Page 1 2019-03 0.2 USER MANUAL...
Page 3 DECLARATION OF CONFORMITY The manufacturer Neatech.it Via A. de Curtis 4/A, 80040, Cercola (NA), Italy declares that the wheelchair EVO 1 (reference code: S045) other names: EVO-1, EVO 1, EVO-1 FWD, EVO-1 RWD, EVO 1 FWD, EVO 1 RWD, PEGASUS EVO 1 satisfies the requirements laid down by the European Directive 93/42;...
Page 4: Table Of Contents
Index PRODUCT INFORMATION ....................... 1 PREPARATION FOR FIRST USE ....................2 Checks to be made on delivery ..................2 Unpacking ........................2 Software description ....................... 3 ADJUSTMENTS ........................4 List of adjustments ......................4 Seat depth ........................5 Backrest angle ........................7 3.3.1 Adjunctive backrest angle adjustment ..............
Page 5 Main switch ........................56 Battery charging ......................57 Transport and storage ....................59 MAINTENANCE ........................60 Maintenance and cleaning .................... 60 Controls to be performed on the product..............61 Tire puncture ......................... 62 5.3.1 User information ....................62 Wiring diagram ......................67 5.4.1 Rnet .........................
Page 6 5.6.20 Sidepad ......................... 112 5.6.21 Legrest support ..................... 113 5.6.22 Lever for angle adjustable legrest ................ 116 5.6.23 Calf support ......................118 SPECIFICATIONS ........................121 Maximum user weight ....................122 Other provided information ..................123 Dimensions ........................125 WARRANTY TERMS ......................126 Serial number ......................
Page 7 Symbols in this manual WARNING This symbol means presence of danger for the user or damage for the product. Always follow instructions when this symbol is present. PINCH HAZARD This symbol means presence of pinch hazard. ELECTRICAL WARNING This symbol means presence of danger related to the presence of electrical energy.
Page 8 TEMPERATURE The temperature of some surfaces may increase when the product is exposed to external heat sources as direct sunlight. TIPPING HAZARD Tipping hazard is strongly reduced because of the design of the product according to EN 12182. In any case, please pay special attention during the adjustments and use of the product to prevent any damage to the user or product itself.
Page 9 ELECTROMAGNETIC RADIATION DANGER The behavior of the wheelchair while driving may be affected by electromagnetic fields created by transceivers such as: Citizens band (CB) radios, walkie-talkies, fire and police radios, cellular phones, lap-top computers, commercial radio and television broadcast antennas. PLEASE USE CAUTION in the presence of these devices.
Page 10 Service manual is intended for technical personnel to maintain and repair wheelchairs. It is important to follow the instructions contained in this manual in order to professionally work with the product. The qualified personnel who works with wheelchairs must comply with all provisions of occupational safety and common sense in order to preserve his own safety.
Page 11 MANUFACTURER For any need not expressly explained in this manual, please contact the manufacturer. Neatech.it SRL via A. de Curtis 4/A, 80040, Cercola (NA), Italy www.neatech.it –...
Page 12: Product Information
MAX 150 kg Seat width MIN 300 mm – MAX 460 mm Batteries 2x 12 V 35 Ah / 2x 12 V 50 Ah Charger Power module VR2 60 A / Rnet 80 A Motors 2x 220 W www.neatech.it 1/126...
Page 13: Preparation For First Use
The wheelchair is delivered already mounted and ready to use. Before starting to use the wheelchair please check if all described components are present. If not, please contact as soon as possible the vendor. PACKAGING DISPOSAL To properly recycle the packaging materials follow instructions provided by your local waste disposal service. www.neatech.it 2/126...
Page 14: Software Description
Programming must be conducted only by qualified personnel with in- depth knowledge of the wheelchair and power module system. Any change to this part of the software may result in a hazardous situation for the user. www.neatech.it 3/126...
Page 15: Adjustments
B - Assistant Sidepad height B - Assistant Footplates height B - Assistant Footplates angle and depth B - Assistant Joystick position B - Assistant Calf support position B - Assistant Legrest angle B - Assistant Table 2 www.neatech.it 4/126...
Page 16: Seat Depth
520 mm M5 – S045-V073 460 mm 520 mm Table 3 WARNING It is needed to set separately left and right seat depth. Always set them at the same manner. Average needed Difficulty level: time: Easy 5 min www.neatech.it 5/126...
Page 17 OPEN-END WRENCH • Set the backrest according to the desired seat depth. 10 mm • Tight again the 6 screws. • Repeat operations for both left and right side of the wheelchair. • Mount again the backrest. www.neatech.it 6/126...
Page 18: Backrest Angle
Average needed Difficulty level: time: Easy 5 min Powered legrest • Act on the joystick as described in section 4.1. Angle adjustable with pistons Use the lever located on the push bar to move the backrest. www.neatech.it 7/126...
Page 19 • Repeat operations for both left and right side of the wheelchair. • Set the position of the hardware highlighted in OPEN-END WRENCH 10 mm figure according to the desired backrest angle. • Screw again screws. • Repeat operations for both left and right side of the wheelchair. www.neatech.it 8/126...
Page 20 ADDITIONAL ADJUSTMENT After adjusted the angle of backrest as described above it is possible to adjust of more 20° simply acting on the axis shown in figure. Figure 3 www.neatech.it 9/126...
Page 21: Adjunctive Backrest Angle Adjustment
Average needed Difficulty level: time: Easy 5 min BACKREST POSSIBLE CONFIGURATION VALUES 90° - 130° 95° : 130° 100° : 135° Angle adjustable with pistons 105° : 135° 110° - 140° 120° - 145° www.neatech.it 10/126...
Page 22 • Repeat operations for both left and right side of the wheelchair. • Set the position of the hardware highlighted in OPEN-END WRENCH 10 mm figure according to the desired backrest angle. • Screw again screws. • Repeat operations for both left and right side of the wheelchair. www.neatech.it 11/126...
Page 23: Armrest Depth
RIGHT AND LEFT SIDE It is possible to adjust separately left and right side. Average needed Difficulty level: time: Easy <5 min RANGE Please be sure that the chosen position doesn't represent an obstacle. Figure 5 www.neatech.it 12/126...
Page 24 • Unscrew the lever shown in figure. ALLEN WRENCH 4 mm • Loosen the 2 screws shown in figure and set the depth of armrest clamp as desired. • Tighten again the 2 screws and put back the armrest. www.neatech.it 13/126...
Page 25 ADDITIONA ADJUSTMENT Moreover it is possible to adjust armrest depth unscrewing the 2 screws shown in figure with a 4 mm allen wrench. Figure 8 www.neatech.it 14/126...
Page 26: Armrest Height
RIGHT AND LEFT SIDE It is possible to adjust separately left and right armrest. Average needed Difficulty level: time: Easy <5 min SIDEPAD, JOYSTICK AND ARMREST HEIGHT It is better to adjust first armrest height, then joystick and finally the sidepad. www.neatech.it 15/126...
Page 27 Figure 9 • Loosen the 2 screws shown in figure. ALLEN WRENCH • Set the armrest according to the desired height. 4 mm • Tight again the 2 screws. www.neatech.it 16/126...
Page 28: Sidepad Height
RIGHT AND LEFT SIDE It is possible to adjust separately left and right sidepad. SIDEPAD, JOYSTICK AND ARMREST HEIGHT It is better to adjust first armrest height, then joystick and finally the sidepad. Average needed Difficulty level: time: Easy <5 min www.neatech.it 17/126...
Page 29 Please be sure that the chosen position doesn't represent an obstacle for armrest. Figure 10 Figure 11 • Unscrew the 2 screws shown in figure and set the ALLEN WRENCH position of sidepad as desired. 3 mm • Screw again the 2 screws. www.neatech.it 18/126...
Page 30: Footplates Height
185 mm 205 mm 225 mm 245 mm 265 mm Central mounted legrest 285 mm 305 mm 325 mm 345 mm 365 mm 385 mm 255 mm 280 mm 305 mm Powered legrest 330 mm 355 mm 380 mm www.neatech.it 19/126...
Page 31 5 mm end wrench. • Repeat the operation for both left and right side of the wheelchair. • Set the position of the footplate according to OPEN-END WRENCH 13 mm desired height. • Screw again the screws. www.neatech.it 20/126...
Page 32 • Unscrew the screw shown in figure with the allen ALLEN WRENCH wrench while holding the nut behind with the open- 5 mm end wrench. • Set the position of the footplate according to desired height. OPEN-END WRENCH • Screw again the screws. 13 mm www.neatech.it 21/126...
Page 33: Footplates Depth And Angle
In any case it is always possible to choose between 3 different depth. RIGHT AND LEFT SIDE It is possible to adjust separately left and right legrest if you have splitted footrest. Average needed Difficulty level: time: Easy <5 min www.neatech.it 22/126...
Page 34 Set the position of the footplate according to desired angle. 4 mm • Tighten again the screws. Central mounted legrest Figure 15 • ALLEN WRENCH Loosen the screw shown in figure to lower the footplate. Tighten it to rise the footplate. 4 mm www.neatech.it 23/126...
Page 35 Unscrew the 2 screws shown in figure. ALLEN WRENCH • Set the position of the footplate according to desired depth. 4 mm • Screw again the screws. Central mounted legrest RANGE It is not possible to perform this adjustment with central mounted legrest. www.neatech.it 24/126...
Page 36: Calf Support Position
It is possible to adjust separately left and right side. Average needed Difficulty level: time: Easy <5 min Figure 17 • Unscrew the 2 screws shown in figure and set the ALLEN WRENCH position of calf support as desired. 4 mm • Screw again the 2 screws. www.neatech.it 25/126...
Page 37 Moreover it is possible to choose the angle of calf support simply by pulling or pushing it. Figure 18 Central mounted legrest Figure 19 • Unscrew the screw shown in figure and set the ALLEN WRENCH height of calf support as desired. 6 mm • Screw again the 2 screws. www.neatech.it 26/126...
Page 38 Figure 20 • Loosen the screw shown in figure using a allen ALLEN WRENCH 6 mm wrench and a open-end wrench. • Set the angle ad desired and tighten again the OPEN-END WRENCH screw. 13 mm www.neatech.it 27/126...
Page 39: Legrest Angle
10° - 90° Powered legrest -15° - 80° Angle adjustable Average needed Difficulty level: time: Easy <1 min Figure 21 • Loosen the lever shown in figure. • Set legrest angle as desired. • Tighten again the lever. www.neatech.it 28/126...
Page 40 Please pay special attention when moving legrest because there is the possibility of trapping your or someone else fingers in legrest mechanism. Figure 22 Central mounted legrest Figure 23 • Loosen the lever shown in figure. • Set legrest angle as desired. • Tighten again the lever. www.neatech.it 29/126...
Page 41: Joystick Position
Difficulty level: time: Easy <5 min 3.11.1 Standard support - Depth Figure 24 • Unscrew the 2 screws shown in figure. ALLEN WRENCH • Adjust the depth of the joystick as desired. 5 mm • Screw again the screws. www.neatech.it 30/126...
Page 42: Retractable Support - Depth And Height
3.11.1 Retractable support - Depth and height Figure 26 • Unscrew the 2 screws shown in figure. ALLEN WRENCH • Adjust the depth and the height of the joystick as 5 mm desired. • Screw again the screws. www.neatech.it 31/126...
Page 43: Default Position
Default position means that all adjustable parts of the wheelchair are set in the most stable and safe configuration ADJUSTABLE PARTS VALUE NOTES Seat angle 0° Backrest angle 90° Legrest angle 90° Or minimum Seat height 0 cm Table 4 www.neatech.it 32/126...
Page 44: Use Of The Product
INFORMATION Do not install, maintain or operate the product without reading all warnings and this entire manual. Always keep this manual in connection with the product. INFORMATION The wheelchair is designed for use mostly in indoor environments. www.neatech.it 33/126...
Page 45 Do not stand on the frame of the wheelchair. Some pathologies may limit your ability to use your wheelchair safely. Be sure to consult with a doctor about your physical limitations. Please practice your drive ability under the supervision of an assistant. www.neatech.it 34/126...
Page 46 MAX 6° Figure 27 Dealing with downhill When facing a downhill road it is recommended to set the seating system to default position. It is better to use a drive profile with low speed MAX 6° Figure 28 www.neatech.it 35/126...
Page 47 When facing with side slopes, always use the wheelchair with great caution and make sure the seating system is in the default position. MAX 6° Figure 29 Turning with the wheelchair When turning with the wheelchair, always use great caution. www.neatech.it 36/126...
Page 48 Transfer into and out the wheelchair Users transfer is recommended with the presence of an assistant. Don’t use footrests or armrests as support. Always turn off the wheelchair before transfer. www.neatech.it 37/126...
Page 49 Do not lift the wheelchair with a user on board. Do not lift the wheelchair grabbing the legrests. If you really need to lift the wheelchair, it is suggested to grab it with the help of at least one other people. Grab the wheelchair using the tie down shown in figure. Figure 31 www.neatech.it 38/126...
Page 50: Control System Of The Wheelchair
On-Off Use this function to turn on and off the wheelchair. Don't use this function to stop the wheelchair unless it is an emergency. Horn MODE Use this function to navigate between drive and seat function. Speed increase/decrease www.neatech.it 39/126...
Page 51: Rnet 80 A Control System
Speed increase/decrease and outdoor. Use the function PROFILE to change different types of profiles: they are sorted from the more indoor ones to the more outdoor ones. For each profile it is possible to change the speed. www.neatech.it 40/126...
Page 52 Use this function to see total and partial distance made with the wheelchair. It is also possible to reset partial distance. Backlight It is possible to adjust backlights of the screen. Background Use this function to choose the color of background of the display. www.neatech.it 41/126...
Page 53: Manual Brake Release Lever
Don’t operate the brake release without the presence of an assistant. WARNING The drive system should be re-engaged before an occupant is left unattended or attempts to operate the wheelchair. WARNING Always act on both left and right manual release levers. www.neatech.it 42/126...
Page 54: Use As Seat In A Motor Vehicle
• The pelvic belt should be worn low across the front of the pelvis, so that the angle of the pelvic belt is within the preferred zone of 30° to 75° to the horizontal, similar to that shown in figure. Figure 35 www.neatech.it 43/126...
Page 55 In order to mount pelvic belt on the wheelchair, firstly mount the fixing plate as shown in figure. Use socket head cap screw M6x10 and a 5 mm allen ALLEN WRENCH 5 mm wrench. Repeat operation for both left and right side of the wheelchair. www.neatech.it 44/126...
Page 56 Firstly mount the fixing plate as shown in OPEN-END figure. WRENCH Use hushroom head square neck bolt screw M5x16 DIN 8 mm 603, M5 nut, and a 8 mm open-end wrench. Repeat operation for both left and right side of the wheelchair. www.neatech.it 45/126...
Page 57 WARNING: Safety of wheelchair and user can't be assured when the movement of gas springs is not correctly locked while using the wheelchair as a seat in a motor vehicle. Figure 39 www.neatech.it 46/126...
Page 58 When possible other auxiliary wheelchair equipment should be either secured to the wheelchair or removed from the wheelchair and secured in the vehicle during travel, so that it does not break and cause injury to vehicle occupants in the event of a collision. www.neatech.it 47/126...
Page 59 Alterations or substitutions should not be made to the wheelchair securement points or to structural and frame parts or components without consulting the wheelchair manufacturer. WARNING Wheelchair has sealed type batteries. Never use different battery type when used in a motor vehicle. www.neatech.it 48/126...
Page 60 WARNING Care should be taken when applying the occupant restraint to position the seatbelt buckle so that the release button will not be contacted by wheelchair components during a crash. www.neatech.it 49/126...
Page 61: Four Points Tie-Down
Use the tie down points marked with the symbol shown in figure. Figure 40 Use the tie down points marked with the symbol shown in figure. Hook the wheelchair in 4 points: two in the front part and two in the rear part. Figure 41 www.neatech.it 50/126...
Page 62 Tie down straps should form angles shown below. PREFERRED ANGLES OF FRONT PREFERRED ANGLES OF REAR WHEELCHAIR WHEELCHAIR TIE DOWN STRAPS TIE DOWN STRAPS 40° 30° 45° 60° 25° 25° 10° 10° Figure 42 Figure 43 WARNING Always use four tie down straps. www.neatech.it 51/126...
Page 63: Dahl Engineering Docking Station
Do not attempt to reverse out the docking station until the red LED on the control module, which indicates the unlock position, has been illuminated. Move the wheelchair away from the docking station within this 5-second period. www.neatech.it 52/126...
Page 64 If this happens repeat above unlocking procedure. Figure 45 CONTACT INFORMATION For more information contact the manufacturer of the wheelchair or the manufacturer of the docking station. Dahl Engineering Løvevej 3 DK-7700 Thisted Tel. +45 96 18 00 77 https://dahlengineering.dk sales@dahlengineering.dk www.neatech.it 53/126...
Page 65: Powered Functions
BACKREST Move forward the backrest Recline the backrest LEFT LEGREST Low left legrest Elevate left legrest www.neatech.it 54/126...
Page 66 RIGHT LEGREST Low right legrest Elevate right legrest LEGRESTS BOTH Low both legrests Elevate both legrests TILT Move forward the seat Tilt the seat LIFT Rise the seat Lower the seat www.neatech.it 55/126...
Page 67: Main Switch
If the problem still continues, it means that there is some electric fault. If the switch operates, often this means that there is a major electrical fault. The cause of fault should be checked carefully. For more information, please contact the manufacturer. www.neatech.it 56/126...
Page 68: Battery Charging
Seat width from 300 mm to 360 mm: 24 V - 35 Ah - about 197x131x180 (h) about Seat width from 380 mm to 460 mm: 24 V - 50 Ah - about 198x166x171 (h) mm - about 15 kg www.neatech.it 57/126...
Page 69 Check if charger requirements data matches with the network power (voltage, frequency) RELEASE DANGER Any impact to the batteries could cause a loss of fluids. Please pay special attention. BATTERIES DISPOSAL To properly recycle the batteries follow instructions provided by your local waste disposal service. www.neatech.it 58/126...
Page 70: Transport And Storage
It is possible to store the wheelchair in a place with a temperature between -20 °C and +45 °C. • Turn off the wheelchair. • Turn off the main switch. See section 4.5. WARNING If you transport the wheelchair with motors disengaged, the wheelchair is free to move. This may result in a hazardous situation. www.neatech.it 59/126...
Page 71: Maintenance
To clean the wheelchair do not use high-pressure water spray devices. For plastic and metal parts use a soft cloth dampened with mild detergent. For the upholstery, linings, seat and back covers use warm water and mild detergent. Do not use stain removers, solvents, acids, etc. www.neatech.it 60/126...
Page 72: Controls To Be Performed On The Product
250 kPa. Check if the lever of the main Weekly B - Assistant switch works correctly Check tire usury Monthly B - Assistant Check brake release lever Monthly B - Assistant Check aging of batteries Monthly C - Service www.neatech.it 61/126...
Page 73: Tire Puncture
5.3 Tire puncture 5.3.1 User information Traction wheel Figure 48 • Lift the wheelchair. ALLEN WRENCH • Unscrew the 4 screws shown in figure. 6 mm • Remove the wheel. www.neatech.it 62/126...
Page 74 • Remove the castor. Contact an authorized service center for the repair or the substitution of the damaged wheel. When the authorized service center gives you back the repaired wheel or a new one, mount it following instructions in reverse order. www.neatech.it 63/126...
Page 75 R045-0133 Tube for castor Ø200 mm x 50 mm Table 5 Type of operation Parts that can be bought at an authorized service center and substitute autonomously Parts that need to be substituted at an authorized service center. www.neatech.it 64/126...
Page 76 Code Quantity R045-0120A tire R045-0120B tire R045-0120 R045-0120 tube R045-0120 R045-0120 R045-121A tire R045-121B tire Figure 50 R045-0122 tube www.neatech.it 65/126...
Page 77 Code Quantity 162A R045-0131A tire 162B R045-0131B tire 162C R045-0131C tire 162D R045-0131D tire R045-0131A tube R045-0131B tube R045-0131 R045-0131 162A R045-0132A tire 162B Figure 51 R045-0132B tire R045-0133 tube www.neatech.it 66/126...
Page 78: Wiring Diagram
5.4 Wiring diagram 5.4.1 Rnet Figure 52 www.neatech.it 67/126...
Page 79: Vr2
5.4.2 VR2 Figure 53 www.neatech.it 68/126...
Page 80: Reuse
The product is suitable for reuse. Before dispensing it, the product must be cleaned, and subjected to maintenance. The operating instructions are included in this manual and must also be provided when the product is passed on. WARNING This operation must be performed only at an authorized service center. www.neatech.it 69/126...
Page 81: Spare Parts
Castor PU black Ø200 mm x 50 mm R045-0132A Tire of castor gray Ø200 mm x 50 mm R045-0132B Tire of castor black Ø200 mm x 50 mm R045-0133 Tube for castor Ø200 mm x 50 mm R045-0134 Fork www.neatech.it 70/126...
Page 82 Footplates splitted - seat width 300 mm R045-0320B Footplates splitted - seat width 340 mm R045-0320C Footplates splitted - seat width 380 mm R045-0320D Footplates splitted - seat width 420 mm R045-0320E Footplates splitted - seat width 460 mm www.neatech.it 71/126...
Page 83 Backrest actuator R045-0371 Backrest support (4 pieces) R045-0372 Gas spring for tilting - couple R045-0373 Backrest pin R045-0374 Axis for angle adjustable backrest R045-0380 Padding for push handle R045-0391 Armrest padding R045-0392 Armrest support R045-0393 Armrest fixing system www.neatech.it 72/126...
Page 84 Calf support for central mounted legrest LARGE R045-0420 Gyroscope Table 7 WARNING The use of spare parts or accessories not approved by the manufacturer may make the wheelchair unstable or uncontrollable. For each order, always contact an authorized service center. www.neatech.it 73/126...
Page 85 CONTACT INFORMATION For any other part not described in this manual please contact the manufacturer. www.neatech.it 74/126...
Page 86: Antitip Wheels
5.6.1 Antitip wheels Average needed Difficulty level: time: Easy 5 min Figure 54 • Unscrew the screws shown in figure. SCREWDRIVER • Substitute the wheel. • Screw the new screws. www.neatech.it 75/126...
Page 87 Code Quantity R045-0140 R045-0140 Figure 55 Code Description Type of Notes operation R045-0140 Antitip wheel www.neatech.it 76/126...
Page 88: Cover A
5.6.2 Cover A Average needed Difficulty level: time: Easy 5 min Figure 56 • Unscrew the 4 screws shown in figure. ALLEN WRENCH • Substitute the cover. 3 mm • Screw the new screws. www.neatech.it 77/126...
Page 89 Code Description Type of Notes operation R045-0150 Cover A Code Quantity R045-0150 R045-0150 Figure 57 www.neatech.it 78/126...
Page 90: Cover B
5.6.3 Cover B Average needed Difficulty level: time: Easy 5 min Figure 58 • Unscrew the 4 screws shown in figure. ALLEN WRENCH • Substitute the cover. 3 mm • Screw the new screws. www.neatech.it 79/126...
Page 91 Code Description Type of Notes operation R045-0160 Cover B Code Quantity R045-0160 R045-0160 R045-0161 Figure 59 www.neatech.it 80/126...
Page 92: Levers For Cover
5.6.4 Levers for cover Average needed Difficulty level: time: Easy 5 min Figure 60 • Substitute the levers shown in figure. Code Description Type of Notes operation R045-0161 Levers for cover www.neatech.it 81/126...
Page 93: Lever For Motors
• Unscrew the screw shown in figure. ALLEN WRENCH • Substitute the levers for motor. 4 mm • Screw the new screw. Code Description Type of Notes operation R045-0171 Lever for motors Code Quantity R045-0171 R045-0171 Figure 62 www.neatech.it 82/126...
Page 94: Standard Joystick Support
Remove the joystick. Figure 64 • Unscrew the 2 screws shown in figure. Unscrew the 2 screws shown in figure. ALLEN WRENCH • Substitute the joystick support. 5 mm • Mount the old joystick following instructions in reverse order. www.neatech.it 83/126...
Page 95 Code Description Type of Notes operation R045-0190A Standard joystick support Code Quantity R045-0190 A R045-0190 A R045-0190 A R045-0190 A R045-0190 A R045-0190 A R045-0190 A R045-0190 A Figure 65 R045-0190 A R045-0190 A R045-0190 A www.neatech.it 84/126...
Page 96: Retractable Joystick Support
• Unscrew the 2 screws shown in figure. ALLEN WRENCH 3 mm • Remove the joystick. Figure 67 • Unscrew the 2 screws shown in figure. • Substitute the joystick support. ALLEN WRENCH 3 mm • Mount the old joystick following instructions in reverse order. www.neatech.it 85/126...
Page 97 Code Description Type of Notes operation R045-0190B Retractable joystick support Code Quantity R045-0190B R045-0190B R045-0190B R045-0190B R045-0190B R045-0190B Figure 68 R045-0190B www.neatech.it 86/126...
Page 98: Joystick
• Unscrew the 2 screws shown in figure. ALLEN WRENCH 4 mm • Substitute the joystick. Retractable joystick support Figure 70 • Unscrew the 2 screws shown in figure. ALLEN WRENCH 3 mm • Substitute the joystick support. www.neatech.it 87/126...
Page 99: Legrest Actuator
Easy 5 min Figure 71 • Remove the seegers shown in figure. Use a screwdriver as a lever. SCREWDRIVER • Unplug cable of actuator. • Substitute the actuator. Code Description Type of Notes operation R045-0313 Legrest actuator www.neatech.it 88/126...
Page 100 Code Quantity Figure 72 R045-0313 www.neatech.it 89/126...
Page 101: Footplates
5.6.10 Footplates Average needed Difficulty level: time: Easy 5 min Figure 73 • Unscrew the screws shown in figure. ALLEN WRENCH • Repeat operations for both left and right side of the 4 mm wheelchair. • Substitute footplates. www.neatech.it 90/126...
Page 102 Central mounted legrest Figure 74 ALLEN WRENCH • Unscrew the screws shown in figure using a allen 4 mm wrench while holding the nut behind with a open-end wrench. OPEN-END • Substitute footplate. WRENCH 10 mm www.neatech.it 91/126...
Page 103 Footplate unique - seat width 380 mm R045-0320J Footplate unique - seat width 420 mm R045-0320K Footplate unique - seat width 460 mm Code Quantity R045-0320 R045-0320A 293A R045-0320B 293B R045-0320C 293C R045-0320D 293D Figure 75 R045-0320E 293E www.neatech.it 92/126...
Page 104 Code Quantity R045-0320 R045-0320F 301A R045-0320G 301B R045-0320H 301C R045-0320J 301D Figure 76 R045-0320K 301E www.neatech.it 93/126...
Page 105: Footplate Fixing System
ALLEN WRENCH • Unscrew the screws shown in figure using a allen 5 mm wrench while holding the nut behind with a open-end wrench. OPEN-END • Substitute footplate fixing system and mount the old WRENCH 13 mm footplate. www.neatech.it 94/126...
Page 106 Notes operation R045-0321A Fixing system for footrest - LEFT side unique footplate R045-0321B Fixing system for footrest - RIGHT or LEFT side splitted footplates or RIGHT side unique footboard R045-0321C Fixing system for footrest - central mounted legrest www.neatech.it 95/126...
Page 107 Code Quantity R045-0321A R045-0321A R045-0321A R045-0321A R045-0321A R045-0321A R045-0321A Figure 79 Code Quantity R045-0321B R045-0321B R045-0321B R045-0321B R045-0321B R045-0321B Figure 80 R045-0321B www.neatech.it 96/126...
Page 108 Code Quantity R045-0321C R045-0321C R045-0321C R045-0321C R045-0321C R045-0321C Figure 81 R045-0321C www.neatech.it 97/126...
Page 109: Backrest Actuator
Backrest actuator Average needed Difficulty level: time: Easy 5 min Figure 82 • Remove the axis shown in figure. ALLEN WRENCH • Unscrew the screw shown in figure. 6 mm • Unplug the actuator. • Substitute the actuator. www.neatech.it 98/126...
Page 110 Code Description Type of Notes operation R045-0360 Backrest actuator Code Quantity R045-0360 R045-0360 Figure 83 www.neatech.it 99/126...
Page 111: Backrest Support
OPEN-END WRENCH 10 mm • Repeat operations for 4 backrest supports (right and left side of the wheelchair), one support at time. WARNING It is very important to substitute one backrest support at time. Please pay special attention. www.neatech.it 100/126...
Page 112 Code Description Type of Notes operation R045-0371 Backrest support Code Quantity R045-0371 R045-0371 R045-0371 R045-0371 R045-0371 R045-0371 R045-0371 R045-0371 R045-0371 R045-0371 R045-0371 R045-0371 R045-0371 R045-0371 Figure 85 R045-0371 R045-0371 R045-0371 R045-0371 www.neatech.it 101/126...
Page 113: Backrest Pin
5.6.14 Backrest pin Average needed Difficulty level: time: Easy 5 min Figure 86 • Substitute the pin shown in figure. Code Description Type of Notes operation R045-0373 Backrest pin Code Quantity R045-0373 R045-0373 R045-0373 Figure 87 R045-0373 www.neatech.it 102/126...
Page 114: Axis For Angle Adjustable Backrest
• Remove the pin shown in figure. ALLEN WRENCH • Unscrew the screw shown in figure. 6 mm • Substitute the axis. Code Description Type of Notes operation R045-0374 Axis for angle adjustable backrest Code Quantity R045-0374 R045-0374 Figure 89 www.neatech.it 103/126...
Page 115: Armrest Padding
5.6.16 Armrest padding Average needed Difficulty level: time: Easy 5 min Figure 90 • Unscrew the 2 screws shown in figure. ALLEN WRENCH 5 mm • Substitute the armrest padding. www.neatech.it 104/126...
Page 116 Code Description Type of Notes operation R045-0391 Armrest padding Code Quantity R045-0391 R045-0391 R045-0391 Figure 91 www.neatech.it 105/126...
Page 117: Armrest Support
5 min Figure 92 • Remove armrest padding. See section 5.6.16 • Unscrew the 2 screws shown in figure. ALLEN WRENCH 4 mm • Substitute the armrest support. • Mount the old armrest padding. See section 5.6.16 . www.neatech.it 106/126...
Page 118 Code Description Type of Notes operation R045-0392 Armrest support Code Quantity R045-0392 R045-0392 R045-0392 Figure 93 www.neatech.it 107/126...
Page 119: Armrest Fixing System
Difficulty level: time: Easy 5 min Figure 94 • Unscrew the lever shown in figure and remove the ALLEN WRENCH armrest. 4 mm • Unscrew the 2 screws shown in figure. • Substitute the fixing system for armrest. www.neatech.it 108/126...
Page 120 Code Description Type of Notes operation R045-0393 Armrest fixing system R045-0394 Lever for armrest Code Quantity R045-0393 R045-0393 R045-0393 R045-0393 R045-0393 R045-0394 Figure 95 www.neatech.it 109/126...
Page 121: Armrest Lower Support
5.6.19 Armrest lower support Average needed Difficulty level: time: Easy 5 min Figure 96 • Loosen the lever shown in figure and remove the armrest. • Remove the sidepad. See section 5.6.20 . www.neatech.it 110/126...
Page 122 • Substitute the armrest lower support following ALLEN WRENCH 4 mm instructions in reverse order. Code Description Type of Notes operation R045-0395A Armrest lower support standard R045-0395B Armrest lower support high Code Quantity R045-0395A 263 A R045-0395B 263B Figure 98 www.neatech.it 111/126...
Page 123: Sidepad
Average needed Difficulty level: time: Easy 5 min Figure 99 • Unscrew the screws shown in figure. • Substitute the sidepad. ALLEN WRENCH 3 mm Code Description Type of Notes operation R045-0396 Sidepad Code Quantity R045-0395A R045-0395B Figure 100 www.neatech.it 112/126...
Page 124: Legrest Support
5.6.21 Legrest support Average needed Difficulty level: time: Easy 5 min Figure 101 • Loosen the lever shown in figure. • Remove legrest. www.neatech.it 113/126...
Page 125 Figure 102 • Unscrew the screws shown in figure. • Substitute the legrest support. ALLEN WRENCH 5 mm • Mount the old legrest following instructions in reverse order. INFORMATION It is also possible to substitute only the lever. www.neatech.it 114/126...
Page 126 Code Description Type of Notes operation R045-0400 Legrest support R045-0401 Lever for legrest Code Quantity R045-0400 R045-0400 R045-0400 R045-0400 R045-0401 Figure 103 www.neatech.it 115/126...
Page 127: Lever For Angle Adjustable Legrest
5.6.22 Lever for angle adjustable legrest Average needed Difficulty level: time: Easy 1 min Figure 104 • Substitute the lever shown in figure. Central mounted legrest Figure 105 • Substitute the lever shown in figure. www.neatech.it 116/126...
Page 128 Code Description Type of Notes operation R045-0402A Lever for angle adjustable legrest - standard legrest R045-0402B Lever for angle adjustable legrest - central mounted legrest www.neatech.it 117/126...
Page 129: Calf Support
5.6.23 Calf support Average needed Difficulty level: time: Easy 5 min Figure 106 • Unscrew the screws shown in figure. ALLEN WRENCH • Substitute the calf support. 4 mm www.neatech.it 118/126...
Page 130 OPEN-END WRENCH • Substitute the calf support. 13 mm Code Description Type of Notes operation R045-0404A Calf support SMALL R045-0404B Calf support LARGE R045-0404C Calf support for central mounted legrest SMALL R045-0404D Calf support for central mounted legrest LARGE www.neatech.it 119/126...
Page 131 Code Quantity R045-0404A R045-0404B R045-0404 R045-0404 R045-0404 R045-0404 R045-0404 Figure 108 R045-0404 Code Quantity R045-0404C R045-0404D R045-0404 R045-0404 R045-0404 R045-0404 Figure 109 www.neatech.it 120/126...
Page 132: Specifications
It is possible to use the wheelchair when the temperature is between -10 °C and +40 °C. It is possible to store the wheelchair in a place with a temperature between -20 °C and +45 °C. www.neatech.it 121/126...
Page 133: Maximum User Weight
6.1 Maximum user weight Seat width 30 cm 50 kg 34 cm 75 kg 38 cm 100 kg 42 cm 150 kg 46 cm 150 kg Table 8 www.neatech.it 122/126...
Page 134: Other Provided Information
6.2 Other provided information Manufacturer Neatech.it srl Address via A. de Curtis 4/A – 80040 – Cercola (NA) - Italy Model S045 – EVO1 Description Value 110 cm Overall length with legrest Overall width MIN: 50.0 cm MAX: 59.0 cm Folded length N.A.
Page 135 MIN: 45.0 cm MAX: 55.0 cm Footrest to seat distance MIN: 15.0 cm MAX: 40.0 cm Armrest to seat distance MIN: 22.0 cm MAX: 28.5 cm Minimum turning radius [ISO 7176-5] 30 cm Turn around distance [ISO 7176-5] 120 cm www.neatech.it 124/126...
Page 136: Dimensions
610 mm 220 mm – 285 mm MIN 150 mm – MAX 400 mm see section 3.7 0° TILT: 450 mm 30° TITL: 445 mm 45° TILT 48m5 mm LIFT 490 mm FWD: 75 cm RWD: 64 cm www.neatech.it 125/126...
Page 137: Warranty Terms
The warranty expires in case of tampering, improper storage, unauthorized or incorrect maintenance. 7.1 Serial number For any report or assistance request, please communicate the serial number mentioned on the label in the position shown in figure. Figure 110 www.neatech.it 126/126...
Page 138 Note...
