FBU345 Specifications and Layout

The Table 8. FBU345 specifications shows the specifications for the FBU 345 Supercap. The Figure 19.
FBU345 layoutsame device followed by its dimensions and pin description.
Super Capacitor Module Operating Temperature
Super Capacitor Module Storage Temperature
Rated Voltage
Surge Voltage
Super Capacitor Module Capacity
Capacity Tolerance
RMFBU5 Cache Off-load Module Mechanical
Rated Energy
Super Capacitor Module Charge Time
Super Capacitor Module Shelf Life
Super Capacitor Module Operational Life
Maximum Equivalent Series Resistance (ESR)
Weight
The FBU345 is very sensitive to the high operating temperature, and excessive heat may shorten its life. The
over temperature detection circuitry sends an event to the RAID module when the operating temperature is
over 55 degrees Celsius, which gets registered in the module's log file.
39
Item

Table 8. FBU345 specifications

Value
0°C to 55°C
0°C to 70°C
13.5 VDC
14.25 VDC
7.6 F
65 mm x 52 mm
-0%, +30%
0.04 Wh
Approximately 2 minutes
3 years
Intel provides a three-year warranty on the Intel®
RMFBU AXXRMFBU7.
190 mOhm
46 g
