Carrier CRPWREXH008B00 Installation Instructions Manual

GENERAL
The accessory power exhaust package is used on the fol-
lowing units when these base units are fitted with economizers:
15 to 25 ton, standard-efficiency electric heat/electric cool and
gas heat/electric cool units; 12 to 20 ton, high-efficiency elec-
tric heat/electric cool and gas heat/electric cool units; and 13
and 15 ton, high-efficiency heat pump units. See Table 1.
The accessory will show a date code of 0903000001. Use this
accessory with 13 to 25 ton rooftop units with a serial
number of 3503Fxxxxx or later that are equipped with the
EconoMi$er+.
NOTE: This accessory is not compatible with the preassembled
horizontal supply transition accessory.
Table 1 — Accessory Power Exhaust Usage
UNIT VOLTAGE
208/230, 460 V (60 Hz)
575 V (60 Hz)
220 V, 400 V (50 Hz)
*Power exhaust motor is wired for 460 v.
PACKAGE CONTENTS
QUANTITY
1 Power exhaust with motor, control box, fan,
and fan grille
1 Conduit assembly
5 Electrical snap bushings
1
7 No. 10AB x / -in. lg screws
2
1 Center post
1 Insulated panel
3
2 No. 10-32 x / -in. machine screws
8
3 Wire nut connectors
INSTALLATION
1. Unpack accessory package. See Fig. 1.
2. Disconnect power to unit. Remove the control box
access panel, main control box cover, and alternate
return-air access panel (see Fig. 2). Using screws from
alternate return-air access panel, install center post and
insulated panel as shown in Fig. 3.
