6.2 EMC and Environmental Type Tests
HV Impulse
Damped Os-
cillatory Mag-
netic Field

Environmental Type Tests

IEC 60068-2-1
IEC 60068-2-2
IEC 60068-2-30
IEC 60068-21-1
IEC 60068-21-2
44
Description
DC Power Ports
AC Power Ports
Signal Ports
DC Power Ports
AC Power Ports
Dielectric Signal Ports
Strength
DC Power Ports
AC Power Ports
Enclosure Ports
Test
Cold Temperature
Humidity (Damp Heat, Cyclic)
Description
Dry Heat
Vibration
Shock
Test Levels
2.5 kV Common
1 kV differential mode @ 1 MHz
2.5 kV Common
1 kV differential mode @ 1 MHz
5 kV (Fail-Safe Relay Output)
5 kV
5 kV
2 kV
2 kV
2 kV
100 A/m
Test Levels
Test Ad -40 °C (-40 °F), 16 Hours
Test Bd 85 °C (185 °F), 16 Hours
Test Db 95% (Non-Condensing),
55 °C (131 °F), 6 Cycles
2g @ 10-150 Hz
30 g @ 11 ms
