Snapper R195517B Safety Instructions & Operator's Manual

19” steel deck walk mowers series 17
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL DESIGNATION
CUTTING WIDTH
R – Recycling Model
Thank you for buying a SNAPPER Product! Before operating your Walk Behind, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power
equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance
with the operating instructions and common sense.
COPYRIGHT © 2002
SNAPPER INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
MODEL NUMBER EXPLANATION
R
19
19 – 19" Cutting Width
B – Briggs & Stratton Engine
19" STEEL DECK
WALK MOWERS
55
17
55 – 5.5 HP (Engine Horse Power)
SERIES 17
MODEL
R195517B
B
ENGINE TYPE
SERIES DESIGNATION
ENGINE HORSE POWER
17 - Series Designation
MANUAL No. 7-5107 (I.R. 6/21/02)
