- Page 1 Parts Manual for 22" STEEL DECK WALK BEHIND MOWERS MODEL NS2265 (7800228) NSP2265 (7800229) S2265 (7800189) SP2265 (7800165) Briggs & Stratton Yard Power Products Group 535 Macon Road Manual No. 7006258 McDonough, GA, 30253 U.S.A. 800-935-2967 Revision IR, 4/7/2008 TP 400-5393-IR-WB-N...
-
Page 3: Table Of Contents
PAGE GROUP Handles & Controls (Push) Handles & Controls (Self-Propelled) Deck Assembly (Push) Deck Assemby (Self-Propelled) Height-of-Cut Assemblies Engine, Blade & Front Cover Decals 22" STEEL DECK WALK BEHIND MOWERS Table Of Contents Manual No. 7006258 TP 400-5393-IR-WB-N... -
Page 4: Handles & Controls (Push)
Handles & Controls (Push) Manual No. 7006258 22" STEEL DECK WALK BEHIND MOWERS TP 400-5393-IR-WB-N... - Page 5 Handles & Controls (Push) Item Part No Description 7101405 UPPER HANDLE, Plastic, Snapper Push 7101321 BAIL, Plastic Handle, WBM 7090015 BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2, YZ 2860694 NUT, 1/4-20, Hex Flange (Esna) YZ 7300649 HANDLE, Connecting, 21”/22” WBM...
-
Page 6: Handles & Controls (Self-Propelled)
Handles & Controls (Self-Propelled) Manual No. 7006258 22" STEEL DECK WALK BEHIND MOWERS TP 400-5393-IR-WB-N... - Page 7 Handles & Controls (Self-Propelled) Item Part No Description 7101312 UPPER HANDLE, Plastic, WBM 7101417 ASSY, Control Head, 22” WBM, Single Speed 7101321 BAIL, Plastic Handle, WBM 7090015 BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2, YZ 2860694 NUT, 1/4-20, Hex Flange (Nyloc) YZ 7300670 PLATE, Control Panel 7100225...
-
Page 8: Deck Assembly (Push)
Deck Assembly (Push) Manual No. 7006258 22" STEEL DECK WALK BEHIND MOWERS TP 400-5393-IR-WB-N... - Page 9 Deck Assembly (Push) Item Part No Description 7300401 DECK, 22” Walk 722848 SCREW, 1/4-20 x 11/16” Pan Head Self-Tap (Torx) 7091020 PUSHNUT, 1/4” 726768 BRACKET, Chute 726766 PLATE, Mulch, 22” RB Scott's 722507 SPRING, Chute (Torsion) 7101067 ROD, Pivot (1/4” Dia. x 5.55”) 721682 COVER, Mulch, Plastic, Black 721681...
-
Page 10: Deck Assemby (Self-Propelled)
Deck Assemby (Self-Propelled) Manual No. 7006258 22" STEEL DECK WALK BEHIND MOWERS TP 400-5393-IR-WB-N... - Page 11 Deck Assemby (Self-Propelled) Item Part No Description 7300400 DECK, 22” Walk, 3 N 1 722848 SCREW, 1/4-20 x 11/16” Pan Head Self-Tap (Torx) 7091020 PUSHNUT 1/4” 726768 BRACKET, Chute 726766 PLATE, Mulch, 22” RB Scott's 722507 SPRING, Chute (Torsion) 7101067 ROD, Pivot (1/4”...
- Page 12 Deck Assemby (Self-Propelled) Manual No. 7006258 22" STEEL DECK WALK BEHIND MOWERS TP 400-5393-IR-WB-N...
- Page 13 Deck Assemby (Self-Propelled) Item Part No Description 7300440 BAFFLE, Front, 22” WBM 722410 SPRING, Compression Footnotes: Note: * This assembly is also shown on Height-of-Cut Assemblies page. 22" STEEL DECK WALK BEHIND MOWERS Note Manual No. 7006258 TP 400-5393-IR-WB-N...
-
Page 14: Height-Of-Cut Assemblies
Height-of-Cut Assemblies Manual No. 7006258 22" STEEL DECK WALK BEHIND MOWERS TP 400-5393-IR-WB-N... - Page 15 Height-of-Cut Assemblies Item Part No Description 7501056 * ASSY, Height-Of-Cut, Right Rear, 22” WBM, Push & Propelled 7501055 * ASSY, Height-Of-Cut, Left Rear, 22” WBM, Push & Propelled 7501057 * ASSY, Height-Of-Cut, RF, 22” WBM, Propelled 7501058 * ASSY, Height-Of-Cut, LF, 22” WBM, Propelled 7501073 * ASSY, Height-Of-Cut, Right Front, 22”...
-
Page 16: Engine, Blade & Front Cover
Engine, Blade & Front Cover Manual No. 7006258 22" STEEL DECK WALK BEHIND MOWERS TP 400-5393-IR-WB-N... - Page 17 NOTE: * Purchase engine parts from engine manufacturer dealer. Note: ** Part number appears on belt 22" STEEL DECK WALK BEHIND MOWERS Note used on S2265 & SP2265 used on NS2265 & NSP2265 includes 7101209 (spacer) & 7101448 (3) (bushings) used on SP2265 Manual No.
-
Page 18: Decals
Decals Manual No. 7006258 22" STEEL DECK WALK BEHIND MOWERS TP 400-5393-IR-WB-N... - Page 19 Decals Item Part No Description 7101537 DECAL, Front Cover, 22” Snapper, Push 7101538 DECAL, Front Cover, 22” Snapper, Single Speed 7101429 DECAL, Control Head, MY 08 7100984 DECAL, Warning/Danger WBM 7013010 DECAL, Danger, Cut Finger 7029782 DECAL, OPC Bail International Symbol...
- Page 22 IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED Briggs & Stratton Yard Power Products Group 535 Macon Road McDonough, GA, 30253 U.S.A. 800-935-2967 www.snapper.com Copyright © 2008 Briggs & Stratton Corporation Milwaukee, WI USA. All Rights Reserved Manual No. 7006258...
