Showing Port Statistics

You can display statistics on network traffic from the ports. These statistics
can be used to identify potential problems with the switch (such as a faulty
port or unusually heavy loading). All values displayed have been
accumulated since the last system reboot, but can be reset to zero by
clicking the CLEAR button. The current statistics are not displayed until
you click the REFRESH button.
Parameter
Interface Statistics
Received Octets
Received Unicast Packets
Received Errors
Transmitted Multicast
Packets
Transmitted Broadcast
Packets
Received High Priority
Packets
Transmitted High Priority
Packets
Received Multicast Packets The number of packets, delivered by this sub-layer to
12
S
WITCH
Table 4 Port Statistics
Description
The total number of octets received on the interface,
including framing characters.
The number of subnetwork-unicast packets delivered
to a higher-layer protocol.
The number of inbound packets that contained errors
preventing them from being deliverable to a
higher-layer protocol.
The total number of packets that higher-level
protocols requested be transmitted, and which were
addressed to a multicast address at this sub-layer,
including those that were discarded or not sent.
The total number of packets that higher-level
protocols requested be transmitted, and which were
addressed to a broadcast address at this sub-layer,
including those that were discarded or not sent.
The total number of received packets that set as High
Priority in the QoS settings.
The total number of transmitted packets that set as
High Priority in the QoS settings.
a higher (sub-)layer, which were addressed to a
multicast address at this sub-layer.
