About SG Series Firmware Updates
(Web Image Monitor)

TABLE OF CONTENTS

1. About Firmware Updates ......................................................................... 2
2. Operating Environment ............................................................................ 2
3. Disclaimer .................................................................................................. 2
4. Caution ........................................................................................................ 2
5. Firmware Update Operating Instructions ............................................... 3
6. Wireless LAN Update Operating Instructions ..................................... 10
7. Trademarks .............................................................................................. 21
1

Advertisement

loading

Related Manuals for Ricoh SG Series

Summary of Contents for Ricoh SG Series

  • Page 1: Table Of Contents

    About SG Series Firmware Updates (Web Image Monitor) TABLE OF CONTENTS 1. About Firmware Updates ................. 2 2. Operating Environment ................2 3. Disclaimer ....................2 4. Caution ......................2 5. Firmware Update Operating Instructions ..........3 6. Wireless LAN Update Operating Instructions ........10...

  • Page 2: About Firmware Updates

    1. About Firmware Updates This manual explains how to update the software for SG series network boards. 2. Operating Environment A Web browser is required for use. To use the Web browser, specify the TCP/IP protocols of your computer and the ma- chine.

  • Page 3: Firmware Update Operating Instructions

    5. Firmware Update Operating Instructions These instructions explain how to update the firmware of the machine. Before you start the update, make sure of the following: • The machine is in standby mode. • No applications are running on the computer. The following procedure uses Windows 7 screenshots.
  • Page 4 3. Click [Administrator Login]. CHU267 The following screen appears.
  • Page 5 4. Enter the login name and password, and then click [OK]. The default login name for administrators is "admin". No login password is set up. To ensure security, it is important you change the password. CHU282 5. In the menu area, click [Settings]. CHU268...
  • Page 6 6. Click [ROM Update]. CHU269 7. Select the update file (***.bin). Enter the path to the file in [Firmware File Name] or click [Browse...] and select the file. CHU279...
  • Page 7 8. Click [Update]. CHU280 Updating starts. When the update file transfer completes, the following message appears: The update takes a while. Do not operate the Web browser, computer, or the ma- chine while updating. The update progress appears on the machine's control pan-...
  • Page 8 9. Click [OK]. CHU277 The rebooting takes a while. Click [OK] after it reboots. The display returns to the ROM Update page. If DHCP has been enabled, the IP address might be updated, resulting in the Web browser not returning to the top page. If the top page does not appear, check the IP address using the machine's control panel and try connecting again.
  • Page 9 10. Check the current firmware version. CHU278 If it has been updated, the update has completed successfully. Otherwise, turn the power off and back on, and then try this procedure again from Step 1.

  • Page 10: Wireless Lan Update Operating Instructions

    6. Wireless LAN Update Operating Instructions These instructions explain how to update the wireless LAN of SG 3110DW. Before you start the update, make sure of the following: • The machine is in standby mode. • A wireless LAN connection is active. •...
  • Page 11 3. Click [Administrator Login]. CHU267 The following screen appears.
  • Page 12 4. Enter the login name and password, and then click [OK]. The default login name for administrators is "admin". No login password is set up. To ensure security, it is important you change the password. CHU282 5. In the menu area, click [Settings]. CHU268...
  • Page 13 6. Click [Wireless LAN Settings]. CHU283...
  • Page 14 7. Select the update file (***.bin). Enter the path to the file in [Firmware File Name] or click [Browse...] and select the file. CHU270...
  • Page 15 8. Click [Update]. CHU271 Updating starts.
  • Page 16 When the update file transfer completes, the following message appears: The update takes a while. Do not operate the Web browser, computer, or the ma- chine while updating. The update progress appears on the machine's control pan-...
  • Page 17 9. Click [OK]. CHU272 The rebooting takes a while. Click [OK] after it reboots. The display returns to the ROM Update page. If DHCP has been enabled, the IP address might be updated, resulting in the Web browser not returning to the top page. If the top page does not appear, check the IP address using the machine's control panel and try connecting again.
  • Page 18 11. Click [Cancel]. CHU284 12. Click [Home]. CHU274...
  • Page 19 13. Click [Device Info]. CHU275 14. Check the version in "Wireless LAN". CHU276 If it has been updated, the update has completed successfully.
  • Page 20 Otherwise, turn the power off and back on, and then try this procedure again from Step 1.

  • Page 21: Trademarks

    7. Trademarks Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and /or other countries. • The product names of Windows 7 are as follows: ® ® Microsoft Windows 7 Home Premium ® ®...
