DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
7

DEFINITY LAN Gateway System

Installing DEFINITY LAN Gateway in a Single-Carrier Cabinet

DEFINITY LAN Gateway System
The DEFINITY LAN Gateway lets DEFINITY exchange messages with LAN
communications software. The DEFINITY LAN Gateway system is used in display
set mode only, not in control link. Use it with the R8r, R8si, or R8csi. Refer to the
DEFINITY Communications System Generic 3 Installation, Administration and
Maintenance of CallVisor ASAI over the DEFINITY LAN Gateway for complete
installation procedures.
Use the add subscribers command during administration, to prevent a no port
available error. When administration is complete, enter reset system reboot to
clear all alarms.
Installing DEFINITY LAN Gateway in
a Single-Carrier Cabinet
The DEFINITY LAN Gateway system installs in five adjacent slots, preferably the
five rightmost slots in a Single-Carrier Cabinet. See
!
CAUTION:
Do not power up the DEFINITY LAN Gateway System until instructed to do
so. Refer to the DEFINITY Communications System Generic 3 Installation,
Administration and Maintenance of CallVisor ASAI over the DEFINITY LAN
Gateway.
It is not necessary to power down a system before installing a DEFINITY LAN
Gateway.
7
Figure 25.
Issue 1
April 2000
99
