SMC Networks SMC8608SX Specification Sheet

TigerSwitch™ 1000
SMC8608SX
8 Port Gigabit Switch
SMC's new TigerSwitch™ 1000 is a Gigabit Ethernet backbone switch that provides 8
full-duplex 1000BASE-SX ports. With 16 Gbps of bandwidth, this switch dramatically
improves the performance of congested networks. A host of advanced features and
comprehensive management capabilities make this device a potent solution for the
network core.
The TigerSwitch™ 1000 provides high bandwidth, high-performance connectivity
within and between workgroups, and increased capacity for server farms, giving users
faster access to network-wide resources. Moreover, the 1000BASE-SX fiber optic ports
support connections up to 550 meters (1800 feet) in length.
The TigerSwitch™ 1000 comes fully-loaded with advanced performance-enhancing
features. IGMP maintains available bandwidth by limiting multicast transmissions to
subscribers only. Broadcast Storm Suppression prevents broadcast traffic storms from
engulfing the network. QoS priority queueing ensures the minimum delay for real-
time multimedia data across the network. Flow Control eliminates the loss of packets
due to bottlenecks caused by port saturation. Port-based and tagged VLANs are also
included to provide traffic security and efficient use of network bandwidth.
Outstanding Performance
• 8 full-duplex 1000BASE-SX ports
• 16 Gbps of aggregate bandwidth
• QoS support with two levels of priority and Weighted Fair Queueing
• IGMP filtering and snooping provides complete control of multicastpacets
• Broadcast storm suppression prevents broadcast traffic storms from engulfing the network
• Address table of up to 12K MAC addresses
• Full-duplex flow control eliminates lost packets due to port saturation
Flexible
• Up to 16 IEEE 802.1Q VLANs provides maximum security and bandwidth efficiency
• Port mirroring allows detailed analysis of traffic crossing any port in real time
• Rack-mountable (standard 19" rack)
• Supports a redundant power supply for fail-safe operation
Manageable
• In-band via Telnet, or any SNMP-based management application
• Out-of-band via RS-232 console port
• Web management agent for switch configuration access anytime, anywhere
• 4-group RMON (groups 1, 2, 3, 9)
• Spanning Tree Protocol allows the creation of redundant data paths
Compatible
• IEEE 802.3z, 802.3x, 802.1d, 802.1Q, and 802.1p
Reliability
• Three-year warranty
• Toll-free technical support
• SMC Customer Satisfaction Guarantee
