5 External Modems

Setting Up the U.S. Robotics Modem for DEFINITY

Setting Up the U.S. Robotics Modem
for DEFINITY
The U.S. Robotics modem external modem is recommended for DEFINITY
systems. For instructions on how to physically connect it and for general
configuration instructions, see the documentation that came with the modem.
This document describes configuring the modem for particular DEFINITY
adjuncts.
All configuration is done via hardware switches. Proceed as follows.
1. Set the DIP switches on the modem to match the settings listed in the table
below (for switch locations, consult the documentation that came with the
modem).
Table 13. U.S. Robotics External Modem Switch Settings
Switch
1
2
3
4
5
6
7
8
Administering the DEFINITY for
Modems
You have to administer each modem that you attach to the system.
NOTE:
Only the basic procedure is covered here. For the full range of options, see
the DEFINITY R8 Administrator's Guide.
Accessing the Administration Form
1. Open the modem-administration form. At the management terminal, enter
change system-parameters maintenance.
2. Scroll to page 3 of the form.
Setting Function
OFF (Up) DTR (Data Terminal Ready) override
OFF (Up) Result codes
ON (Down) Result codes
OFF (Up) Keyboard command echo
ON (Down) Auto answer
OFF (Up) CD (Carrier Detect) override
OFF (Up) Power-on and ATZ reset software defaults
ON (Down) AT command recognition
Issue 1
April 2000
Continued on next page
