MODEL DESIGNATION
CUTTING WIDTH
R – Recycling Model
19 – 19" Cutting Width
Thank you for buying a SNAPPER Product! Before operating your Walk Behind, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power
equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance
with the operating instructions and common sense.
NOTE: Specifications are correct at time of printing and are subject to change without notice.
* Actual sustained engine power will likely be lower due to operating limitations and environmental factors. Please refer to 'Engine Power Rating
Information' on Page 4 for further information.
BRIGGS & STRATTON YARD POWER PRODUCTS GROUP
COPYRIGHT © 2007, BRIGGS & STRATTON CORPORATION
MILWAUKEE, WI, USA. ALL RIGHTS RESERVED.
Safety Instructions & Operator's Manual for
MODEL NUMBER EXPLANATION
R
19
625 – 6.25 (Engine Power *)
19 – Series Designation
19" STEEL DECK
WALK MOWERS
625
19
B
MANUAL No. 7101292 (I.R. 1/26/2007)
SERIES 19
MODEL
R1962519B
ENGINE TYPE
SERIES DESIGNATION
ENGINE POWER *
B – Briggs & Stratton Engine
TP 100-5255-IR-WB-N
