78
LINK_O
79
WAKEUP
80
PW_RST#
74,75,77 NC
Power
5,20,36,
DVDD
55,72,90,
73
15,23,42,
DGND
58,63,81,
99,76
64M SDRAM (IC102)
O
Cable link status output. Active High.
This pin is also used as a strap pin to define the MII interface is reversed
MII interface (pull-high) or normal MII interface (not pull-high).
O
Issue a wake-up signal when wake-up event happens.
I
Hardware Reset
Active low signal to initiate the DM9000.
Not connect
Digital VCC
Digital GND
19
DN-V750/V755
