TOWING POINTS

Front Towing Point
1
E241979
1. Push the cover.
2. Release the cover.
E241980
3. Install the recovery hook.
EcoSport (CBW) India, Vehicles Built From: 14-08-2017, GN15-19G219-ZCA enIND, Edition date: 201708, First Printing

Towing

Rear Towing Point
E241981
1. Push the cover.
2. Release the cover.
3
E241982
3. Install the recovery hook.
The recovery hook may be in the following
locations:
• Inside temporary mobility kit.
• Inside Jack and tools storage tray.
You must carry the recovery hook in your
vehicle at all times.
Note: The recovery hook has a left-hand
thread. Turn it counterclockwise to install it
and make sure that it is fully tightened.
Failure to do so could result in the recovery
hook becoming loose.
Note: If your vehicle has a tow bar, use this
to tow other vehicles.
