Quadra-Fire 3100 Millennium Owner's Manual

Wood appliance automatic combustion control
Hide thumbs Also See for 3100 Millennium:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with question on installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
3100 MILLENNIUM WOOD
APPLIANCE
AUTOMATIC COMBUSTION
CONTROL (ACC)
MODEL:
31M-ACC-C
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Owner's Manual
Operation & Care
R
7033-351D
WARNING
If the information in these instructions is
not followed exactly, a fire could result
causing property damage, personal injury,
or death.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
•
Do not over-fire - If appliance or chimney connector
glows, you are over-firing. Over-firing will void
your warranty.
•
Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass and appliance will cause burns.
•
Do not touch glass until it is cooled
•
Use leather gloves when reloading fuel
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room
as appliance.
•
Alert children and adults to hazards of
high temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other
flammable materials away.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may over-fire and generate
poisonous gases (i.e. carbon monoxide).
NOTE: To obtain a French translation of this
manual, please contact your dealer or visit
www.quadrafire.com
REMARQUE : Pour obtenir une traduction française de
ce manuel, s'il vous plaît contacter votre
revendeur ou visitez
www.quadrafire.com
September 9, 2019

Advertisement

Table of Contents
loading

Related Manuals for Quadra-Fire 3100 Millennium

Summary of Contents for Quadra-Fire 3100 Millennium

  • Page 1 NOTICE: DO NOT DISCARD THIS MANUAL If the information in these instructions is not followed exactly, a fire could result causing property damage, personal injury, 3100 MILLENNIUM WOOD or death. APPLIANCE • Do not store or use gasoline or other flammable...

  • Page 2: Sample Of Serial Number / Safety Label

    31M-ACC-C NOTE: Clearances may only be reduced by means approved by the regulatory authority having jurisdiction A. Sample of Serial Number / Safety Label LOCATION: Back of appliance ITEM PART NUMBER PART NAME 7033-354 SERIAL RATING PLATE CAUTION HOT WHILE IN OPERATION DO NOT TOUCH, KEEP CHILDREN AND CLOTHING AWAY. CONTACT MAY CAUSE SKIN BURNS. KEEP FURNISHINGS AND OTHER COMBUSTIBLE MATERIAL FAR AWAY FROM THE APPLIANCE.

  • Page 3: Table Of Contents

    K. Negative Pressure......15 L. Frequently Asked Questions ....16 Quadra-Fire is a registered trademark of Hearth & Home Technologies. September 9, 2019...

  • Page 4: Warranty Policy

    31M-ACC-C B. Warranty Policy Hearth & Home Technologies LIMITED LIFETIME WARRANTY Hearth & Home Technologies, on behalf of its hearth brands (“HHT”), extends the following warranty for HHT gas, wood, pellet and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: WARRANTY PERIOD: distributor, whichever occurs earlier.
  • Page 5 31M-ACC-C WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • • This warranty is only valid in the country in which the HHT authorized dealer or distributor that sold the appliance resides. •...
  • Page 6 31M-ACC-C This warranty is void if: • • • There is any damage to the appliance or other components due to water or weather damage which is the result of, but not limited LIMITATIONS OF LIABILITY • have other rights, which vary from state to state. EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN.

  • Page 7: Quick Start Guide

    31M-ACC-C C. Quick Start Guide NOTE: These are generic drawings and may not represent your specifi c model. 10 Pieces of Newspaper, 10-20 Pieces of Dry ITEMS NEEDED FOR FIRST FIRE: Kindling and Few Pieces of Dry Split Wood. OPEN AIR CONTROLS LOAD WOOD ADD NEWSPAPER...

  • Page 8: Listing And Code Approvals

    31M-ACC-C Listing and Code Approvals B. BTU & Efficiency Specifications A. Appliance Certification Model: 3100 Millennium Wood Appliance EPA Certification 86-17 Number: Laboratory: OMNI Test Laboratories, Inc. EPA Certified Emissions: 1.9 grams per hour Report No: 0061WS066S *LHV Tested Efficiency: 78.3%...

  • Page 9: Glass Specifications

    31M-ACC-C C. Glass Specifications WARNING This appliance is equipped with 5mm ceramic glass. Replace glass only with 5mm ceramic glass. Please contact your dealer for replacement glass. Fire Risk. Hearth & Home Technologies disclaims any responsibility for, and the warranty will be D.

  • Page 10: Operating Instructions

    Chimney connector or appliance glowing In order to improve the situation, we at Quadra-Fire Roaring, rumbling noises have developed cleaner-burning wood appliances that Loud cracking or banging sounds...

  • Page 11: Air Controls

    31M-ACC-C E. Using Burn Rate Air Control & ACC System 2. Second Stage The next stage of burning, the secondary stage, is the 1. Start up and Reloading Fuel period when the wood gives off flammable gases which Open both Burn Rate Air Control and ACC systems burn above the fuel with bright flames.

  • Page 12: Burn Rates And Operating Efficiency

    31M-ACC-C F. Burn Rates and Operating Efficiency WARNING For maximum operating efficiency This wood appliance has a manufacturer-set minimum Risk of Fire. low burn rate that must not be altered. It is against federal When set on High Burn Rate and over-riding regulations to alter this setting or otherwise operate this the Automatic Combustion Control system an wood appliance in a manner inconsistent with operating...

  • Page 13: Building A Fire

    31M-ACC-C G. Building A Fire NOTE: Before lighting your first fire in the appliance: • Build fire on brick firebox floor. • Do NOT use grates, andirons or other methods to NOTE: The special high temperature paint that your support fuel. It will adversely affect emissions. appliance is finished with will cure as your appliance heats.

  • Page 14: Blower Operating Instructions

    I. Opacity (Smoke) H. Blower Operating Instructions This is the measure of how cleanly your appliance is NOTE: If your Quadra-Fire wood appliance is equipped burning. Opacity is measured in percent; 100% opacity is with an optional blower, you should follow these...

  • Page 15: Clear Space

    31M-ACC-C J. Clear Space K. Negative Pressure • Do NOT place combustible objects within 4 ft (1.2 m) of WARNING the front of appliance (Figure 15.1). • Mantel: Asphyxiation Risk. Avoid placing candles and other heat-sensitive objects • Negative pressure can cause spillage on mantel or hearth.

  • Page 16: Frequently Asked Questions

    31M-ACC-C L. Frequently Asked Questions ISSUES SOLUTIONS When first operated, this appliance may release an odor for the first several hours. This is Odor from appliance caused by the curing of the paint and the burning off of any oils remaining from manufacturing. Noise is caused by metal expanding and contracting as it heats up and cools down, similar to Metallic noise the sound produced by a furnace or heating duct.

  • Page 17: Maintenance And Service

    31M-ACC-C Maintenance and Service CAUTION A. Quick Reference Maintenance Guide When properly maintained, your fireplace will give Allow the appliance to completely cool down before you many years of trouble-free service. Contact your performing any cleaning or maintenance. Start the dealer to answer questions regarding proper operation, first inspection after the first 2 months of use, or if troubleshooting and service for your appliance.

  • Page 18: General Maintenance

    31M-ACC-C B. General Maintenance 2. Disposal of Ashes • Frequency: When ash is within 1-3/4 in. (44mm) of 1. Creosote (Chimney) Cleaning firebox lip • Frequency: Every 2 months during heating season or • By: Homeowner as recommended by a certified chimney sweep; more frequently if chimney exceeds or is under 14-16 ft.
  • Page 19 31M-ACC-C 4. Glass Cleaning 6. Inspect Firebrick • Frequency: As desired • Frequency: After each ash removal • By: Homeowner • By: Homeowner Replace the firebrick if they become crumbly and/or if there CAUTION is a 1/4 inch (6.35mm) gap between the bricks. Handle glass assembly with care.

  • Page 20: Correct Baffle & Blanket Placement

    31M-ACC-C INCORRECT POSITIONS C. Correct Baffle & Blanket Placement WARNING Fire Risk. Firebox damage due to improper baffle placement is not covered by warranty. Operate the wood burning appliance with the baffle in the correct position only. Not doing so could result in: •...

  • Page 21: Troubleshooting Guide

    31M-ACC-C Troubleshooting Guide With proper installation, operation, and maintenance your wood appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist you or a qualified service person in the diagnosis of a problem and the corrective action to be taken.

  • Page 22: Service Part Replacement

    NOTE: DO NOT OVER TIGHTEN RETAINERS - can cause glass to break. 9. Replace the door on the appliance. Quadra-Fire appliances are equipped with ceramic super heat-resistant glass, which can only be broken by impact or misuse. WARNING Figure 22.1...

  • Page 23: Snap Disc Replacement

    31M-ACC-C C. Snap Disc Replacement Service Part: SRV230-0470 1. Locate the snap disc bracket assembly at the bottom left rear corner of the appliance. 2. A magnet holds the bracket to the appliance. Pull the bracket down away from the appliance to expose the snap disc.

  • Page 24: Door Handle Assembly

    31M-ACC-C E. Door Handle Assembly F. Tube Channel Assembly Replacement Service Part: SRV7033-023 Service Part: 832-0540 Removing Tube Channel Assembly 1. Install washer on door handle shaft. 1. Remove the right side shield by removing 2 screws in 2. Slide door handle through door. 3.

  • Page 25: Reference Materials

    31M-ACC-C Reference Materials A. Service and Maintenance Log Date of Service Performed By Description of Service September 9, 2019 7033-351D...
  • Page 26 31M-ACC-C Date of Service Performed By Description of Service 7033-351D September 9, 2019...

  • Page 27: Exploded View

    31M-ACC-C B. Exploded View 31M-ACC-C Service Parts Millennium - Wood Stove Beginning Manufacturing Date: June 2017 Advanced Combustion Control (ACC) Ending Manufacturing Date: Active Part number list on following page. 09/19 September 9, 2019 7033-351D...

  • Page 28: Service Parts

    31M-ACC-C C. Service Parts 31M-ACC-C Service Parts Beginning Manufacturing Date: June 2017 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
  • Page 29 Cam Latch SRV430-1141 13.6 Nut, Locking Door Handle Pkg of 24 226-0100/24 Component Pack: (Spring Handles(1) 1/2” & (2) 1/4”, 2 Nickel 436-5360 Hinge Pins, & Quadra-Fire Logo) Additional service part numbers appear on following page. September 9, 2019 7033-351D...
  • Page 30 31M-ACC-C 31M-ACC-C Service Parts Beginning Manufacturing Date: June 2017 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor.

  • Page 31: Accessories

    31M-ACC-C D. Accessories 31M-ACC-C Service Parts Beginning Manufacturing Date: June 2017 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
  • Page 32 CONTACT INFORMATION Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL •...
