SMC Networks SMC8624/48T Management Manual page 443

Field
LACPDUs
Internal
LACP System
Priority
LACP Port
Priority
Admin State,
Oper State
Description
Number of seconds before invalidating received LACPDU
information.
LACP system priority assigned to this port channel.
LACP port priority assigned to this interface within the
channel group.
Administrative or operational values of the actor's state
parameters:
• Expired – The actor's receive machine is in the expired state.
• Defaulted – The actor's receive machine is using defaulted
operational partner information, administratively configured
for the partner.
• Distributing – If false, distribution of outgoing frames on
this link is disabled; i.e., distribution is currently disabled and
is not expected to be enabled in the absence of
administrative changes or changes in received protocol
information.
• Collecting – Collection of incoming frames on this link is
enabled; i.e., collection is currently enabled and is not
expected to be disabled in the absence of administrative
changes or changes in received protocol information.
• Synchronization – The System considers this link to be
IN_SYNC; i.e., it has been allocated to the correct Link
Aggregation Group, the group has been associated with a
compatible Aggregator, and the identity of the Link
Aggregation Group is consistent with the System ID and
operational Key information transmitted.
• Aggregation – The system considers this link to be
aggregatable; i.e., a potential candidate for aggregation.
• Long timeout – Periodic transmission of LACPDUs uses a
slow transmission rate.
• LACP-Activity – Activity control value with regard to this
link. (0: Passive; 1: Active)
L A
INK GGREGATION
C
OMMANDS
4-198
