Unit Status

This page provides detailed information about the unit:
Unit Name The name configured for the stack.
Location Where the stack is located.
Contact The person to contact if there is a problem with the stack.
The Unit Name can be configured using the System Name page (in the
Management Settings category), refer to "System Name" on page 7-19.
The Location and Contact can be configured using Quick Config
Manager or an SNMP network management application.
Unit Description The unit's product name.
Hardware Rev The version of hardware inside the unit.
MAC Address The unit's MAC (Ethernet) address.
Software Version The version of management software that the unit
is running.
Boot PROM Version The version of software on the Boot PROM inside
the unit.
Unit Uptime The time that has elapsed since the unit was last reset,
initialized or powered on.
Unit Attention Light A checkbox for you to light the Attn LED, to
help identify the unit in the stack.
To display the Management Addresses page, click IP Setup at the
bottom of the Unit Status page.
