Thank you for buying a SNAPPER Product! Before operating your Z-RIDER, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power
equipment can be dangerous if used improperly.
accordance with the operating instructions and common sense!
COPYRIGHT © 1999
SNAPPER INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
MODEL NUMBER EXPLANATION
Z
F
22 – Engine Horse Power
25 – Engine Horse Power
52 – Mower Cutting Width
61 – Mower Cutting Width
OUT FRONT Z-RIDER
ZERO TURNING
22
00
POWER UNIT
00 – Series Designation
MOWER UNIT
00 – Series Designation
Also keep in mind that SAFETY requires careful use in
HYDRO DRIVE
SERIES 0
POWER UNIT MODELS
ZF2200K
ZF2500K
ZF2500KH
MOWER UNIT MODELS
ZF5200M
K
SERIES DESIGNATION
K – Kohler Engine
KH – Kohler Engine
M – Mower Deck
MANUAL No. 4-6480 (REV. 2, 8/20/99)
ZF6100M
ENGINE TYPE
ENGINE HP

Advertisement

Table of Contents
loading

Related Manuals for Snapper ZF2200K, ZF2500K, ZF2500KH, ZF5200M, ZF6100M

Summary of Contents for Snapper ZF2200K, ZF2500K, ZF2500KH, ZF5200M, ZF6100M

  • Page 1 Z – Zero Turning – Hydro Drive F – Out Front Mower Thank you for buying a SNAPPER Product! Before operating your Z-RIDER, read this manual carefully and pay particular attention to the “IMPORTANT SAFETY INSTRUCTIONS” on Pages 2 & 3. Remember that all power equipment can be dangerous if used improperly.

  • Page 2: Section 1 - Important Safety Instructions

    If you have any questions pertaining to your machine which your dealer cannot answer to your satisfaction, call or write the Customer Service Department at SNAPPER, McDonough, Georgia 30253. Phone: (1-800-935-2967).

  • Page 3: Section 1 - Important Safety Instructions

    14. Have machine serviced by an authorized SNAPPER dealer at least once a year and have the dealer install any new safety devices. 15. Use only genuine SNAPPER replacement parts...

  • Page 4: Table Of Contents

    These structures, when installed and used properly can offer additional security to the operator against serious injury in the event of a tip over accident. Operator Protective Structures may be required by local ordinances. Discuss your mowing application and ordinances with your local Snapper Dealer. IMPORTANT...

  • Page 5: Section 1 - Familiarization

    FIGURE 1.1 1.2 NOMENCLATURE The nomenclature information above, Figure 1.1, shows the essential parts of the SNAPPER OUT FRONT Z- RIDER. It is recommended that all operator’s of this equipment become thoroughly familiar with the controls, components, and operation of this machine before operating.

  • Page 6: Section 2 - Operating Instructions

    Section 2 - OPERATING INSTRUCTIONS 2.1 PRE-START CHECK LIST Make the following checks and perform the service required before each start-up. 2.1.1. Check tires and add or release air as needed to bring pressure in drive tires to: 12 psi (Turf Type Tires), 5 psi (All Terrain Type Tires) and 25 psi in rear caster tire.

  • Page 7: Starting & Stopping Engine, Blades & Parking Brake

    Section 2 - OPERATING INSTRUCTIONS 2.2 STARTING & STOPPING – ENGINE, BLADES & PARKING BRAKE This machine is equipped with dual hydrostatic wheel drive transmissions. Each transmission is controlled by a single motion control lever or joystick. This single control lever (joystick) controls the direction of motion, Forward and Reverse, and the speed of motion.

  • Page 8: Starting & Stopping Mower Blades

    7 seconds, the electric clutch should be checked. Replacement of electric clutch may be necessary. Return the machine to an authorized Snapper dealer for replacement. DO NOT CONTINUE to operate mower if blades fail to stop in 7 seconds. WARNING DO NOT park the machine on slopes.

  • Page 9: Driving & Stopping Machine

    Section 2 - OPERATING INSTRUCTIONS 2.3 OPERATION – MOTION CONTROL 2.3.1 DRIVING MACHINE IMPORTANT: The joystick lever has to be manually moved to propel machine. Always return the joystick with hand assistance to the neutral position to stop machine. Release the joystick and it will gradually return toward the neutral position.

  • Page 10: Section 3 - Maintenance Instructions

    Section 3 – MAINTENANCE 3.1 INTRODUCTION To retain the quality of the SNAPPER Out Front Z- Rider, use genuine SNAPPER replacement parts only. Contact a local SNAPPER dealer for parts and service assistance. information for a particular SNAPPER Out Front Z- Rider, always mention the model and serial number.

  • Page 11: Check Mower Drive Belt

    Section 3 – MAINTENANCE 3.2.3. CHECK MOWER DRIVE BELT 1. Drive Belt Cover Removal a. Lower deck to lowest setting. b. Remove four knobs that secure the deck cover. See Figure 3.3. c. Remove cover to gain access to deck belt.

  • Page 12: Front Wheel Bearings Lubrication

    Reinstall reservoir cap. See Figure 3.6. IMPORTANT: DO NOT remove or service the transaxle fluid filters. This service should be made periodically by an authorized SNAPPER dealer. See the service schedule to determine the recommended change interval. OIL FILL...

  • Page 13: Fuel Filter Replacement

    Section 3 – MAINTENANCE 3.5 ANNUALLY (END OF EACH SEASON) (Continued from previous Page) 3.5.2. FUEL FILTER Service fuel filter as instructed below. Turn key to “OFF” position. Engine MUST be stopped and MUST be cold before removing filter. Clamp fuel line to prevent fuel spillage or perform filter change when fuel tank and fuel line are empty.

  • Page 14: Section 4 - Adjustments And Repair

    However, if there is difficulty in making these adjustments and repairs, it is recommended that these repairs be made by an authorized SNAPPER dealer. 4.2.1. MOWER DECK ADJUSTMENT (LEVELNESS) SIDE to SIDE and FRONT to REAR...

  • Page 15: Parking Brake Adjustment

    CASTER WHEEL BRACKET PARKING BRAKE LEVER 4.4 ENGINE ADJUSTMENTS & REPAIR Refer to the engine owner’s manual for engine adjustments and/or repairs. your authorized Snapper dealer WARNING ROTATE ROD CLOCKWISE TO TIGHTEN BRAKE PARKING BRAKE ROD FIGURE 4.4...

  • Page 16: Mower Blade Replacement

    Section 4 - ADJUSTMENTS & REPAIR 4.5 MOWER BLADE REPAIR/REPLACEMENT 4.5.1. BLADE WEAR LIMITS 1. Inspect blade frequently for signs of excessive wear or damage. See Figure 4.5. NEW BLADE DANGEROUS CONDITION! DO NOT USE ON MOWER! REPLACE WITH NEW BLADE. FIGURE 4.5 WARNING DO NOT use a cutting blade that shows signs of...

  • Page 17: Battery Removal

    Section 4 - ADJUSTMENTS & REPAIR 4.6.2. ENGINE BELT REPLACEMENT 1. Route belt around blade pulleys and idler pulley in same the position as old belt was removed. It may be necessary to use a pry bar to pull idler pulley back to install belt. See Figure 4.8.

  • Page 18: Battery Testing

    Section 4 - ADJUSTMENTS & REPAIR 4.7.4. BATTERY TESTING There are two types of battery tests: Unloaded and Loaded. The unloaded test is the procedure that will be discussed. It’s the simplest and most commonly used. An unloaded test is made on a battery without discharging current.

  • Page 19: Mower Spindles (Field Serviceable Spindles) Bearing Replacement

    SPINDLES (Field Spindles) BEARING REPLACEMENT In the event that a spindle bearing requires replacement, the SNAPPER Field Serviceable Spindles have been designed so that no special tools or presses are required. 1. Remove belt. Loosen blade nut and remove. Allow blade bolt, washer, blade and four spacers to drop down out of the spindle housing.

  • Page 20: Troubleshooting

    CORRECTIVE ACTION 1. Service battery. 2. Replace fuse. 3. Clean and check connections for good contact. 4. Contact authorized SNAPPER dealer. 1. Move blade engagement switch to “OFF”. 2. Set park brake. 3. Fill fuel tank with fresh fuel. 4. Move choke control to “CHOKE” position.

  • Page 21: Troubleshooting

    5. Replace traction drive belt. 1. Move blade switch to the “ON” position. 2. Replace clutch belt. 3. Replace mower belt. 4. Contact authorized SNAPPER dealer. 5. Contact authorized SNAPPER dealer. 6. Connect power transfer shaft or repair damage. 1. Bring to proper pressure.

  • Page 22: Service Schedule

    ITEM SERVICE PERFORMED Check Oil Level Engine Oil Initial Oil Change Periodic Oil Change Clean Sponge Element Air Pre-Cleaner Clean or Replace Air Cleaner Replace Spark Plug Replace Fuel Filter Engine Cooling Clean Shroud & Fins System Check Electrolyte Battery Charge Battery Testing Battery Check Pressures...

  • Page 23: Warranty

    For two (2) years from purchase date for the original purchaser's use, SNAPPER, through any authorized SNAPPER dealer will replace, free of charge (except for taxes where applicable), any part or parts found upon examination by the factory at McDonough, Georgia, to be defective in material or workmanship or both.

  • Page 24: Primary Maintenance

    PRIMARY MAINTENANCE...
  • Page 25 PRIMARY MAINTENANCE...
  • Page 26 PRIMARY MAINTENANCE...

  • Page 27: Primary Maintenance

    PRIMARY MAINTENANCE...

  • Page 28: Important

    Read, Understand, and Follow all warnings and instructions in this manual, the engine manual, and on the machine, engine and attachments. If you have any questions about your Snapper product, contact your local authorized Snapper dealer or contact Snapper Customer Service at Snapper, McDonough, GA.
