Summary of Contents for Thermador HCSW
- Page 1 WALL HOODS (Turn Book Over for Installation Instructions) READ AND SAVE THESE INSTRUCTIONS HTSW HCSW HGSW 5551 McFadden Avenue, Huntington Beach, CA 92649 • 800/735-4328 ECO 71589 • 35-05-017F • © BSH Home Appliances Corp. 1997 • Litho in Italy 10/01...
-
Page 2: Important Safety Instructions Warning
IMPORTANT SAFETY INSTRUCTIONS WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: CAUTION FOR GENERAL VENTILATING USE ONLY. DO NOT USE TO EXHAUST HAZARDOUS OR EXPLOSIVE MATERIALS OR VAPOR. 1. Use this unit only in the manner intended by the manufacturer. - Page 3 LES INSTRUCTIONS DE SÉCURITÉ IMPORTANTES AVERTISSEMENT POUR RÉDUIRE LE RISQUE D’INCENDIE, ÉLECTRIQUE, BLESSURE AUX PERSONNES, OBSERVER LE SUIVANT: ATTENTION SEULEMENT POUR L’UTILISATION D’AÉRATION. NE PAS L’UTILISER POUR ÉPUISER LA VAPEUR OU LES MATIÈRES EXPLOSIVES OU DANGEREUSES. 1. Utiliser cet appareil seulement dans la manière destinée par le fabricant.
- Page 4 A for about 3 seconds until you hear the signal (beep); the LED D will now stop flashing. MODELS: HCSW and HSW ELECTRONIC PUSH BUTTONS A. Motor OFF button B. Motor ON button and speed selector 1, 2, 3, 1...
- Page 5 They are made of anodized aluminum To Remove The Metal Grease Filter/s • Disconnect electricity. for Models HSW, HCSW, HGSW • Push clips towards the center and pull the filters downward. Fig. 1. for Models HDW, HTSW • Push each handle towards the back and pull downwards Fig.
- Page 6 Replace Lights For Models HDW, HGSW, HCSW36/42 (Fig. 3) • Unscrew the light cover. • Remove the damaged light and replace with a new 12 Volt, 20 Watt (maximum) halogen light made for a G-4 base. Follow package directions and do not touch new light with bare hands.
- Page 7 Fig. 7 Page 7...
-
Page 8: Thermador Hood Warranty
We reserve the right to change specifications or design without notice. Some models are certified for use in Canada. Thermador is not responsible for products which are trans- ported from the U.S. for use in Canada. Check with your local Canadian distributor or dealer. -
Page 9: Important Safety Instructions
READ AND SAVE THESE INSTRUCTIONS L933C Ed. 05/98 INSTALLATION INSTRUCTIONS WALL HOOD SERIES: HDW, HSW, HCSW, HGSW, HTSW FOR RESIDENTIAL USE ONLY NOT TO BE INSTALLED OVER GAS GRILLS panel to indicate power has been switched off for maintenance. - Page 10 E. Due to size and weight of this unit two installers are recommended. F. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities. G. Ducted fans must always be vented to the outdoors. Do not LES INSTRUCTIONS DE SÉCURITÉ...
- Page 11 Page 3...
-
Page 12: Considerations Before Installing Hood
The lower the hood above the cooktop, the more efficient the capturing of cooking odors, grease and smoke. Thermador recommends the hood be installed 30-36" above the countertop. The lower height may be inconvenient for tall people and large cooking vessels. - Page 13 Preparation of mounting surface (Drywall) 1. Select a mounting height comfortable for the user and mark on wall behind cooktop. 2. Mark center line of cooktop and draw vertical line from bottom of hood to the ceiling. 3. Tape template, matching center- line and hood bottom as shown in Fig.
- Page 14 Appliance Installation: A. Install transition on top of hood if removed for shipping. Fig. C B. Hang hood on 2 mounting hooks through the rectangular cutouts on back of hood. Fig. D C. Level the appliance, using a carpenters level across bottom of hood with leveling screws in mounting hooks or rectangular cutouts.
- Page 15 6. Install duct cover per Fig. B. Make sure to leave this manual for the home owner. Alternate - reduced ceiling height Installation for HCSW and HSW models: The hood may be installed with only the lower part of the duct cover to reduce the overall height.
- Page 16 Alternate - reduced ceiling height Installation for HDW and HTSW and HGSW models: The hood may be installed with only the lower part of the duct cover to reduce the overall height. This hood height is signified by * in Table 1. For the duct cover to slide down and engage the top of the hood, the ceiling bracket must be mounted 1/4"...
