Specifications

Amplifier section
DIN power output
(LBT-XB3)
(LBT-XB5)
(LBT-XB6)
Continuous RMS power output
(LBT-XB3)
(LBT-XB5)
(LBT-XB6)
Music power output:
(LBT-XB3)
(LBT-XB5)
(LBT-XB6)
Inputs
PHONO IN (phono jacks):
VIDEO (AUDIO) IN (phono jacks):
MIX MIC (phone jack):
Outputs
PHONES (stereo phone jack):
SPEAKER:
(LBT-XB3)
(LBT-XB5/XB6)
SURROUND SPEAKER (LBT-XB5/XB6 only):
40
55 + 55 watts
(6 ohms at 1 kHz, DIN)
100 + 100 watts
(6 ohms at 1 kHz, DIN)
100 + 100 watts
(6 ohms at 1 kHz, DIN)
65 + 65 watts
(6 ohms at 1 kHz, 10%
THD)
120 + 120 watts
(6 ohms at 1 kHz, 10%
THD)
120 + 120 watts
(6 ohms at 1 kHz, 10%
THD)
100 + 100 watts
210 + 210 watts
210 + 210 watts
sensitivity 3 mV,
impedance 47 kilohms
sensitivity 250 mV,
impedance 47 kilohms
sensitivity 1 mV,
impedance 10 kilohms
accepts headphones of 8
ohms or more
accepts impedance of 6 to
16 ohms
accepts impedance of 8 to
16 ohms
accepts impedance of 16
ohms
CD player section
System
Laser
Laser output
Wavelength
Frequency response
Signal-to-noise ratio
Dynamic range
Tape player section
Recording system
Frequency response
(DOLBY NR OFF)
Wow and flutter
Compact disc and digital
audio system
Semiconductor laser
( = 780 nm)
Emission
duration: continuous
Max. 44.6 F*
* This output is the value
measured at a distance of
200 mm from the
objective lens surface on
the Optical Pick-up Block
with 7 mm aperture.
780 – 790 nm
2 Hz – 20 kHz (±0.5 dB)
More than 90 dB
More than 90 dB
4-track 2-channel stereo
60 – 13,000 Hz (±3 dB),
using a Sony TYPE I
cassette
60 – 14,000 Hz (±3 dB),
using a Sony TYPE II
cassette
±0.15% W. Peak (IEC)
0.1% W. RMS (NAB)
±0.2% W. Peak (DIN)
