Introduction; Technical Specifications - Symbol IEEE 802.11A/B Hardware Quick Reference Manual

Introduction

The 5030 Access Port provides area coverage to 802.11a/b (when configured with 802.11a/b
radios) wireless network devices. The Access Port includes different placement options, allowing
best placement for it to operate within its optimum range.
The standard mounting base allows the unit to be secured to a wall by the use of two screws and
wall anchors (included, use if needed). Use the mounting bracket as a template for marking the
location of the mounting holes. The above/below ceiling and wall mounting options allow the unit
to attach to the specified surfaces using only the mounting hardware provided. The Access Port
receives power and transfers data through the same (CAT-5) cable or through a Symbol approved
power supply.

Technical Specifications

Operating Voltage
Operating Current
Peak Current
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Altitude
Drop
MTBF
Electrostatic Discharge
48 vdc (typical)
36 vdc to 57 vdc (range)
10 mA to 150 mA
250 mA
-20°C to 50°C
5% to 85%
-40° to 70°C
85%
8,000 feet (operating max)
15,000 feet (storage max)
30 inches (to concrete)
27,000 hrs
+/-15 kV (air discharge)
+/-8 kV (contact discharge)
+/-2 kV (pin discharge)
- 5 -Model 5030 Access Port Quick Reference Guide DRAFT V3
