Summary of Contents for BT Diverse Solo
Page 1
Alternative arrangements should be made for access to emergency services. This product is intended for connection to analogue public switched telephone networks and private switchboards in the United Kingdom. Diverse Solo User Guide Digital Cordless Telephone...
All manuals and user guides at all-guides.com At a glance Handset display Displays the status of your handset. Redial Directory Press to redial one 10 numbers can of the last five be stored, dialled numbers called. and edited in the directory.
All manuals and user guides at all-guides.com Quick guide to handset display icons Star (*). Hash (#). Keypad locked. Recall. Pause. Number – left hand corner of display – directory entry number. ( NUMBER ) Directory empty. Quick Guide Menu Structure You can select a menu function more quickly if, rather than scrolling through the menu, you simply press the relevant buttons when the handset is in the idle state.
All manuals and user guides at all-guides.com Handset settings HANDSET VOL SET LEVEL 1 SET LEVEL 2 SET LEVEL 3 RINGER VOL SET LEVEL 1 SET LEVEL 2 SET LEVEL 3 SET LEVEL 4 MELODY MELODY 1 MELODY 2 MELODY 3 MELODY 4 MELODY 5 LANGUAGE...
Introduction Unpacking your Diverse Solo If anything is missing, please contact your place of purchase immediately. One Diverse Solo base station. One Diverse Solo handset. One power supply for the base station. One telephone line cord. Two AA rechargeable batteries.
All manuals and user guides at all-guides.com Safety information General Only use the power supply included with the product. Using an unauthorised power supply will invalidate your guarantee and may damage the telephone. The power supply unit number will be either M-GA35-095130F or M-GA35-095132F.
Setting Up IMPORTANT Please note that your handset is NOT registered to the base station. The Diverse Solo handset will be easily registered once you complete the steps 1 to 3 below. Plan the location Situate your product close enough to the telephone and mains power sockets so that the cables will reach.
All manuals and user guides at all-guides.com Registering and charging the handset The display is protected by a plastic film. Remove the protective film from the display. SEARCH BASE Insert the batteries Insert the two batteries supplied, as indicated on the label inside the battery compartment and slide the battery compartment cover shut.
Eventually they will need to be replaced. New batteries can be obtained from any BT shop or from the Diverse Helpline 08457 908070. If you replace the handset batteries with ones that have been fully charged, the battery indicator will not show full until the next charge cycle has been completed.
Ensure that each end of the line cord is fitted into the correct socket. Helpline Your Diverse Solo is now ready for use. However, if you experience any difficulties please call the BT Diverse Helpline on 08457 908 070. Signal strength The range of your Diverse Solo base station is 200 metres outdoors and up to 30 metres indoors under ideal conditions.
All manuals and user guides at all-guides.com Preparatory dialling Enter the phone number first and then check that it is correct. Press the GREEN PHONE button to dial the number. To end a call Press the RED PHONE button. Place the handset back on the base station. To receive an external call When the phone rings, pick up the handset and press the GREEN PHONE button to answer the call.
All manuals and user guides at all-guides.com Using the directory You can store up to 10 telephone numbers in the directory. You can enter numbers up to 22 digits. To store a number in the directory Press the DIRECTORY button. Press the UP or DOWN button to select the location number between 0 and 9 under which you want to store the number.
Important To use Caller Display you must first subscribe to the Service from your Network Provider. For more information on BT’s Select Services call BT free on 0800 800 150. If you subscribe to a Caller Display Service you can see the number of your caller on the handset display (unless the number has been withheld).
Page 14
All manuals and user guides at all-guides.com Press the OK button. The display shows the volume level. Press the DOWN button to select the earpiece volume level you want (1-3). Press the OK button to confirm. The display will show SAVED and you will hear a confirmation tone.
Page 15
All manuals and user guides at all-guides.com To change the handset display language Press the OK button to open the menu. Press the DOWN button until the display shows LANGUAGE. Press the OK button. Press the DOWN button to select the language you want.
All manuals and user guides at all-guides.com To reset the handset You can restore the handset to its factory settings. Press the OK button to open the menu. Press the DOWN button until the display shows HS RESET. Press the OK button. Press the DOWN button to display RESET YES? and press the OK button to confirm.
Page 17
Dialling mode Flash time tone 100ms To register your Diverse Solo handset to another GAP base station or to re-register to the Solo base station It is not possible to register other GAP handsets to the Solo base station, however, if you de-register the Solo handset, please follow the guidelines below.
Page 18
All manuals and user guides at all-guides.com Help Problem Possible Cause Solution Handset not The base is not Make sure that the registering. powered. power supply is plugged in at the base and switched There are no Make sure that the batteries in the rechargeable handset.
All manuals and user guides at all-guides.com General information Guarantee Your Diverse Solo is guaranteed for a period of 24 months from the date of purchase. Subject to the terms listed below the guarantee will provide for the repair of, or at BT’s or its agent’s discretion the option to...
Solo has a REN of 1. Any other instrument provided by BT may be assumed to have a REN of 1 unless stated otherwise. A total REN of 4 is allowed. (For example: if Diverse Solo is used in conjunction with three extension telephones, each with a REN of 1, the total REN is 4.)
All manuals and user guides at all-guides.com Press the OK button to confirm. Press the DOWN button until the display shows TONE. Press the OK button to confirm. Press the RED PHONE button. Setting pauses Please note If you want to insert a pause into a telephone number you are storing in your directory, start storing the number (see page 12) and where a pause is needed, press and hold button.
