Daikin MC30VVM-A Operation Manual page 13

OPERATING/INDICATOR PANEL
6
Dust/PM2.5 sensor lamp
5
FAN lamp [green]
ON/OFF button
1
Press to turn the power ON or OFF.
ON/OFF lamp [green]
3
Lamp will light up when the power
is ON.
FAN lamp [green]
5
Indicates the active FAN setting
(4 settings: Quiet, Low, Standard,Turbo).
About the FAN symbols
▶
*
Symbol
Setting Quiet Low
∗ The size of the symbols varies in accordance with
the airflow rate setting.
About the dust/PM2.5 sensor lamp
- After operation is started, the lamp will light green for the first minute (approx.) regardless of air impurity level.
- If the responsiveness of the dust/PM2.5 sensor is poor, change the sensitivity setting of the sensor. ►Page14
- The responsiveness of the dust/PM2.5 sensor may be poor during FAN setting "Turbo" or when airflow is high in
AUTO FAN MODE. The strong airflow causes dust to be drawn into the air inlets before it can be detected by the
dust/PM2.5 sensor. This is normal (not a malfunction).
TIPS
Dust/PM2.5 sensor detection range
- Detectable matter : house dust, tobacco smoke, pollen, mites, pet hairs,diesel particulate matter
- Sometimes detectable : steam, oil smoke
4
MODE lamps [green]
FAN
* *
Standard Turbo
2 1
FAN/MODE Button
3
ON/OFF lamp [green]
FAN/MODE button
2
Press to cycle between FAN
settings and MODEs.
MODE lamps [green]
4
Indicates the MODE in operation.
Dust/PM2.5 sensor lamp
6
Indicates the volume of ambient dust in 3 colours:
green, orange, red.
∗ Green indicates that the air is clean.
∗ The dust/PM2.5 sensor lamp can detect small (approx.1.0-
2.5μm) and large (approx. 2.5μm and above) dust particles.
The "PM2.5" lamp lights in response to small particles and the
DUST lamp lights in response to large dust particles.
Green Orange
Lamp colour
Few
Dust
Indicators Buttons
ON/OFF Button
Red
Many
11
12
