Sennheiser EK 300 IEM G3 Instruction Manual

Hide thumbs Also See for EK 300 IEM G3:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual, User Manual
Enlarged version
EK 300 IEM
Instruction manual
Contents
Important safety instructions .......................................................................... 2
The EK 300 IEM G3 diversity receiver .............................................................. 3
Areas of application ........................................................................................ 3
The frequency bank system .......................................................................... 3
Delivery includes .................................................................................................. 4
Product overview ................................................................................................. 5
Overview of the EK 300 IEM G3 diversity receiver .................................... 5
Overview of the displays ................................................................................ 6
Putting the diversity receiver into operation ............................................... 7
Inserting the batteries/accupack ................................................................. 7
Charging the accupack .................................................................................... 7
Connecting the earphones ............................................................................. 7
Attaching the diversity receiver to clothing .............................................. 8
Using the diversity receiver .............................................................................. 9
Deactivating the lock mode temporarily ................................................. 10
Selecting a standard display ...................................................................... 10
Using the operating menu ............................................................................. 11
The buttons .................................................................................................... 11
Overview of the operating menu ............................................................... 11
Working with the operating menu ........................................................... 12
Adjusting settings via the operating menu ................................................. 14
transmitter with the diversity receiver ........................................................ 21
channels (Easy Setup Sync) ........................................................................ 21
Using freely selectable receiving frequencies ......................................... 22
Cleaning the diversity receiver ...................................................................... 23
Recommendations and tips ........................................................................... 23
If a problem occurs ... ....................................................................................... 24
Specifications .................................................................................................... 25
Manufacturer Declarations ............................................................................. 26
For additional information, visit the EK 300 IEM G3 product
page on our website at www.sennheiser.com.
1

Advertisement

Table of Contents
loading

Related Manuals for Sennheiser EK 300 IEM G3

Summary of Contents for Sennheiser EK 300 IEM G3

  • Page 1: Table Of Contents

    The frequency bank system ................3 Delivery includes ....................4 Product overview ....................5 Overview of the EK 300 IEM G3 diversity receiver ........5 Overview of the displays ................6 Putting the diversity receiver into operation ..........7 Inserting the batteries/accupack ..............7 Charging the accupack ..................

  • Page 2: Important Safety Instructions

    AF II longer hear high notes. Intended use Intended use of the EK 300 IEM G3 diversity receiver includes: • having read these instructions especially the chapter “Important safety instructions”, • using the product within the operating conditions and limitations This transmitter is available in the same UHF frequency ranges and is described in this instruction manual.

  • Page 3: Delivery Includes

    ¹ ¶ frequency information sheet. Updated versions of the frequency informa- tion sheet can be downloaded from the EK 300 IEM G3 product page on our º website at www.sennheiser.com. The frequency banks “U1” to “U6” allow you to freely select and store ¸...

  • Page 4: Overview Of The Displays

    Inserting the batteries/accupack The display backlighting is automatically reduced after approx. 20 seconds. For powering the diversity receiver, you can either use two 1.5 V AA size batteries or the rechargeable Sennheiser BA 2015 accupack (optional 519.150 accessory). ew300 IEM ¸...

  • Page 5: Attaching The Diversity Receiver To Clothing

    Putting the diversity receiver into operation Using the diversity receiver Attaching the diversity receiver to clothing Using the diversity receiver You can use the belt clip to attach the diversity receiver to clothing To establish a transmission link, proceed as follows: (e.g.

  • Page 6: Deactivating The Lock Mode Temporarily

    You can activate or deactivate the automatic lock mode via the “Auto A special feature of the Sennheiser ew G3 series is the consistent, intuitive Lock” menu item (see page 16). If the lock mode is activated, you have to menu structure of transmitters and receivers.

  • Page 7: Working With The Operating Menu

    Using the operating menu Using the operating menu Changing and storing settings Display Function of the menu item Page “Easy Setup“ Frequency Preset Frequency Preset Menu Frequency Preset B.Ch: 1. 1 B.Ch: Reset List Releases all locked frequency presets B.Ch: 1. 1 863.100MHz 824.500MHz Current List...

  • Page 8: Adjusting Settings Via The Operating Menu

    Adjusting settings via the operating menu Adjusting settings via the operating menu Adjusting settings via the operating Setting the frequency bank and the channel – “Frequency Preset” menu Frequency Preset Frequency Preset Menu Frequency Preset B.Ch: 1. 1 B.Ch: B.Ch: 1. 1 863.100MHz 824.500MHz The main menu “Menu”...

  • Page 9: The Extended Menu "Advanced Menu

    Adjusting settings via the operating menu Adjusting settings via the operating menu Switching between “Stereo” and “Focus” mode – “Mode” The extended menu “Advanced Menu” To get into the extended menu “Advanced Menu”: Mode Mode Menu Mode Stereo Focus From the main menu, select “Advanced”. Stereo Call up “Mode”...
  • Page 10 Mode”, you can read out the settings of other EK receivers and The pilot tone evaluation is activated. The receiver does save these settings in profiles using your EK 300 IEM G3 receiver. not receive a pilot tone because the transmitter operates in mono mode.

  • Page 11: Synchronizing An Sr 300 Iem G3

    The settings of the receiver are assigned to the selected profile. enclosed frequency information sheet. You can also contact your Sennheiser partner who will be Repeat this procedure to create profiles of other EK receivers. pleased to calculate intermodulation-free frequencies for you.

  • Page 12: Synchronizing Transmitters With Diversity Receivers (Sync)

    If you are using frequencies from the frequency banks “U1” to “U6”, it might be that the receiving frequencies are not intermod- ulation-free. Contact your Sennheiser partner who will be pleased to calculate intermodulation-free frequencies for you (see www.sennheiser.com). Set each diversity receiver to the same frequency bank (“U1” to “U6”).

  • Page 13: If A Problem Occurs

    If a problem occurs that is not listed in the above table or if the problem cannot be solved with the proposed solutions, please contact your local Sennheiser partner for assistance. To find a Sennheiser partner in your country, search at www.sennheiser.com under “Service & Support”.

  • Page 14: Manufacturer Declarations

    Connector assignment 3.5 mm jack plug Manufacturer Declarations Warranty Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months on this product. For the current warranty conditions, please visit our web site at www.sennheiser.com or contact your Sennheiser partner.
