Snapper S200X/72 Operator's Manual

S200x series zero-turn riding mower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model Number:
5900664
5900692
5900695
5900693
5900694
Briggs & Stratton Yard Power Products Group
5375 North Main Street
Munnsville, NY 13409
800-933-6175
OPERATOR'S
MANUAL
S200X Series
Zero-Turn Riding Mower
Description
S200XKAV2561, 25HP Kawasaki, 61" Cut Zero-Turn Riding Mower
S200XKOH2761, 27HP Kohler, 61" Cut Zero-Turn Riding Mower
S200XKAV2761, 27HP Kawasaki, 61" Cut Zero-Turn Riding Mower
S200XBV32, 32HP Briggs & Stratton Zero-Turn Riding Mower
S200X/72, 72" Mower Deck
5101090
Revision C
Rev. Date: 9/2007
TP 100-7332-C-M2-SP

Advertisement

Table of Contents
loading

Related Manuals for Snapper S200X/72

Summary of Contents for Snapper S200X/72

  • Page 1 S200XKAV2561, 25HP Kawasaki, 61” Cut Zero-Turn Riding Mower S200XKOH2761, 27HP Kohler, 61” Cut Zero-Turn Riding Mower S200XKAV2761, 27HP Kawasaki, 61” Cut Zero-Turn Riding Mower S200XBV32, 32HP Briggs & Stratton Zero-Turn Riding Mower S200X/72, 72” Mower Deck 5101090 Revision C Rev. Date: 9/2007...
  • Page 2 Snapper Pro product. We’re pleased that you’ve placed your confidence in the Snapper Pro brand. When operated and maintained according to the instructions in this manual, your Snapper Pro product will provide many years of dependable service.

  • Page 3: Table Of Contents

    Table of Contents Operator Safety ...2 Safety Rules and Information ...2 Safety Decals ...11 Safety Interlock System...12 Features & Controls ...13 Identification Numbers ...13 Control Functions ...14 Operation ...16 General ...16 Checks Before Starting ...16 Checking Tire Pressures ...17 Seat Adjustment ...17 Mowing Height Adjustment ...18 Foot Pedal Adjustment...18 Raise and Lower the Roll Bar ...19...

  • Page 4: Operator Safety

    Operator Safety Operator Safety Safety Rules and Information READ THE MANUAL The operator’s manual contains important safety information you need to be aware of BEFORE you operate your unit as well as DURING operation. Safe operating techniques, an explanation of the product’s features and controls, and maintenance information is included to help you get the most out of your equipment investment.
  • Page 5 THROWN OBJECTS This unit has spinning mower blades. These blades can pick up and throw debris that could seriously injure a bystander. Be sure to clean up the area to be mowed and remove objects that could be thrown by the blade BEFORE you start mowing.
  • Page 6 Operator Safety RETAINING WALLS, DROP-OFFS, AND WATER Retaining walls and drop-offs around steps and water are a common hazard. Give yourself a minimum of two mower widths of clearance around these hazards and hand-trim with a walk behind mower or string trimmer. Wheels dropping over retaining walls, edges, ditches, embankments, or into water can cause rollovers, which may result in serious injury, death, or drowning.
  • Page 7 ENCLOSED AREAS Only operate this unit outdoors and away from unventilated areas such as inside garages or enclosed trailers. The engine emits poisonous carbon monoxide gas and prolonged exposure in an enclosed area can result in serious injury or death. Operator Safety FUEL AND MAINTENANCE Always disengage all drives, shutoff the engine, and remove the...
  • Page 8 Operator Safety Read these safety rules and follow them closely. Failure to obey these rules could result in loss of control of unit, severe personal injury or death to you, or bystanders, or damage to property or equipment. This mowing deck is capable of amputating hands and feet and throwing objects.
  • Page 9 spark arrester. It is a violation of California Public Resource Code Section 4442 to use or operate the engine on or near any forest-covered, brush-covered, or grass-covered land unless the exhaust system is equipped with a spark arrester meeting any applicable local or state laws.
  • Page 10 Operator Safety SERVICE AND MAINTENANCE To avoid personal injury or property damage, use extreme care in handling gasoline. Gasoline is extremely flammable and the vapors are explosive. Safe Handling of Gasoline 1. Extinguish all cigarettes, cigars, pipes, and other sources of ignition. 2.
  • Page 11 27. Models equipped with an engine radiator: WARNING: Stored energy device. To prevent serious bodily injury from hot coolant or steam blow-out, never attempt to remove the radiator cap while the engine is running. Stop the engine and wait until it is cool. Even then, use extreme care when removing the cap.
  • Page 12 Operator Safety WARNING Failure to properly inspect and maintain the seat belt can cause serious injury or death. INSPECTION AND MAINTENANCE OF THE ROLL BAR SEAT BELT • The seat belt like the ROLL BAR, needs to be periodically inspected to verify that the integrity has not been compromised through normal machine use, misuse, age degradation, modifications, or a roll over.

  • Page 13: Safety Decals

    Safety Decals This unit has been designed and manufactured to provide you with the safety and reliability you would expect from an industry leader in outdoor power equipment manufacturing. Although reading this manual and the safety instructions it contains will provide you with the necessary basic knowledge to operate this equipment safely and effectively, we have placed several safety labels on the unit to remind you of this important information while you are operating...

  • Page 14: Safety Interlock System

    Operator Safety Safety Interlock System This unit is equipped with safety interlock switches. These safety systems are present for your safety, do not attempt to bypass safety switches, and never tamper with safety devices. Check their operation regularly. Operational SAFETY Checks Test 1 —...

  • Page 15: Features & Controls

    Features and Controls Identification Numbers When contacting your authorized dealer for replacement parts, service, or information you MUST have these numbers. Record your part number, serial number and engine serial numbers in the space provided on the inside front cover for easy access.

  • Page 16: Control Functions

    Features and Controls Figure 2. Control Locations Control Functions The information below briefly describes the function of individual controls. Starting, stopping, driving, and mowing require the combined use of several controls applied in specific sequences. To learn what combination and sequence of controls to use for various tasks see the OPERATION section.
  • Page 17 Parking Brake DISENGAGE Releases the parking brake. ENGAGE Locks the parking brake. Pull the parking brake lever back to engage the parking brake. Move the lever fully forward to disengage the parking brake. NOTE: To start the unit the parking brake must be engaged.

  • Page 18: Operation

    Operation Operation General Operating Safety Before first time operation: • Be sure to read all information in the Safety and Operation sections before attempting to operate this tractor and mower. • Become familiar with all of the controls and how to stop the unit.

  • Page 19: Checking Tire Pressures

    Check Tire Pressures Tire pressure should be checked periodically, and maintained at the levels shown in the chart. Note that these pressures may differ slightly from the “Max Inflation” stamped on the side-wall of the tires. The pressures shown provide proper traction, improve cut quality, and extend tire life.

  • Page 20: Mowing Height Adjustment

    Operation Mowing Height Adjustment The cutting height adjustment pin (A, Figure 6) control the mower cutting height. The cutting height is adjustable between 1-3/4” (4,4 cm) and 5” (12,7 cm) in 1/4” (0,64 cm) increments. 1. Depress the deck lift foot pedal (B) until it locks into the 5”...

  • Page 21: Raise And Lower The Roll Bar

    Raise and Lower the Roll Bar WARNING AVOID SERIOUS INJURY OR DEATH FROM ROLL OVER: Keep roll bar in the raised position and use the seat belt. THERE IS NO ROLL OVER PROTECTION WHEN THE ROLL BAR IS DOWN Lower the roll bar only when necessary and NEVER remove it.

  • Page 22: Starting The Engine

    Operation Starting the Engine WARNING If you do not understand how a specific control functions, or have not yet thoroughly read the FEATURES & CONTROLS section, do so now. Do NOT attempt to operate the tractor without first becoming familiar with the location and function of ALL controls.

  • Page 23: Zero Turn Driving Practice

    Zero Turn Driving Practice The lever controls of the Zero Turn rider are responsive, and learning to gain a smooth and efficient control of the rider’s forward, reverse, and turning movements will take some practice. Spending some time going through the maneuvers shown and becoming familiar with how the unit accelerates, travels, and steers —...
  • Page 24 Operation Practice Turning Around a Corner While traveling forward allow one handle to gradually return back toward neutral. Repeat several times. NOTE: To prevent pivoting directly on the tire tread, it is best to keep both wheels going at least slightly forward. Executing Turns Figure 13.

  • Page 25: Mowing

    Mowing 1. Engage the parking brake. Make sure the PTO switch is disengaged, the motion control levers are locked in the NEUTRAL position and the operator is on the seat. 2. Start the engine (see Starting The Engine ). 3. Set the mower cutting height (see Mowing Height Adjustment ).

  • Page 26: Mowing Methods

    Operation When and How Often to Mow The time of day and condition of the grass greatly affect the results you’ll get when mowing. For the best results, follow these guidelines: 1. Mow when the grass is between three and five inches high.

  • Page 27: Attaching A Trailer

    Proper Mulching Mulching consists of a mower deck which cuts and recuts clippings into tiny particles and which then blows them down INTO the lawn. These tiny particles decompose rapidly into by-products your lawn can use. UNDER PROPER CONDITIONS, your mulching mower will virtually eliminate noticeable clippings on the lawn surface.

  • Page 28: Regular Maintenance

    Regular Maintenance Regular Maintenance Maintenance Schedule The following schedule should be followed for normal care of your rider and mower. You will need to keep a record of your operating time. Determining operating time is easily accomplished by observing the elapsed time recorded by the hour meter. Safety Items Check Safety Interlock System Check Rider Brakes...

  • Page 29: Checking/Adding Fuel

    Checking / Adding Fuel To add fuel: 1. Remove the fuel cap. 2. Fill the tank to about 1-1/2” (3,81 cm) of the bottom of the filler neck. This will allow for fuel expansion. NOTE: Do not overfill. Refer to your engine manual for specific fuel recommendations.

  • Page 30: Lubrication

    Regular Maintenance Lubrication Lubricate the unit at the locations shown in Figures 21 through 24 as well as the following lubrication points. Grease: • front caster wheel axles & yokes • deck lift pivot blocks • mower deck spindles • mower deck idler arm Use grease fittings when present.

  • Page 31: Check Hydraulic Oil Level

    Check Hydraulic Oil Level 1. Before removing the reservoir cap, make sure the area around the reservoir cap and fill neck of the reservoir is free of dust, dirt, or other debris. 2. Unscrew the reservoir cap (B, Figure 25). 3.

  • Page 32: Servicing The Mower Blades

    Regular Maintenance Servicing The Mower Blades Removing the Mower Blade CAUTION Avoid injury! Mower blades are sharp. • Always wear gloves when handling mower blades or working near blades. 1. To remove the mower blade, use a 1” wrench on the flats of the spindle shaft and remove the mower blade mounting bolt with a 15/16”...
  • Page 33 Sharpening the Mower Blade CAUTION Avoid injury! Mower blades are sharp. • Always wear gloves when handling the mower blades. • Always wear safety eye protection when grinding. 1. Sharpen the mower blades with grinder, hand file, or electric blade sharpener. 2.

  • Page 34: Ground Speed Control Lever Adjustment

    Regular Maintenance Ground Speed Control Lever Adjustment The control levers can be adjusted in three ways. The alignment of the control levers, the placement of the levers (how close the ends are to one another) and the height of the levers can be adjusted. To Adjust the Handle Alignment Loosen the mount bolts (A, Figure 33) and pivot the lever(s) (B) to align with each other.

  • Page 35: Neutral Adjustment

    Do not adjust the spring to be shorter than 1-15/16” (4,9 cm) when compressed. This may damage the brake mechanism. If this does not correct the braking problem, see your Snapper Pro dealer. Regular Maintenance Figure 35. Neutral Adjustment (LH side shown) A.

  • Page 36: Return To Neutral Adjustment

    Regular Maintenance Return-To-Neutral Adjustment To determine if it is necessary to adjust the neutral return, perform the following steps. 1. Disengage the PTO, engage the parking brake and turn off the engine. 2. Move the ground speed control levers into the operating position, pull levers rearward and release.

  • Page 37: Deck Rod Timing Adjustment

    Deck Rod Timing Adjustment 1. Park the machine on a flat, level surface. Disengage the PTO, engage the parking brake, turn off the engine, and remove the ignition key. Rear tires must be inflated to 15 psi (1,03 bar); front tires to 25 psi (1,72 bar). 2.

  • Page 38: Mower Belt Replacement

    Regular Maintenance Mower Belt Replacement NOTICE To avoid damaging belts, DO NOT PRY BELTS OVER PULLEYS. 1. Park the tractor on a smooth, level surface such as a concrete floor. Disengage the PTO, engage the parking brake, turn off the engine, and remove the ignition key. 2.

  • Page 39: Hydraulic Pump Drive Belt Replacement

    Hydraulic Pump Drive Belt Replacement 1. Park the tractor on a smooth, level surface such as a concrete floor. Disengage the PTO, engage the parking brake, turn off the engine, and remove the ignition key. 2. Remove the PTO drive belt (see MOWER BELT REPLACEMENT for removal instructions).

  • Page 40: Battery Maintenance

    Regular Maintenance Battery Maintenance NOTE: This unit is equipped with a maintenance-free BCIU1 battery. Cleaning the Battery and Cables WARNING Be careful when handling the battery. Avoid spilling electrolyte. Keep flames and sparks away from the battery. When removing or installing battery cables, disconnect the negative cable FIRST and reconnect it LAST.

  • Page 41: Battery Service

    Battery Service Checking Battery Voltage WARNING Keep open flames and sparks away from the battery; the gasses coming from it are highly explosive. Ventilate the battery well during charging. A voltmeter can be used to determine condition of battery. When engine is off, the voltmeter shows battery voltage, which should be 12 volts.
  • Page 42 Regular Maintenance THIS HOOK-UP FOR NEGATIVE GROUND VEHICLES Starter Switch Starting Vehicle Battery To Ground MAKE CERTAIN VEHICLES DO NOT TOUCH Figure 46. Jump Starting WARNING Any procedure other than the preceding could result in: (1) personal injury caused by electrolyte squirting out the battery vents, (2) personal injury or property damage due to battery explosion,...

  • Page 43: Storage

    Storage Temporary Storage (30 Days Or Less) Remember, the fuel tank will still contain some gasoline, so never store the unit indoors or in any other area where fuel vapor could travel to any ignition source. Fuel vapor is also toxic if inhaled, so never store the unit in any structure used for human or animal habitation.

  • Page 44: Troubleshooting

    Troubleshooting Troubleshooting Troubleshooting Chart While normal care and regular maintenance will extend the life of your equipment, prolonged or constant use may eventually require that service be performed to allow it to continue operating properly. The troubleshooting guide below lists the most common problems, their causes and remedies.

  • Page 45: Troubleshooting The Mower

    Rider Troubleshooting Continued. Problem Engine runs, but rider will not drive. Rider drive belt slips. Brake will not hold. Rider steers or handles poorly. Troubleshooting the Mower Problem Mower will not raise. Engine stalls easily with mower engaged. Excessive mower vibration. Excessive belt wear or breakage.

  • Page 46: Troubleshooting Common Cutting Problems

    Troubleshooting Troubleshooting Common Cutting Problems Problem Streaking. Scalping. Stepped Cutting. Uneven Cutting. Stingers. Cause Blades are not sharp. Blades are worn down to far. Engine speed is too slow. Ground speed is too fast. Deck is plugged with grass Not overlapping cutting rows enough.

  • Page 47: Specifications

    Specifications NOTE: Specifications are correct at time of printing and are subject to change without notice. *Actual sustained equipment horsepower will likely be lower due to operating limitations and environmental factors. ENGINE: 25 HP Kawasaki Make Kawasaki Model FH721V Horsepower 25 @ 3600 rpm Displacement 41.2 Cu.
  • Page 48 Ferris Industries - a division of Simplicity Manufacturing Inc. Thank you for purchasing Ferris commercial mowing equipment. Please take a few minutes to read this limited warranty information. It contains all the information you will need to have your Ferris mower repaired in the unlikely event that a breakdown covered by this limited warranty should occur. Owner's Responsibilities - As a condition to our obligations under this limited warranty, you shall have read the operator's manual and you shall have completed and submitted to Ferris, within 20 days from the date of purchase, the Ferris Product Registration.

  • Page 49: Product Specifications

    Product Specifications: ENGINE: 25 HP Kawasaki Make Kawasaki Model FH721V Oil Capacity 2.0 US pt. ( 1.9 L) w/ Filter 27 HP Kohler Make Kohler Model CV740S Oil Capacity 2.2 pt. (2.0 L) w/ Filter 27 HP Kawasaki Make Kawasaki Model FX751V Oil Capacity...

This manual is also suitable for:

S200xbv32S200xkav2561S200xkav2761S200xkoh2761
