ELECTROLUX HOME PRODUCTS PTY LTD
ABN 51 004 762 341
Technical Publication Nº KSSSI113
DIAGNOSTIC MANUAL
Release Date: September 2011
Copyright 2013 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services
KELVINATOR
SPLIT SYSTEM
AIR-CONDITIONER
Issue: 2
Date: 01/13
MODEL:
KSV26HRC
PNC: 950132910
KSV35HRC
PNC: 950132911
Advertisement
Related Manuals for Electrolux KSV26HRC
Summary of Contents for Electrolux KSV26HRC
- Page 1 ELECTROLUX HOME PRODUCTS PTY LTD ABN 51 004 762 341 Issue: 2 Technical Publication Nº KSSSI113 Date: 01/13 KELVINATOR SPLIT SYSTEM AIR-CONDITIONER DIAGNOSTIC MANUAL MODEL: KSV26HRC Release Date: September 2011 PNC: 950132910 KSV35HRC PNC: 950132911 Copyright 2013 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
-
Page 2: Table Of Contents
Index: Indoor Display Standby Heating Cooling Description – (Indoor) Page Nº Code Safe Electrical Working Practices Positive Lock Terminals Capacitor Discharge 6 & 7 Led Flash Code Sequence Description 8 & 9 Not Operating Diagnostic Display Mode Description 29 to 31 Wiring Diagram (Indoor &... - Page 3 Green Yellow Description – (Outdoor) Page Nº Normal Communication Flash-1 Normal Operation Flash-8 Normal Operation Flash-0.5 Defrosting Flash-2 Frequency Limit Flash-1 Anti-High Temperature Protection Flash-3 Low Voltage Protection Flash-12 High Voltage Protection Flash-13 Flash-3 Anti-Freeze Protection Flash-4 Anti-Freeze Limit, Frequency Drop Flash-4 Anti-High Temperature Protection Communications Fault...
-
Page 4: Safe Electrical Working Practices
Safe Electrical Working Practices Remove Power cord, Fuse or Switch off the circuit breaker. Always check appliance with multimeter to ensure the supply power is disconnected. Use only insulated tools & equipment. Wear insulated shoes. No water on the floor or working space. Reduce the amount of exposed skin, by covering your arms and legs. -
Page 5: Capacitor Discharge
Capacitor Discharge Discharge the capacitors located on the outdoor main PCB assembly. Note: Even if the power supply has been disconnected, high voltage power can be stored in these capacitors. Discharge the capacitors with the use of a 25 or 40-Watt incandescent globe. As illustrated below. Electrolytic Capacitors Bulb (25-40W) Page 5 KSSSI113... -
Page 6: Led Flash Code Sequence Description
LED Flash Code Sequence Description (Indoor Display PCB) # In the event of a complete shutdown or an operational control adjustment the Standby, Heating or Cooling LED’s on the indoor display PCB flash to indicate this sequence. Note: The LED’s flash at a 1 second rate for the required number of flashes, and then a 2 second pause before repeating the 1 second rate sequence. -
Page 7: Led Flash Code Sequence Description
LED Flash Code Sequence Description (Outdoor PCB) # In the event of a complete shutdown or an operational control adjustment the outdoor PCB Green, Yellow & Red LED’s flash to indicate this sequence. Note: The LED’s flash at a 1 second rate for the required number of flashes, then a 2 second pause before repeating the 1 second rate sequence. -
Page 8: Not Operating
Not Operating: # Check the wiring configuration from the outdoor unit to the indoor unit. Is it wired up correctly in accordance to the wiring diagrams provided on both indoor & outdoor units? (Refer pages 29 to 31) # While the unit is in “standby” mode, check if the red stand by light is on? # Try operating the unit by the forced operations button: By pressing the button once, the unit should activate in Auto mode. -
Page 9: Not Operating
Not Operating Continues # Check for supply voltage at the following connection points: From the isolation switch to the Active-In & Neutral connector points located on the indoor PCB. If supply power is available at the above connector points, yet the unit can still not be operated by the remote control or the forced operation button, replace the indoor PCB. -
Page 10: Diagnostic Display Mode Description
Diagnostic Display Mode Description: Built into the software for models: KSV26HRC & KSV35HRC are two different diagnostic methods: (Fault Codes & Condition Codes) that can be used to help diagnose various faults. These two diagnostic types are described in the following pages. - Page 11 Fault Code Description Continues: E8, Indoor Unit. (Delayed) Indoor Standby LED, flash 8 times. (Delayed) Red LED, Outdoor unit flashing 3 times. (Anti-High Temperature Protection) # Check the indoor coil for airflow obstructions. # Check the indoor fan motor for correct operation. H1, Indoor unit.
- Page 12 Condition Code Description: D1, Indoor unit - (Condition Code) DRED (Demand Response Electrical Device) # Compressor off. D2, Indoor unit - (Condition Code) DRED (Demand Response Electrical Device) # Output capacity limited to 50%. D3, Indoor unit - (Condition Code) DRED (Demand Response Electrical Device) # Output capacity limited to 75%.
- Page 13 Condition Code Continues: PO, Indoor Unit - (Condition Code) {Remote Control Access - 5} (Compressor Minimum Frequency - Test State) # Set remote control: (Cooling mode: 16ºC – Heating mode: 27ºC) P1, Indoor Unit - (Condition Code) {Remote Control Access - 5} (Compressor Rated Frequency - Test State) # Set remote control: (Cooling mode: 18ºC –...
- Page 14 EE, Indoor unit. Indoor Heating LED, flash 15 times Yellow LED, Outdoor unit flashing 11 times. (Loading EEPROM malfunction) # Check if the Program Chip is anchored correctly to the outdoor PCB. Note: If the Program Chip is correctly anchored, yet “EE” fault still exists, replace the outdoor PCB assembly.
- Page 15 Communication Fault: E6, Indoor unit. Indoor Standby LED, flash 6 times. Green LED, Outdoor unit off. # If applicable, disconnect the DRED (Demand Response Enabled Device) or also known as a (Peak Smart Meter) connecting network cable plug, located at the rear corner of the indoor unit (behind the terminal block).
- Page 16 Communication Fault: E6, Indoor unit. Indoor Standby LED, flash 6 times. Green LED, Outdoor unit off. # Disconnect the main power supply to the indoor unit by means of the isolation switch. After approximately one minute, turn the power supply back on & attempt to operate the unit in “Auto” mode with a set temperature of two degrees above or below the ambient temperature.
- Page 17 Communication Fault Continues: # Disconnect the supply power & check the continuity of the COM-U wire from the following points: COM-U terminal point on the indoor PCB. To the communication terminal points on the indoor terminal block. To the communication terminal points on the outdoor terminal block. To the COM-U terminal point on the outdoor PCB.
- Page 18 Communication Fault Continues: # Check the continuity of the connecting wires from the outdoor PCB to the Reactor, as listed below. Orange terminal point on outdoor PCB to orange terminal point on Reactor. White terminal point on outdoor PCB to white terminal point on Reactor. Check the continuity of the reactor.
- Page 19 IPM Protection: H5, Indoor unit. (Delayed) Indoor Heating LED, flash 5 times (Delayed) Yellow LED, Outdoor unit flashing 4 times. # Disconnect the supply power to the unit by means of the isolation switch. # Remove the Blue-U, Yellow-V & Red-W spade terminals from the main outdoor PCB to the compressor, then measure the resistance value of each winding from these three spade terminal points.
- Page 20 IPM Protection Continues: # Remove the Blue, Yellow & Red wires that connect to the U, V & W terminal points on the outdoor main PCB. # Check for continuity across any terminal combination of the U, V & W spade terminal points. Note: All continuity checks should read “open circuit”.
- Page 21 IPM Protection Continues: # Check for >100V-DC between the following points: Negative DC & positive DC-U Negative DC & positive DC-V Negative DC & positive DC-W If >100V-DC is not available at each of the above test points, replace the main outdoor PCB. Negative &...
- Page 22 F3 Indoor unit. Indoor Cooling LED, flash 3 times. Red LED, Outdoor unit flashing 5 times. (Outdoor Ambient Sensor) F4, Indoor unit. Indoor Cooling LED, flash 4 times. Red LED, Outdoor unit flashing 6 times. (Outdoor Coil Sensor) F5, Indoor unit. Indoor Cooling LED, flash 5 times.
- Page 23 F1, Indoor unit. Indoor Cooling LED, flash 1 time. (Room Temp Sensor Failure) F2, Indoor unit. Indoor Cooling LED, flash 2 times. (Tube Temp Sensor Failure) # Check the Indoor Ambient & Indoor Tube sensors for correct connection. # Check the continuity of the relevant sensor, if the sensor is open circuit, change it. Note: If all the above checks relating to the sensors &...
- Page 24 H6, Indoor unit. (Indoor Fan Stall) Indoor Standby LED, flashing 11 times. Yellow LED, Outdoor unit flashing 6 times. (High Temp Prevention) Red LED, Outdoor unit flashing 3 times. (High Temp Prevention) # Check if the filters are blocked on the indoor unit. # Check the refrigerant charge.
- Page 25 L3, Indoor unit. Indoor Standby LED, flashing 23 times. Red LED, Outdoor unit flashing 14 times. (Outdoor DC Fan Motor Malfunction) # Check the condenser fan for correct operation. If the fan motor is not operating check the three pin DC-Motor connector plug for correct termination to the outdoor PCB.
- Page 26 H3, Indoor unit. Indoor Heating LED, flashing 3 times. Yellow LED, Outdoor unit flashing 8 times. (Compressor Overload Protection) # Check the following points: Refrigerant charge. Restrictions within the capillary tube. Poor air flow across the indoor & outdoor coils. Correct operation of the four-way reversing valve.
- Page 27 LP, Indoor unit. Indoor Standby LED, flash 23 times (Indoor & Outdoor units don’t match) # Check if the Indoor & Outdoor units are correctly matched. Note: If the indoor & outdoor units are from two different model types, the LP fault code will be displayed.
- Page 28 E3, Indoor unit. Indoor Standby LED, flashing 3 times. (Refrigeration System Blocked or Gas Leakage) # Check the Low Pressure Sensor connector plug located on the outdoor PCB & the two spade terminals located on the Low Pressure Sensor for correct termination & continuity. # Check the Low Pressure Sensor located next to the compressor.
- Page 29 Indoor Wiring Diagram: KSV26 & 35CRC/HRC Page 29 KSSSI113...
- Page 30 Outdoor Wiring Diagram: KSV35CRC Page 30 KSSSI113...
- Page 31 Outdoor Wiring Diagram: KSV26 & 35HRC Page 31 KSSSI113...
