Air purifi er
Floor standing or desktop type
Model
MC30YVM
• Thank you for purchasing this air purifi er.
• Please read the operation manual carefully and follow it for correct use.
• Please read the "Safety Precautions" section before use.
Please keep the operation manual in a safe place for later reference.
Air Purifi er
OPERATION MANUAL
► Page 2,3
For internal
use only
3P664947-7
Advertisement
Table of Contents
Related Manuals for Daikin MC30Y
Summary of Contents for Daikin MC30Y
- Page 1 Air purifi er Floor standing or desktop type Air Purifi er Model MC30YVM OPERATION MANUAL • Thank you for purchasing this air purifi er. • Please read the operation manual carefully and follow it for correct use. For internal ► Page 2,3 •...
-
Page 2: Table Of Contents
Read First Contents Read First Safety Precautions ............Names of Parts and Operations ........Preparation Before Operation .......... Using the Air Purifying Operation ........Operation Changing the Airfl ow Rate ..........Operating the Unit in a MODE ........10 SLEEP MODE Useful Functions Using the Child Proof Lock .......... - Page 3 Read First Safety Precautions Observe these precautions in order to prevent property damage or injury. The consequences of incorrect use are categorised as follows: WARNING CAUTION Failure to follow these instructions properly may Failure to follow these instructions properly may result in property damage or personal injury, which result in personal injury or loss of life.
- Page 4 Read First Safety Precautions CAUTION Observe in order to prevent short circuiting, injury or property damage. During use • Small children or immobile persons (due to illness or injury) should not operate the unit by themselves. For EU: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 5 Read First Names of Parts and Operations CAUTION Do not lift up the unit holding the grip on the deodorising fi lter unit. (May lead to falling over) Front Back Operating/Indicator panel ► Page 5, 6 Air outlet Grip (for carrying the unit) Deodorising fi...
- Page 6 Read First Names of Parts and Operations Operating/Indicator panel When a lamp is blinking ►Page 16 ON-OFF lamp [blue] Streamer lamp [blue] Lamp will light up when the power Light up when the Streamer is is ON. active Child Proof Lock lamp FAN lamps [blue] MODE lamp [blue] [blue]...
- Page 7 Read First Operating/Indicator panel ON-OFF button Press to turn the power ON or OFF FAN button MODE button Press to cycle between FAN settings Press to active SLEEP MODE Accessories Operation manual ... 1 Deodorising fi lter ....1 Attach to the unit before operation. Preparation Before Operation Positioning the unit Pointers for good positioning...
- Page 8 Read First Preparation Before Operation Do not use in the following places Do not expose to direct sunlight. Do not use cosmetics etc., containing silicone* near the unit. (Discolouration may result) * Hair care products (split ends coating agents, hair ...
- Page 9 Read First Attaching the deodorising filter CAUTION Attach the deodorising filter. Carry out these steps before inserting the 1 Set the deodorising fi lter under the fi xed parts. (2 places) power supply plug. Fixed parts Deodorising fi lter Remove the deodorising filter unit from the main unit.
- Page 10 Operation WARNING Operation Do not turn off the unit by unplugging it from the power socket. (Fire or an electric shock may result from heating) Using the Air Purifying Operation (turning operation ON/OFF) Cleans the air in the room. Press •...
-
Page 11: Operating The Unit In A Mode
Useful Functions Useful Functions Operating the Unit in a MODE Select the MODE according to your needs. Press • Each press will activate and deactivate SLEEP MODE [blue]. SLEEP MODE Usage and Function SLEEP Provide a quieter and comfortable sleep experience. MODE 1 FAN setting will operates at Quiet fan to provide the less noise condition. -
Page 12: Using The Child Proof Lock
Useful Functions Useful Functions Using the Child Proof Lock Button operation is restricted, preventing misoperation by small children. Hold down for about 3 seconds. • Hold down for about 3 seconds again to turn off Child Proof Lock. • When Child Proof Lock is active, operations will be restricted. When any button is pressed, only a tone (3 short beeps) will sound, preventing misoperation by small children. -
Page 13: Streamer Output Settings
Advanced Settings Advanced Settings If the hissing sound generated by the Streamer discharge or the *Setting at time of purchase smell of ozone bothers you Streamer Output Settings Regular* Hold down for about 3 seconds with the power supply plug inserted and the unit turned off. -
Page 14: Maintenance
WARNING Maintenance Maintenance Before cleaning and maintenance work, make sure to unplug the unit. (An electric shock or injury may result) Outfl ow grille Cleaning the air outlet (When dirt becomes and issue) Clean the air outlet with a soft brush. Exercise caution not to have dust fall inside the air purifi... - Page 15 Maintenance WARNING • Do not use petrol, benzine, thinner, polishing compound, paraffi n, alcohol, etc. (An electric shock, fi re, or cracking may result) • Do not wash the main body of the unit with water. (An electric shock, fi re, or malfunctioning/ breakage may result) Deodorising fi...
-
Page 16: Separately Sold Part
Maintenance Separately Sold Part Contact the place of purchase. Replacement part Dust collection fi lter (1 piece) Model: BAFP500A • Replace about every 10 years. • Failure to clean parts properly could result in: • Reduced air purifying capacity. • Reduced deodorising capacity. •... -
Page 17: About The Indicator Lamps
WARNING Troubleshooting About the Indicator Lamps Before cleaning and maintenance work, make sure to unplug the unit. (An electric shock or injury may result) Operating/Indicator panel Check the indicator lamps and respond as indicated below. Indicator lamp Cause/Solution This lamp blinks if the deodorising fi lter unit has been detached or MODE lamp is blinking. -
Page 18: Faqs
Troubleshooting FAQs Please check the following before contacting us. Q: Can the dust collection fi lter be cleaned? A: If dirt buildup is severe, please clean with a vacuum cleaner or replace it. Do not attempt to clean it with water, as this may result ►Page 14 in reduced performance of dust collection fi... -
Page 19: Troubleshooting
Troubleshooting Troubleshooting Before making an inquiry or a request for repair, please check the following. If the problem persists, contact the place of purchase. In the event of malfunction during operation If the indicator lamps light up abnormally, or become inoperable, due to a lightning strike etc., remove the power supply plug, wait at least 5 seconds then reinsert the power supply plug and turn the unit on again. - Page 20 Troubleshooting Troubleshooting Phenomenon Check points All the FAN lamps are blinking • Are the pre-fi lters and dust collection fi lter attached? together. These lamps may blink if the unit is operated without a part attached. [If one or more parts are not attached] ...
- Page 21 Troubleshooting Air purifying function Phenomenon Check points Air purifying capacity is • Is the unit positioned in a place where airfl ow cannot reduced reach or surrounded by obstacles? Choose a position that is obstacle-free and from where airfl...
-
Page 22: Specifi Cations
Troubleshooting Specifi cations Model name MC30YVM Power supply 1Ph, 220-240/220-230V, 50/60 Hz Air Purifying Operation mode Turbo Standard Quiet Power consumption (W) Operating sound (dB) Airfl ow rate (m³/h) Coverage area (m²) CADR (m³/h) Unit dimensions (mm) 450(H) x 270(W) x 270(D) Weight (kg) Power supply cord length (m) Made in Malaysia... - Page 24 47000 Sungai Buloh, Selangor Darul Ehsan, Malaysia. Gülsuyu Mahallesi, Fevzi Çakmak Caddesi, Burçak Sokak No:20 34848 Maltepe / İSTANBUL / TÜRKIYE Tel: 0216 453 27 00 Faks: 0216 671 06 00 For manufacturing use only Çağri Merkezi: 444 999 0 3P664949-7 Web: www.daikin.com.tr...
