- Page 1 INSTRUCTION MANUAL Sensor & Wire-saving Link System S-LINK VME Bus S-LINK V Control Board SL-VVMES2 © Panasonic Industrial Devices SUNX Co., Ltd. 2013 CMJE-SLVVMES2 No.0037-87V...
- Page 2 1. Introduction Thank you very much for using Panasonic products. Please read this Instruction Manual carefully and thoroughly for the correct and optimum use of this product. Kindly keep this manual in a con- venient place for quick reference. WARNING Never use this product in a device for personnel protection.
- Page 3 VME bus rack. If the jumper is not pulled out, this product may break. 3) In case of inserting SL-VVMES2 WR WKH 90( EXV UDFN RU SXOOLQJ LW RXW WDNH VXI¿FLHQW FDUH QRW WR come in contact with the adjacent VME bus module.
-
Page 4: Function Description
4. Function Description (Unit: mm) 186.1 6) Transmission 7.45 (16.5) 169.6 indicator for port 1 (Green) M2.5 (length 9) 9) Interruption level setting switches 7) BUSY indicator for port 1 (Orange) 8) Error indicator 10) Status / ID for port 1 (Red) setting switches 2) I/O first address 5) System setting... - Page 5 ,2 ¿UVW DGGUHVV VHWWLQJ VZLWFK 6: Set upper two digits out of four digits of the hexadecimal short address of VME bus. Ensure that the address does not overlap with the I/O address used on the other boards. (ON = 1, OFF = 0) (Example) Address = 0200H to 03FFH Switch Hexadecimal...
- Page 6 4) I/O setting switch (For port 1: SW1 / SW2, For port 2: SW4 / SW5) I/O setting is done for each 32 points with the I/O setting switch. Setting is read in only once when power is supplied to the computer or when the reset command is executed on the S-LINK V sys- tem side.
- Page 7 8) Error indicator (Red) It lights up when an error occurs on the S-LINK V system main cable. In case the cause of the er- ror is eliminated, it blinks, and if the error No. is cleared with program, or when the system setting is done, it turns OFF.
- Page 8 5. Assignment on Program SL-VVMES2 memory map Port 1 Port 2 VME bus VME bus address address (byte unit) (byte unit) +0000H +0100H 64 bytes 64 bytes S-LINK V I/O data S-LINK V I/O data (32 words) (32 words) +003FH...
- Page 9 1) HL00 + 0000 to HL00 + 003F, HL00 + 0100 to HL00 + 013F: S-LINK V I/O data Relationship between “Computer I/O address” and “S-LINK V address” Computer I/O address S-LINK V address (hexadecimal) Port 1 Port 2 bit 7 bit 6 bit 5 bit 4...
- Page 10 Computer I/O address S-LINK V address (hexadecimal) Port 1 Port 2 bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0 HL00 + 0039 HL00 + 0139 HL00 + 003A HL00 + 013A HL00 + 003B HL00 + 013B HL00 + 003C HL00 + 013C...
- Page 11 3) HL00 + 0042 to 5, HL00 + 0142 to 5: I/O setting It sets the I/O assignment of the S-LINK V I/O units. Just after power ON / reset of the computer, it indicates the setting condition of “4) I/O setting switch (For port 1: SW1 / SW2, For port 2: SW4 / SW5)”...
- Page 12 6) HL00 + 004C to D, HL00 + 014C to D: Command execution request register 7) HL00 + 004E to F, HL00 + 014E to F: Command completion response register (read out only) 7KHVH DUH XVHG WR LQGLFDWH &RPPXQLFDWLRQ IUDPH FRQ¿UPDWLRQ (UURU 1R FOHDUDQFH 'HIDXOW 6\V- tem set, Interruption, Busy, On Hold and command under execution.
- Page 13 Notes: 1) Once each command of bit 0 to 4 is executed, the bit value does not return to the original value. In order to execute the next command, write “0” into the bit corresponding to HL00 + 004C or HL00 + 014C once and check that the bit corresponding to HL00 + 004E or HL00 + 014E has turns to “0”...
- Page 14 Read out Read out Read out The timing of input read out on user’s computer Input signal to the input unit Process of internal Hold circuit Input read out data on user’s computer This cannot be read out because the timing of bit 0 the input signal and reading out do not match.
- Page 15 12) HL00 + 0080 to HL00 + 00BF, HL00 + 0180 to HL00 + 01BF: Address information bank register (read out only) Relationship between “Computer I/O address” and “S-LINK V address” Computer I/O address S-LINK V address (hexadecimal) Port 1 Port 2 bit 7 bit 6...
- Page 16 Computer I/O address S-LINK V address (hexadecimal) Port 1 Port 2 bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0 HL00 + 00B9 HL00 + 01B9 HL00 + 00BA HL00 + 01BA HL00 + 00BB HL00 + 01BB HL00 + 00BC HL00 + 01BC HL00 + 00BD HL00 + 01BD HL00 + 00BE HL00 + 01BE...
- Page 17 Bank change-over procedure SL-VVMES2 User’s computer HL00 + 0080 / HL00 + 0180 Address information bank register HL00 + 00B0 / HL00 + 01B0 HL00 + 0050 to 1 / HL00 + 0150 to 1 Internal circuit Bank change-over request...
- Page 18 13) HL00 + 00C0 to HL00 + 00FF, HL00 + 01C0 to HL00 + 01FF: Input interruption allowing address Relationship between “Computer I/O address” and “S-LINK V address” Computer I/O address S-LINK V address (hexadecimal) Port 1 Port 2 bit 7 bit 6 bit 5 bit 4...
- Page 19 Computer I/O address S-LINK V address (hexadecimal) Port 1 Port 2 bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0 HL00 + 00F9 HL00 + 01F9 HL00 + 00FA HL00 + 01FA HL00 + 00FB HL00 + 01FB HL00 + 00FC HL00 + 01FC HL00 + 00FD HL00 + 01FD...
-
Page 20: Specifications
$V IRU DOO RWKHU PRGHOV SOHDVH FRQWDFW RXU RI¿FH Contact for CE <Until June 30 ,2013> Panasonic Electric Works Europe AG Rudolf-Diesel-Ring 2, D-83607 Holzkirchen, Germany <From July 1 ,2013> Panasonic Marketing Europe GmbH Panasonic Testing Center Winsbergring 15, 22525 Hamburg,Germany... - Page 21 (MEMO)
- Page 22 (2) Any Products found to be defective must be shipped to Panasonic Industrial Devices SUNX with all shipping costs paid by Purchaser or offered to Panasonic Industrial Devices SUNX for inspection and examination.
