Adjusting the screen display

Manual screen adjustment

Adjustments can be made using the On Screen Display
(OSD) Menu provided.
1. Display an image that makes the entire screen very
bright. If using Windows, you can open and use the
Adjustment Pattern on the accompanying Utility Disk.
(p. 19)
2. Press the MENU button.
The WHITE BALANCE Menu will be displayed.
At this point relevant menu options can be adjusted.
Each time the MENU button is pressed the next menu
is selected. (WHITE BALANCE
OSD Menu disappears)
Notes:
• The OSD Menu automatically disappears
approximately 30 seconds after the last command.
• This explanation is based on use of the Adjustment
Pattern (for Windows) to make adjustments
WHITE BALANCE Menu
Notes:
• On settings other than [STD] not all graduations can
be displayed. To display all graduations, set to [STD].
• Use the
[WARM] or [USER].
• Selecting USER will display the setting values for [R-
CONTRAST], [G-CONTRAST] and [B-CONTRAST],
in order to make fine adjustments.
• Use the SELECT button to select [R-CONTRAST],
[G-CONTRAST] and [B-CONTRAST].
• To go to the next menu:
COOL . . . . . Color tone bluer than standard
MODE SELECT
• . . . . . . . Color tone slightly bluer than standard
STD . . . . . . . Color tone standard setting
• . . . . . . . Color tone slightly redder than standard
WARM . . . . . Color tone redder than standard
USER
R-CONTRAST . . .
G-CONTRAST . . .
B-CONTRAST . . .
23
(when using a digital signal)
buttons to select [COOL], [·], [STD], [·],
MENU button
button for blue-green
button for red
button for purple
button for green
button for yellow
button for blue
