • Page 170: Copy Om-30X0

    Connect the master OM-30X0 and the slave OM-30X0 (cradle to be configured) together through two RS232 serial interface cables and external power supply. Accessory cables and power supply are available from your Datalogic distributor to provide this connection. RS232 Cables: CAB363 & CAB364 or CAB320 & CAB328 Power Supply: PG12 Read the Configuration Copy barcode below with a reader.

  • Page 171: 5.14 Default Parameters For Pos Terminals

    REFERENCES 5.14 DEFAULT PARAMETERS FOR POS TERMINALS The default values of the RS232 and Data Format parameters for POS terminals are listed in the following table: NIXDORF Mode A FUJITSU ICL Mode RS232 Group Baud Rate 9600 9600 9600 Parity None Even Data Bits...

  • Page 172: 5.15 Firmware Upgrade

    DRAGON™ D131/M131 5.15 FIRMWARE UPGRADE Device firmware upgrades can be performed using the Downloader utility tool (downloadable from the web site: http://www.datalogic.com) from your PC through the USB communication. Procedure: Launch the Downloader tool on your PC. Connect the device to the PC via USB interface.

  • Page 173: Message Formatting

    MESSAGE FORMATTING MESSAGE FORMATTING The system always provides gun to host data communication using the following message formatting: Output Message from Dragon™ D131 or Dragon™ M131 Stand Alone Towards Host [Header] [Gun_Addr] [Gun_Addr_delimiter] ] [Cradle_Addr] [Cradle_Addr_delimiter] CODE [Time stamp] [Ts_delimiter] [Code ID] [Code Length] [Terminator] [Items in square brackets are optional.] Output Message from Dragon™...

  • Page 174: Cursor Control

    DRAGON™ D131/M131 • If you have not enabled the Gun Address Stamping or the Gun Address Delimiter, you must not specify them. In this case all messages will be implicitly addressed to the 'binded' gun of the cradle directly connected to the serial line. •...

  • Page 175: Font Selection

    MESSAGE FORMATTING • The cursor row position is not affected by the currently selected font. The display always has 4 rows, so when writing with the large font, actually two rows are written to: the current one and the one below it. You will need two ESC E commands to step from one row to the next when using the large font.

  • Page 176: Setting Rtc

    DRAGON™ D131/M131 The LED control escape sequences are intended to activate the LEDs for short periods of time and can be used in combination with the Beeper. The LED and Beeper will be controlled by the system after the entire command sequence is interpreted.
  • Page 177 MESSAGE FORMATTING The default characters associated with each key (KeyID) are shown in the following table: Default Key Identifiers KeyID ▲ (left) Key '<' ENTER (center) Key ▼ (right) Key '>'...

  • Page 178: Technical Features

    Power (max) in mW 0.9 mW 1.4 mW Scan Angle 42° 23° PCS minimum (Datalogic Test Chart) Resolution maximum 0.076 mm (3 mils) 0.25 mm (10 mils) Reading Field Width see reading diagrams (par. 7.6) Laser Safety Class EN 60825-1 / CDRH...

  • Page 179: Dragon™ M131

    Power (max) in mW 0.9 mW 1.4 mW Scan Angle 42° 23° PCS minimum (Datalogic Test Chart) Resolution maximum 0.076 mm (3 mils) 0.25 mm (10 mils) Reading Field Width see reading diagrams (par. 7.6) Laser Safety Class EN 60825-1 / CDRH...

  • Page 180: Om-30X0 / C-3000

    DRAGON™ D131/M131 OM-30X0 / C-3000 OM-30X0 C-3000 Electrical and General Features Supply Voltage External Power 10 to 30 Vdc Host Power 5 Vdc ±10% Power Consumption External Power max. 10 W (charging)* Host Power max. 500 mA (charging) Indicators Ext. Power /Data yellow LED Host Power/Data yellow LED Reader batt.

  • Page 181: System And Radio Features

    TECHNICAL FEATURES SYSTEM AND RADIO FEATURES European Models USA Models Radio Features Working Frequency 433.92 MHz 910 MHz Bit Rate 19200 36800 Range (in open air) 50 m 30 m System Configurations OM-3000 model only STARGATE™ Maximum number of devices per base station Maximum number of devices in the 2000...
  • Page 182 DRAGON™ D131/M131 Dragon™ D131/M131 READER DATA ENTRY ¹ Good Read Spot Meaning Beeper one beep² Correct read of a code in normal mode H L long TX buffer full (when FIFO is enabled) or TX error between Dragon™ M131 and OM-3000 H long Successful advanced format...
  • Page 183 TECHNICAL FEATURES OM-30X0/C-3000 POWER/COMMUNICATION Aux LED Host LED Meaning Yellow Yellow Device off Power applied through an external power supply Power applied through the Host Flashing Flashing Transmission over the Host port OM-30X0/C-3000 CHARGE STATUS Reader LED Meaning Green Beeper No reader battery inserted Reader battery in charge single beep...

  • Page 184: Reading Diagrams

    DRAGON™ D131/M131 READING DIAGRAMS DRAGON™ D/M131 108 cm 0.13 mm (5 mils) 0.19 mm (7.5 mils) 0.25 mm (10 mils) 0.33 mm (13 mils) 0.38 mm (15 mils) 0.50 mm (20 mils) 1.00 mm 1.38 mm (40 mils) (55 mils) DRAGON™...

  • Page 185: Ahost Configuration Strings

    HOST CONFIGURATION STRINGS A HOST CONFIGURATION STRINGS In this section we provide a description of how to modify the device configuration using serial strings sent from the Host. This method requires the RS232 interface. The device configuration can be changed by receiving commands from the Host through the serial interface.
  • Page 186 DRAGON™ D131/M131 SERIAL CONFIGURATION STRINGS SPECIAL CONFIGURATION COMMANDS DESCRIPTION STRING Enter Configuration Exit and Save Configuration Restore Default $+$* Transmit Software Release (not for PEN emulation) $+$! Transmit Device Configuration in ASCII (not for PEN emulation) $+$& Set Custom Default $+$0 Restore Custom Default $+$1...
  • Page 187 HOST CONFIGURATION STRINGS RS232 DESCRIPTION STRING Baud Rate 1200 2400 4800 9600 19200 38400 Parity none even Data Bits Stop Bits Handshaking disable RTS/CTS XON/XOFF RTS always On ACK/NACK Protocol disable enable FIFO disable enable Inter-character Delay (ms) CK00 - CK99 RX Timeout (100 ms) CL00 - CL99 Serial Trigger Lock...
  • Page 188 DRAGON™ D131/M131 DESCRIPTION STRING USB-COM Handshaking disable RTS/CTS XON/XOFF RTS always ON ACK/NACK Protocol disable enable FIFO disable enable Inter-character Delay (ms) CK00 - CK99 RX Timeout (100 ms) CL00 - CL99 Serial Trigger Lock disable enable CR1ab USB-KBD Keyboard Nationality Belgian (not for USB-KBD-ALT-MODE) English...
  • Page 189 HOST CONFIGURATION STRINGS WEDGE DESCRIPTION STRING Keyboard Nationality Belgian English French German Italian Spanish Swedish Keyboard Nationality Japanese (IBM AT compatible only) Russian (Latin) Russian (Cyrillic) Hungarian Slovenian, Croatian, Serbian (Latin) Romanian Czech Republic Caps Lock caps Lock ON caps Lock OFF Caps Lock Auto-Recognition disable (IBM AT compatible only)
  • Page 190 DRAGON™ D131/M131 PEN (continued) DESCRIPTION STRING Idle Level normal inverted Overflow narrow overflow medium overflow wide overflow Inter-block Delay (100 ms) CK00-CK99 NETWORK DESCRIPTION STRING RS485 Network Disable Network Enable RS485 Slave Enable RS485 Master Slave Address Range Minimum Address JB0000-1999 Maximum Address JC0000-1999...
  • Page 191 = HEX values representing an ASCII character. a = ASCII character of the DATALOGIC STANDARD Code Identifier from the table on page 63. b = Hex value of the first Custom Code Identifier character from 00 to FD;...
  • Page 192 = a number from the Hex/Numeric Table e, f, g, h = HEX values representing an ASCII character a = ASCII character of the DATALOGIC STANDARD Code Identifier from the table on page 63. d = a number in the range 01-32 from the Hex/Numeric Table...
  • Page 193 HOST CONFIGURATION STRINGS POWER SAVE DESCRIPTION STRING Sleep State disable (only for D131 series) enable Enter Sleep Timeout (100 ms) BR00-BR99 READING PARAMETERS DESCRIPTION STRING Trigger Type software trigger hardware trigger always on Trigger Signal trigger active level trigger active pulse Trigger Click disable enable...
  • Page 194 DRAGON™ D131/M131 DECODING PARAMETERS DESCRIPTION STRING Ink-spread disable enable Overflow Control disable enable Interdigit Control disable enable Puzzle Solver disable enable Decoding Safety one read two reads three reads four reads CODE SELECTION DESCRIPTION STRING DISABLE ALL FAMILY CODES EAN/UPC disable EAN/UPC family EAN 8/EAN 13/UPC A/UPC E without ADD ON...
  • Page 195 HOST CONFIGURATION STRINGS CODE SELECTION (continued) DESCRIPTION STRING UPC A check digit transmission disable AAI0 enable AAI1 UPC E check digit transmission disable AAJ0 enable AAJ1 conversions UPC E to UPC A UPC E to EAN 13 UPC A to EAN 13 EAN 8 to EAN 13 ISBN Conversion codes enable ISBN...
  • Page 196 DRAGON™ D131/M131 CODE SELECTION (continued) DESCRIPTION STRING Codabar disable Codabar family Standard no start/stop character equality control AD111 nor transmission no start/stop character equality control AD112 but transmission start/stop character equality control AD121 but no transmission start/stop character equality control AD122 and transmission ABC Codabar...
  • Page 197 HOST CONFIGURATION STRINGS CODE SELECTION (continued) DESCRIPTION STRING Code 11 disable the family no check Type C with tx AG21 Type C no tx AG22 Type K with tx AG31 Type K no tx AG32 Type C and K with tx AG41 Type C and K no tx AG42...
  • Page 198 DRAGON™ D131/M131 DISPLAY PARAMETERS DESCRIPTION STRING Date IAddmmyy Time IBhhmm Contrast lighter darker Font Size small medium large Backlight Display-Off Timeout Display Mode normal local echo clear display after decode Keypad disabled keys enable and select KeyID characters IK1bbb ddmmyy = numbers from the Hex/Numeric Table representing day, month, year hhmm = numbers from the Hex/Numeric Table representing hour, minutes...

  • Page 199: Bcode Identifier Table

    CODE IDENTIFIER TABLE B CODE IDENTIFIER TABLE 2/5 Interleaved ÌNOÎ 2/5 Industrial ÌPQÎ 2/5 normal 5 bars ÌOPÎ 2/5 matrix 3 bars ÌQRÎ EAN 8 ÌABÎ EAN 13 ÌBCÎ UPC A ÌCDÎ UPC E ÌDEÎ EAN 8 with 2 ADD ON ÌJKÎ...
  • Page 200 DRAGON™ D131/M131 UPC A with 5 ADD ON ÌGHÎ UPC E with 2 ADD ON ÌHIÎ UPC E with 5 ADD ON ÌIJÎ Code 39 ÌVWÎ Code 39 Full ASCII ÌWXÎ CODABAR ÌRSÎ ABC CODABAR ÌSTÎ Code 128 ÌTUÎ EAN 128 ÌklÎ...
  • Page 201 CODE IDENTIFIER TABLE ÌZ[Î Code 16K ÌpqÎ Code 11 ÌbcÎ Code 49 ÌqrÎ RSS Expanded Linear and Stacked ÌtuÎ RSS Limited ÌvwÎ RSS 14 Linear and Stacked ÌuvÎ...

  • Page 202: C Hex And Numeric Table

    DRAGON™ D131/M131 C HEX AND NUMERIC TABLE CHARACTER TO HEX CONVERSION TABLE char char char < > SPACE " &...

  • Page 203: Hex And Numeric Table

    HEX AND NUMERIC TABLE OPEN THIS PAGE TO READ THE DESIRED HEX AND NUMERIC SELECTIONS...
  • Page 204 HEX AND NUMERIC TABLE HEX / NUMERIC TABLE CHARACTER TO HEX CONVERSION TABLE Ì01Î char char char € ª Õ Ì12Î « Ö ‚ ¬ × ENTER Ø Ì23Î ® Ù ¯ Ú ° Û Ì34Î ± Ü ² Ý Ì45Î...
  • Page 205 90ACC1929...
