GB Cordless Steel Rod Cutter
Instruction manual
DSC163

Advertisement

Table of Contents
loading

Related Manuals for Makita DSC163

Summary of Contents for Makita DSC163

  • Page 1 GB Cordless Steel Rod Cutter Instruction manual DSC163...

  • Page 4: Specifications

    26. Blade B on Cutter Rod Side B 18. Blade A (Thicker Blade) 27. Spare Blades SPECIFICATIONS Model DSC163 Max. Cutting Capacity (Dia.mm) Grade 40 - Grade 60 16 mm Grade 40: Tensile Strength 490 N/mm 70,000 PSI Grade 60: Tensile Strength 620 N/mm...
  • Page 5 WARNING: 5. When operating a power tool outdoors, use an • The vibration emission during actual use of the power extension cord suitable for outdoor use. Use of a tool can differ from the declared emission value cord suitable for outdoor use reduces the risk of depending on the ways in which the tool is used.
  • Page 6 9. Always wear protective goggles to protect your 8. Keep handles and grasping surfaces dry, clean eyes from injury when using power tools. The and free from oil and grease. Slippery handles and goggles must comply with ANSI Z87.1 in the USA, grasping surfaces do not allow for safe handling and EN 166 in Europe, or AS/NZS 1336 in Australia/ control of the tool in unexpected situations.

  • Page 7: Functional Description

    CAUTION: Only use genuine Makita batteries. Use DO NOT let comfort or familiarity with product (gained of non-genuine Makita batteries, or batteries that have from repeated use) replace strict adherence to safety been altered, may result in the battery bursting causing rules for the subject product.

  • Page 8: Operating Procedure

    If the condition does not change, battery cartridge with the groove in the housing and slip it have the tool repaired by a Makita local service center. into place. Insert it all the way until it locks in place with a little click.

  • Page 9: Blades Replacement Procedure

    WARNING: Rotating Function of Motor (Fig. 13) • When cutting rebar, adjust the Stopper according to the The Motor Body can be rotated through 360 degrees, in diameter of the rebar to be cut so that the rebar is at 90 either direction, during operation.

  • Page 10: Adding Oil

    7. Repeat the above procedure several times until the oil level remains correct. CAUTION: • Only pure hydraulic oil as recommended by Makita should be used in this tool. Recommended oils include the Makita supplied hydraulic oil, Super Hyrando #46 (JX Nippon Oil &...

  • Page 11: Troubleshooting

    TROUBLE SHOOTING WARNING: • Remove battery before working on machine. PROBLEM CAUSE SOLUTION Cutter Rod will not Insufficient oil Top up oil. (Refer to “Adding Oil”) extend. Cutter Rod has not returned completely due Manually push back Cutter Rod. to build up of debris between Cutter Rod and Remove debris and clean Bar Holder.

  • Page 12: Maintenance

    OPTIONAL ACCESSORIES CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
