Napa 791-6620 E Operating Manual & Parts List

BEFORE USING THIS DEVICE, READ THIS
MANUAL COMPLETELY AND THOROUGHLY,
UNDERSTAND ITS OPERATING
PROCEDURES, SAFETY WARNINGS AND
MAINTENANCE REQUIREMENTS.
It is the responsibility of the device owner to make sure all personnel
read this manual prior to using the device. It is also the responsibility
of the device owner to keep this manual intact and in a convenient
location for all to see and read. If the manual or product labels are lost
or not legible, contact NAPA for replacements. If the operator is not
fluent in English, the product and safety instructions shall be read to
and discussed with the operator in the operator's native language by
the purchaser/owner or his designee, making sure that the operator
comprehends its contents.
SPECIFICATIONS
Low Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1/4"
Raised Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 .5"
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61"
Chassis Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-3/4"
Chassis Width w/ Swivel Caster Bracket . . . . . . . . . . 18 .375"
Chassis Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 .5"
Handle Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45-3/4"
Saddle Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7/8"
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 364 lbs .
791-6620 E
10 TON AIR/HYDRAULIC
WARNING
• Read, study, understand and follow all instructions before op-
erating this device. • Inspect the jack before each use. Do not
use jack if damaged, altered, modified, in poor condition, leak-
ing hydraulic fluid, or unstable due to loose or missing compo-
nents. Make corrections before using. • Lift only on areas of the
vehicle as specified by the vehicle manufacturer. • Wear eye
protection that meets ANSI Z87.1 and OSHA standards (user
and bystanders). • Do not use jack beyond its rated capacity.
Do not shock load • This is a lifting device only. Immediately
after lifting, support the vehicle with jack stands capable
of sustaining the load before working on the vehicle • Use
only on a hard level surface free from obstructions so the jack
is free to reposition itself during lifting and lowering operations.
• Center load on saddle. Be sure setup is stable before working
on vehicle. • Do not move or dolly the vehicle while on the jack.
• Do not use any materials that may serve as risers, spacers or
extenders between the stock lifting saddle and the load. • Do
not use any adapters that replace the stock lifting saddle unless
approved or supplied by the jack manufacturer. • Do not use (or
modify) this product for any other purpose than that for which it
was designed without consulting the manufacturer's authorized
representative. • Always lower the jack slowly and carefully.
Failure to heed these warnings may result in serious or fatal
personal injury and/or property damage.
WARNING: This product can expose you to chemicals
including nickel, which is known to the State of
California to cause cancer and birth defects or other
reproductive harm. For more information go to www.
P65Warnings.ca.gov.
1
MODEL # 791-6620 E
SERVICE JACK
ASME PASE-2014
rev. 03/22/18
