DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
4 Data Modules and Asynchronous Data Units

Installation Procedure

Installation Procedure
To install a typical data module, you perform the following tasks:
1.

Obtain Required Equipment

2.

Sett Hardware Options

physically connect the data module)
3. Connect Data Modules
4. Administer the DEFINITY ECS for Data Modules
before or after you physically connect the data module)
Obtain Required Equipment
To physically connect a data module to the system, you need the following parts.
105C/D Isolating Data Interface (if connecting to a DC cabinet)
EIA-232-D (RS-232-C) cable with a male connector (for the data module)
and the correct connector for the peripheral equipment
The cable connects the PC to the data module
Null-modem converter (optional)
V.35 cable with correct connectors (not required by all systems)
D8W telephone cord
The cord connects the data module's LINE jack to the DEFINITY wall jack.
DCP telephone and D8W cord (optional)
The D8W cord connects the telephone to the data module's PHONE jack.
Suitable auxiliary power supply if the optional telephone is installed (D7AP
power cord and 400B2 adapter in the US, international power supply,
such as the MSP-1, elsewhere).
You must have access to the administration console of the DEFINITY, either
through a terminal and keyboard or through a PC.
A breakout box for RS-232 interfaces may prove helpful in some cases. The RS-
232 breakout box helps you to identify the pin configuration of the RS-232
interface on the equipment you are trying to connect.
Set Hardware Options
Depending on the data module, you may have to set various configuration
options using hardware switches, software commands, or both. You must set the
hardware options before you administer or physically install the data module.
(must be completed before you administer or
Issue 1
April 2000
(can be completed either
27
