This maintenance information manual (MIM) is to be used
to service the diskette drive after it has been removed from
the particular unit of the 5280 system in which it is housed.
Customer engineers using this manual are assumed to have
completed the 5280 education course.
This MIM has three major sections: Maintenance, Tools
and Test Equipment, and Theory. Maintenance includes
locations, procedures, and diagnostic aids. Tools and Test
Equipment includes a list of special tools and test
equipment and the part numbers of the tools and test
equipment. Theory includes data flow, functional units,
and features.
Definitions of terms and abbreviations that are not
common, but are used in the MIM, are in the Glossary of
Terms and Abbreviations.
There are several DANGER and CAUTION notices in this
manual. You can use the blank lines below each notice to
translate it into your own words. The locations of these
notices are listed in the Safety section.
Related Publications
Related information can be found in the following
manuals:
• IBM 5280 General Information Manual, GA21-9350
• IBM 5280 Operator's Guide, GA21-9364
Preface
• IBM 5280 User's Setup Procedures, GA21-9365
• IBM 5280 Data Areas and Diagnostic Aids Handbook,
SY31-0595
• IBM 5281 Data Station Maintenance Information
Manual, SY31-0596
• IBM 5282 Dual Data Station Maintenance Information
Manual, SY31-0597
• IBM 5286 Dual Programmable Data Station
Maintenance Information Manual, SY31-0599
• IBM 5285 Programmable Data Station Maintenance
Information Manual, SY31-0600
• IBM 5288 Programmable Control Unit Maintenance
Information Manual, SY31-0601
• The IBM Diskette General Information Manual,
GA21-9182
