DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
6 Printers

Connecting the Printer

Using the Control Panel
1. Use Line Feed or Form Feed to step through the options for the function.
2. To activate the menu for the function, press On Line.
3. To step through the options for the function, press Line Feed and Form
Feed.
4. When you reach the option you are looking for, press Print Quality to
select.
The printer prints the new setting. Repeat for each option to be set.
5. When finished, press Print Quality. The printer changes to normal mode.
Connecting the Printer
Connect the printer using one of the following methods:
An Asynchronous Data Unit (ADU) or data module (see
Modules and Asynchronous Data
A direct, RS-232 connection from the serial port on the printer (often
labeled COM) to the serial port on the DEFINITY ECS (labled DCE).

Okidata Model OP16N

The following sections describe the set-up of the printer and associated interfaces
used during testing.
Setting Up the OP16N
1. Set up the printer, install toner, and load paper as described in the vendor
documentation, with one exception: fill the paper tray until the paper
indicator gauge reads PAPER FULL.
Do not try to load the full 500 sheets of 20-lb paper indicated in the
documentation. The true capacity is usually about 475 sheets. When more
is loaded, the printer jams.
Connecting OP16N to CMS
Connecting the OP16N via a parallel port
If the new printer is being connected to CMS through the parallel interface, the
connectivity has not changed.
Units'')
Issue 1
April 2000
95
Chapter 4, ''Data
