Napa 791-6570 D Manual

BEFORE USING THIS DEVICE, READ THIS
MANUAL COMPLETELY AND THOROUGHLY,
UNDERSTAND ITS OPERATING
PROCEDURES, SAFETY WARNINGS AND
MAINTENANCE REQUIREMENTS.
It is the responsibility of the device owner to make sure all personnel
read this manual prior to using the device. It is also the responsibility
of the device owner to keep this manual intact and in a convenient
location for all to see and read. If the manual or product labels are lost
or not legible, contact NAPA for replacements. If the operator is not
fluent in English, the product and safety instructions shall be read to
and discussed with the operator in the operator's native language by
the purchaser/owner or his designee, making sure that the operator
comprehends its contents.
SPECIFICATIONS
Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Ton
Low Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6"
Raised Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22"
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55-1/2"
Chassis Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3/4"
Chassis Width with Swivel Caster Bracket . . . . . . . . . 14-3/4"
Handle Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45-3/4"
Saddle Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3/4"
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232 Lbs
791-6570 D
• Read, study, understand & follow all instructions before
using. • Inspect the jack before each use. Do not use if
damaged, altered, modified, in poor condition, leaking
hydraulic fluid or unstable due to loose or missing
components. Make corrections before using. • Use only
on a hard level surface free from obstructions so the
jack is free to reposition itself during lifting and lowering
operations. • Lift only on areas of the vehicle as specified
by the vehicle manufacturer. • User and bystanders must
wear eye protection that meets ANSI Z87.1 and OSHA
standards. • Do not use jack beyond its rated capacity.
Do not shock load. • This is a lifting device only.
Immediately after lifting, support the vehicle with jack
stands capable of sustaining the load before working
on the vehicle. • Center load on saddle. Be sure setup is
stable before working on vehicle. • Do not move or dolly
the vehicle while on the jack. • Do not use any materials
that may serve as risers, spacers or extenders between the
stock lifting saddle and the load. • Do not use any adaptors
that replace the stock lifting saddle unless approved or
supplied by the jack manufacturer. • Always lower the
jack slowly and carefully. • Do not use (or modify) this
product for any other purpose than that for which it was
designed without consulting the manufacturer's authorized
representative. • This product contains chemicals known
to the State of California to cause cancer and birth defects
or other reproductive harm. Wash hands thoroughly after
handling. • Failure to heed these warnings may result in
serious or fatal personal injury and/or property damage.
1
MODEL # 791-6570 D
5 TON CAPACITY
SERVICE JACK
WARNING
06/07/16
