Air puriﬁer

Floor standing type

Model

MC80ZBFVM3

• Thank you for purchasing this air puriﬁer.

• Please read the operation manual carefully and follow it for correct use.

•

Please read the "Safety Precautions" section before use.

Please keep the operation manual in a safe place for later reference.

Streamer Air Puriﬁer

OPERATIONAL MANUAL

Page 3 - 5

For Internal Use only

3P690892-10 C

Table of Contents

Summary of Contents for Daikin MC80ZBFVM3

Page 1 Air puriﬁer Floor standing type Model Streamer Air Puriﬁer MC80ZBFVM3 OPERATIONAL MANUAL • Thank you for purchasing this air puriﬁer. • Please read the operation manual carefully and follow it for correct use. Page 3 - 5 • Please read the "Safety Precautions" section before use.
Page 3: Table Of Contents
Read First Contents Read First Safety Precautions ..........Usage Precautions ..........Names of Parts and Operations ....... Preparation Before Operation ........13 Operating the Air Puriﬁer via Smartphone ....15 Using the Air Purifying Operation ......18 Changing the Airﬂow rate ......... 19 Operation Operating MODEs ...........
Page 4 Read First Safety Precautions Observe these precautions in order to prevent property damage or injury. The consequences of incorrect use are categorised as follows: WARNING CAUTION Failure to follow these instructions properly Failure to follow these instructions properly may result in personal injury and property may result in personal injury or loss of life.
Page 5 Read First WARNING Observe in order to prevent ﬁre, electric shock or severe injury. During use • Do not use chlorinated or acidic detergents. (Injury may result from degradation or cracking of plastic, or harm may be caused to health from the production of toxic gases) •...
Page 6 Read First Safety Precautions CAUTION Observe in order to prevent electrical leakage, injury or property damage. When moving the unit Hold these grips (2 places) • When picking up the unit to move it, handle the unit with caution. (Be sure to always holds the unit using the correct grip) During use •...
Page 7 Read First Usage Precautions Precautions when using the unit Do not use for special uses such as preservation of artworks or academic works. (Degradation of preserved items may result) Shorten the maintenance period depending on use environment. In case the unit is used at areas where a lot of people go in and out such as hotel or public facilities, please shorten the maintenance period for pre-ﬁlter.
Page 8 Read First Names of Parts and Operations CAUTION Be sure to always holds the unit using the correct grip. (Injury may result from the unit falling) Front Air outlet Louvre (hand-operated) Operating/Indicator panel Page 9 - 12 Grip (for carrying the unit) Service cover Odour sensor Inside the air inlet (right side)
Page 9 Read First Main Removable Parts Attention To prevent malfunction, be sure to only operate the unit with all parts attached. Dust collection ﬁlter (white ﬁlter) Streamer unit cover Page 28, 29, 33 Page 30 Deodorising ﬁlter Service cover (black ﬁlter) Page 14, 28, 33 Streamer units (2 units)
Page 10 Read First Names of Parts and Operations Operating/Indicator Panel Daikin eye Operations and operating status will be notiﬁed by tones. Displays the condition of the air selected with • Operation starts ......2 quick beeps 3 colours: Blue, Orange, Red.
Page 11 Read First AIR MONITOR indicator [white] (estimate values) Indicates what setting is selected with to display. (Settings at time of purchase : μg/m The display on the unit may • μg/m (PM2.5 concentration) differ from that of the other Displays the concentration of PM2.5 in the room in the range of 0 to 500 μg/m .
Page 12 Read First Names of Parts and Operations Operating/Indicator Panel Child Proof Lock AIR MONITOR setting lamps [white] Child Proof Lock is active when is pressed for about 2 seconds. Indicate the AIR MONITOR setting. • μg/m (PM2.5 concentration) (Deactivate by pressing for 2 seconds) •...
Page 13 Read First FAN lamps [white] Indicates the active FAN setting. (4 levels: Quiet, Low, Standard, Turbo) MODE lamps [white] Indicates the MODE in operation. (AUTO FAN, ECONO, PET, CIRCULATOR) Communication lamp, Communication ON/OFF button Used when operating the air purifier via smartphone. •...
Page 14: Preparation Before Operation
Read First WARNING Be sure to stop operation and remove Preparation Before Operation the power supply plug before installation. (Electric shock or injury may result) Checking Accessories Attach to the unit before operation. Deodorising filter ..1 unit Operation manual (beneath the unit)..1 unit Positioning The Unit Before setting up, remove the fixing tape on Pointers for good positioning...
Page 15 Read First Attaching the Deodorising Filter Attach the deodorising filter. Remove the service cover. Insert the short side of the filter into the main unit above 1 Firmly hold the service cover grip and slowly pull the dust collection filter. it towards your direction while pressing the lever.
Page 16: Operating The Air Purifier Via Smartphone
Do not turn on the wireless LAN connection adaptor near automatic control devices such as automatic doors. (Accidents may result due to device malfunction) INFORMATION Hereby, Daikin Malaysia Sdn. Bhd. declares that radio equipment type MC80ZBFVM3 is in compliance with Directive 2014/53/EU. Basic parameters of Wireless LAN connection adaptor What...
Page 17 SSID of the router in use. 4 Launch the app and establish settings. • Open the installed app “DAIKIN Mobile Controller” and operate in accordance with the on-screen guidance. • If using an automatic connection function other than 5 Operate the air purifier.
Page 18 Read First Operating the Air Puriﬁer via Smartphone If router does not have built-in WPS Connect the Air Purifier to the Network Follow the steps below even if you are choosing to not use WPS. 1 Press to activate the wireless LAN connection adaptor. 2 Launch the app and follow the guidance to connect the air purifier and router.
Page 19: Using The Air Purifying Operation
Operation WARNING Do not turn off the unit by unplugging it from the power socket. Operation (Fire due to overheating or electric shock may result) Louvres Open the louvres manually before operation. If you want to change airflow direction Approx. 80˚ (After operation is stopped, louvres Adjust the louvres to your desired position.
Page 20: Changing The Airflow Rate
Operation WARNING Do not turn off the unit by removing the power supply plug during operation. (Fire due to overheating or electric shock may result) Operation Do not operate with deodorising ﬁlter unit, dust collection ﬁlter and other components removed. (breakage or malfunction may result) Changing the Airflow Rate Select the desired FAN setting.
Page 21 Operation MODE Usage and Function Automatic airﬂow rate adjustment FAN setting (Quiet, Low, Standard, High) is automatically adjusted according to the degree of air impurity. Purifying capacity increases as airﬂow rate rises. AUTO FAN If operating sound is a concern, airﬂow rate can be changed. Page 25, 26 ※...
Page 22: Streamer Output Settings
Advanced Settings Changing the Setting Function Can be performed either during PET MODE lamp will light up after blinking. Streamer output operation or while operation is settings stopped. (Normal/Low) Press for about 5 seconds and Lit up Blinking Setting at time of when a short beep sounds, press purchase: Normal According to the current setting, the FAN lamp...
Page 23 Advanced Settings Press Press to change the setting*. Each press cycles between Normal and Low. A short beep sounds with the PET MODE lamp blinking while the FAN lamp blinks according to the new setting. While the lamp is blinking, unplug the power supply plug, wait at least 5 seconds, and then insert the power supply...
Page 24: Active Plasma Ion Output
Advanced Settings Changing the Setting Function Can be performed either during CIRCULATOR MODE lamp will light up after Active Plasma Ion operation or while operation is blinking. output (ON/OFF) stopped. Hold down for about 5 seconds Setting at time of purchase: ON Lit up Blinking...
Page 25 Advanced Settings Press Press to change the setting*. Each press cycles between ON and OFF. A short beep sounds with the CIRCULATOR MODE lamp blinking while the FAN lamp blinks according to the new setting. While the lamp is blinking, unplug the power supply plug, wait at least 5 seconds, and then insert the power supply...
Page 26: Monitoring Mode Within Auto Operation And Econo
Advanced Settings Changing the Setting Function The FAN lamp (Quiet) blinks, then lights up. Can be performed either during Monitoring mode operation or while operation is within AUTO stopped. Operation and ECONO MODE Press for about 5 seconds and (ON/OFF) when a short beep sounds, press Setting at time of while continuing to hold...
Page 27 Advanced Settings Press to change the setting*. Press MODE Each press cycles between ON and OFF. A short beep sounds, the FAN lamp (Quiet) blinks, and the ECONO MODE lamp changes to the following display according to the setting. Lit up Unlit While the lamp is blinking, unplug the power supply plug,...
Page 28: Quick Guide For Maintenance
Maintainance WARNING Before cleaning and maintenance work, be sure to unplug Maintenance the unit. (An electric shock or injury may result) Quick Guide for Maintenance Please refer to respective page for the method to install or remove each part during maintenance. Unit When dirt becomes an issue Wipe...
Page 29: Dust Collection Filter
Maintainance WARNING • Do not use gasoline, benzine, thinner, polishing compound, parafﬁn, alcohol, etc. (Cracking, electric shock, and ignition of ﬁre may result) • Do not wash the unit with water. (Electric shock and ﬁre or malfunctioning may result) Filter Fixing Unit Page 14 When dirt becomes an issue Vacuum clean...
Page 30: Replace
Maintainance WARNING Before cleaning and maintenance work, be sure to unplug Maintenance the unit. (An electric shock or injury may result) Dust Collection Filter Replace Attention Be sure to operate with the dust collection filter, deodorising filter and filter fixing unit attached. If the unit is operated without the filters attached, malfunction may result.
Page 31: Streamer Unit Replace
Maintainance Streamer Unit Do not soak or wash Replace If the Streamer lamp blinks Replacement timing Estimated lifespan is about 10 years in the case where unit is operated for 24 hours everyday using AUTO FAN MODE at a house where 5 cigarettes are burned everyday. However, depending on the location where the unit is used (places where oils are present, or dust and humidity is abundant, or sprays and chemical agents are used, etc.), replacement timing may become shorter.
Page 32: When Not Using The Unit For A Prolonged Period
Maintainance WARNING Make sure to stop operation and unplug the power supply plug Maintenance before maintenance. (May cause electric shock or injury) When Not Using the Unit for a Prolonged Period Unplug the power supply. Clean the parts. Page 27, 28 •...
Page 33: State Of The Air Monitor Indicator And Their Meanings
Troubleshooting State of the AIR MONITOR Indicator and Their Meanings In case the AIR MONITOR indicator blinks and an error code appears, unplug the power supply plug, wait at least 5 seconds, then insert the power supply plug again and operate the unit. If an error code still appears, please refer to the procedures below: 3 long beeps AIR MONITOR Indicator...
Page 34: Faqs
Troubleshooting FAQs Please check the following before contacting the place of purchase. Q: The value displayed as the PM2.5 concentration is always low and seems unresponsive, or the sensitivity of the PM2.5 sensor seems to be poor... A: Perform periodic cleaning of the PM2.5 sensor as dirt on its lens can lead to poor sensitivity.
Page 35: Troubleshooting
Troubleshooting Troubleshooting Before making an inquiry or a request for repair, please check the following. If the problem persists, contact the place of purchase. In the event of malfunction during operation. If the indicator lamps light up, or become inoperable, due to a lightning strike etc., remove the power supply plug, wait at least 5 seconds then re-insert the power supply plug and turn the unit ON again.
Page 36 The PM2.5 concentration value Contact the place of purchase. displayed with the AIR MONITOR indicator is always “---”, and Daikin eye remains blue and does not change. There is an odour but the odour • Did an odour already exist around the time you inserted the power...
Page 37 Troubleshooting Air purifying function Phenomenon Check points Air purifying capacity is reduced • Is the unit surrounded by obstacles, or positioned in a place where airflow cannot reach? Choose a position that is obstacle-free and from where airﬂow can reach all areas of the room. •...
Page 38 The unit turns on and off on its • Is someone else operating the unit with a smartphone? • Did you set the schedule timer using “DAIKIN Mobile Controller”? is pressed on the unit, the Communication lamp will turn off, and operation via smartphone and the schedule timer will be disabled.
Page 39: Specifications
Troubleshooting Speciﬁcations Model name MC80ZBFVM3 Power supply Single phase 50Hz 220-240V / 60Hz 220-230V Air Purifying Operation mode Turbo Standard Quiet Power consumption (W) Operating sound (dB) Airﬂow rate (m³/h) Coverage area (m²) External dimensions (mm) 630(H) × 315(W) × 315(D)
Page 40: Separately Sold Parts
Troubleshooting Separately sold parts Replacement Part Dust collection ﬁlter Caster (4 units) (1 unit) Part no: BAFT501A Part no: KKS080B41 • Replace in about 10 years. • Installation location is changed manually. • Catches dust and pollen. • Failure to maintain part properly may result in: •...
Page 41 ............................................... 13 ........15 ..........18 ............19 ........................21 ....................23 PM2.5 ......................27 ............. 29 ............. 30 ............31 ...... 32 AIR MONITOR ..........................34 ............... 38 ..............
Page 42 220-240V...
Page 44 ─ ─ ─ ─ ─...
Page 45 • • 2000 ─ ─...
Page 46 9 - 12 PM2.5 9, 23, 24, 27, 33, 35...
Page 47 HEPA 28, 29, 33 14, 28, 33 14, 28 SSID/KEY...
Page 48 Daikin eye • ......2 • ......1 • ......1 • “μg/m ” • ... 3 PM2.5 • ......... 3 • “°C” (°C) ≤ 10 11-17 18-28 29-35 ≥ 38 21, 22 • “%” 0-20 21-29 30-60 61-70 71-100 •...
Page 49 AIR MONITOR μg/m • μg/m PM2.5 • PM2.5 0 ~ 500 μg/m 1 μg/m PM2.5 500 μg/m “HI” • PM2.5 [– – –] AIR MONITOR • °C 0°C 39°C 1°C 0°C “0” 39°C “39” AIR MONITOR • [– – –] •...
Page 50 AIR MONITOR AIR MONITOR • μg/m (PM2.5 • °C ( • % ( • AIR MONITOR PM2.5 •...
Page 51 • • 16 - 17 19, 20...
Page 52 ..1 ..1 • • • • • • • ※...
Page 53 • • • • • •...
Page 54 IEEE802.11b/g/n (HT20) 2.4GHz 13CH : WPA-PSK (AES), WPA2-PSK (AES) : DHCP : IPv4 HTTP SSID/KEY 12, 17 Daikin Malaysia Sdn. Bhd. MC80ZBFVM3 2014/53/EU 2412 ~ 2472 IEEE 802.11b/g/n (HT20) 13ch 17.21 (11b) / 16.16 (11g) / 16.15 (11n) / 100...
Page 55 • Android • • • DAIKIN Mobile Controller SSID • • • • • • • • • Wi-Fi • “Wi-Fi” SSID • • “DAIKIN Mobile Controller” •...
Page 56 • SSID SSID SSID D-MOBILE iOS App Store Android Play Store • • • • • • MODE • • •...
Page 57 80˚ 70˚ • • • •...
Page 58 • MODE •...
Page 59 25, 26 ※ • (※1) ※ 14.3Wh 7.4Wh 6.9Wh 12.4m² • • • • PM2.5 25, 26 • •...
Page 60 •...
Page 61 • •...
Page 62 • • PM2.5 PM2.5 •...
Page 63 • •...
Page 64 MODE MODE • MODE MODE • MODE...
Page 65 MODE MODE • •...
Page 66 • • • PM2.5 • • • • • • • •...
Page 67 • • • • • • • • • • • • 40℃ • • • • • •...
Page 68 • • • JEM1467 • • •...
Page 69 3 - 6 • • • • •...
Page 70 27, 28 •...
Page 71 AIR MONITOR AIR MONITOR AIR MONITOR...
Page 72 PM2.5 PM2.5 PM2.5 PM2.5 PM2.5 23, 24 PM2.5 PM2.5 PM2.5 28, 29 28, 29...
Page 73 • • • 21, 22 • • • • • • 16 - 17 • • 16 - 17 •...
Page 74 • PM2.5 • PM2.5 • PM2.5 • PM2.5 • PM2.5 • AIR MONITOR PM2.5 “---” PM2.5 AIR MONITOR PM2.5 “---” Daikin eye • • • • • 21, 22 • 25, 26 • •...
Page 75 • • • • • • • • • 28, 29 • • • • AIR MONITOR • • •...
Page 76 • AIR MONITOR • 16, 17 • • • • “DAIKIN Mobile Controller” • • • • 21, 22 • • •...
Page 77 MC80ZBFVM3 50 Hz 220-240 V / 60Hz 220-230 V 630( ) × 315( ) × 315( ) • 50Hz 220–240V 60Hz 220–230V. • 1W (*2) • A 70 dB (A) JEM1467...
Page 78 : BAFT501A : KKS080B41 • • • • • • • • • •...
Page 80 • In the event that there is any conflict in the interpretation of this manual and any translation of the same in any language, the English version of this manual shall prevail. • The manufacturer reserves the right to revise any of the specification and design contain herein at any time with out prior notification.
