Campbell Hausfeld RP3300 Easy Setup Manual

12-Volt Inflator
RP3300
Inflation —
1
• • • •
Connect universal adapter to valve stem or
needle securely into the universal adapter. With universal adapter
in place, Press locking lever down.
Setup Like a Pro
chpower.com
Visit us at
Setup Like a Pro
Easy Setup Guide
Projects are easier with
Campbell Hausfeld products.
Thank you for deciding to purchase a
Campbell Hausfeld product. We are dedicated
to providing tools that help you to complete your
projects Like a Pro.
Items that require less than 20 psi
•
Insert
Inflation —
1
• •
Connect
adapter to valve stem.
With unversal adapter in
place, press
lever down.
IN728800AV 2/09
2
• •
inflation Turn pressure
selector dial to LO.
Between 20 psi and 99 psi
2
• • • • • • •
universal Turn pressure
selector dial to desired
pressure.
locking
Actual Pressure
Desired
Pressure
3
• • • • • • • •
Push power button.
RP3300 — 12-Volt Inflator
3
• • • • • •
Push
power
button.
4
• • • • •
Item reaches desired
Push
firmness, power
button. Gauge displays
actual pressure.
5
• • • • •
Repeat
Steps 3 and 4
for more inflation.
