Accessing the Stack

U Q C
SING UICK ONFIG
The PS Hub uses community strings as a security measure, to check
management access to the stack. The community string you use must
match one of the community strings configured for the stack. Quick
Config Manager remembers the last community string used.
The default community string is security which allows you to view and
configure the stack's information. We recommend you change the
community string as soon as possible for security reasons (use the Edit
Access Levels dialog box), but ensure you remember the community
string as you cannot manage the hub without it.
To enter the community string:
1 From the Configure menu, select Community/Polling.
Quick Config Manager displays the Community/Polling dialog box, as
shown in Figure B-3.
Community/Polling Dialog Box
Figure B-3
2 Enter the community string in the box.
3 Click OK.
Changes made to this dialog box only take effect for new windows.
Any graphs or zoom view windows that are already open will continue
to use the old values. Close these windows and reopen them to use
the new values.
