About SG Series Firmware Updates
1. About Firmware Updates ......................................................................... 2
2. Operating Environment and Other Requirements ................................ 2
Operating Environment ..........................................................................................2
Supported Operating Systems ...............................................................................2
About Printer Drivers ..............................................................................................2
3. Update Cautions ....................................................................................... 3
Caution 1. ...............................................................................................................3
Caution 2. ...............................................................................................................3
Caution 3. ...............................................................................................................3
Caution 4. ...............................................................................................................3
Caution 5. ...............................................................................................................3
Caution 6. ...............................................................................................................4
Caution 7. ...............................................................................................................4
4. Disclaimer .................................................................................................. 5
5. Firmware Update Operating Instructions............................................... 6
Bidirectional-Enabled .............................................................................................7
Bidirectional-Disabled .......................................................................................... 11
6. Trademarks .............................................................................................. 15
(Windows)

TABLE OF CONTENTS

1

Advertisement

Table of Contents
loading

Related Manuals for Ricoh SG Series

Summary of Contents for Ricoh SG Series

  • Page 1: Table Of Contents

    About SG Series Firmware Updates (Windows) TABLE OF CONTENTS 1. About Firmware Updates ................. 2 2. Operating Environment and Other Requirements ........ 2 Operating Environment ..................2 Supported Operating Systems ................2 About Printer Drivers ....................2 3. Update Cautions ..................3 Caution 1........................3 Caution 2.

  • Page 2: About Firmware Updates

    1. About Firmware Updates Updates allow SG Series models to receive the latest firmware. 2. Operating Environment and Other Requirements Operating Environment If the machine is connected to computers by network peer-to-peer or directly via a sin- gle USB cable, successful updates are guaranteed.

  • Page 3: Update Cautions

    3. Update Cautions This section describes several things you must check for to ensure successful up- dates. You must read this section before performing updates. * For more details about cautions, refer to "ReadMe.txt". Caution 1. To update the firmware to version 2.0.0 or later, the current firmware must be version 1.9.0.

  • Page 4: Caution 6

    Caution 6. If you want to use the SmartDeviceMonitor port to update the firmware over a network, be sure to uncheck the [Use Extended Features] check box of SmartDeviceMonitor for Client. Caution 7. Bidirectional communication is not available it you are running SmartDeviceMonitor port under a 64-bit operating system.

  • Page 5: Disclaimer

    4. Disclaimer The manufacturer is not liable for any damages resulting from use or misuse of this software. Nor is the manufacturer liable for any damages resulting from use or misuse of this software with third parties.

  • Page 6: Firmware Update Operating Instructions

    5. Firmware Update Operating Instructions These instructions explain how to update the firmware of the machine. Before you start the update, make sure of the following: • The machine is in standby mode. • No applications are running on the computer. •...

  • Page 7: Bidirectional-Enabled

    Bidirectional-Enabled This section explains how to update the bidirectional-enabled printer driver. 1. Double-click [Product Name_VX.XX_g_upd.exe] to start the update. Product Name represents the machine name; VX.XX, the version. 2. Select [English], and then click [OK]. 3. The following screen appears. Check the displayed details, and then click [Next >].
  • Page 8 5. Check that the system version for [Update data] is later than the system ver- sion for [Printer], and then click [Next >]. The following screen is an example. The versions that actually appear may be dif- ferent. 6. Click [OK]. Do not switch the machine off while updating.
  • Page 9 7. Updating starts. 8. The machine is switched back on automatically.
  • Page 10 9. After updating, check the version, and then click [Finish]. The following screen is an example. The versions that actually appear may be dif- ferent. 10. Updating is complete.

  • Page 11: Bidirectional-Disabled

    Bidirectional-Disabled This section explains how to update the bidirectional-disabled printer driver. To update the firmware when bidirectional communication is disabled, see p.3 "Update Cautions", and then check the following: • You must be able to view the machine's control panel. The procedure requires you to check the machine's status on the control panel.
  • Page 12 3. The following screen appears. Check the displayed details, and then click [Next >]. 4. Select the machine name, and then click [Next >]. 5. After checking the following, click [OK]. • A functional machine has been selected. • The machine is not offline. •...
  • Page 13 6. Check that the message "Waiting for Data" is displayed on the machine’s control panel. Waiting for Data >>______________ 7. Click [OK]. * Check the control panel for the next step. 8. Updating starts. Check the update progress displayed on the LCD of the machine’s control panel. When the "Ready"...
  • Page 14 Update complete Power Off->On Ready |■| |■| |■| |■| |■| 9. After the update, check that the new firmware version is displayed. Use the following procedure to check the version of your machine. 1. Press the [ /Menu] key. 2. Press the [ ] or [ /Menu] key to display [List/Test Print], and then press the [#Enter] key.

  • Page 15: Trademarks

    6. Trademarks ® ® Adobe and Acrobat are either registered trademarks or trademarks of Adobe Sys- tems Incorporated in the United States and/or other countries. Pentium is a registered trademark of Intel Corporation. Netscape is a registered trademark of Netscape Communication Corporation in the U.S.
  • Page 16 • The product names of Windows Server 2008 R2 are as follows: ® ® Microsoft Windows Server 2008 R2 Standard ® ® Microsoft Windows Server 2008 R2 Enterprise • The product names of Windows Server 2012 are as follows: ® ®...
