Copyright © Euro-Pro Operating LLC 2006
3 Speed Electronic Sweeper
with No Touch Dust Cup
OWNER'S MANUAL
Model: V1917
8.4 Volt DC
U.S :
EURO-PRO Operating LLC
94 Main Mill Street, Door 16
Plattsburgh, NY 12901
1 (800) 798-7398
www.sharkcompany.com
Canada : EURO-PRO Operating LLC
4400 Bois Franc
St-Laurent, QC H4S 1A7
Advertisement
Table of Contents
Related Manuals for Shark V1917
Summary of Contents for Shark V1917
- Page 1 Copyright © Euro-Pro Operating LLC 2006 3 Speed Electronic Sweeper with No Touch Dust Cup OWNER’S MANUAL Model: V1917 8.4 Volt DC U.S : EURO-PRO Operating LLC Canada : EURO-PRO Operating LLC 94 Main Mill Street, Door 16 Plattsburgh, NY 12901 1 (800) 798-7398 www.sharkcompany.com...
-
Page 3: Important Safeguards
Model V1917 ONE (1) YEAR LIMITED WARRANTY EURO-PRO Operating LLC warrants this product to be free from defects in material and workmanship for a period of one (1) year from the date of the original purchase, when utilized for normal household use, subject to the following conditions, exclusions and exceptions. -
Page 4: Troubleshooting Guide
PARTS AND COMPONENTS Upper Handle Telescopic Tube No Touch Empty Button Lower Handle Extension Tube Lower Handle Charging Light Indicator On/Off Switch Charging Adapter: Only Use KA12D120015023U Charging Jack 10. Transparent Brush Cover 11. Rotating Brush 12. Edging Tool 13. Gear Box 14. - Page 5 OPERATING INSTRUCTIONS Slip the belt over the brush bar cap. Insert the brush bar into the slot. (Fig. 14) 10. Insert the gear box tabs into the tab slots and push down until it clicks into place. 11. To replace the squeegee, follow instructions above for removing the gear box and slide the squeegee out from left to right.
- Page 6 OPERATING INSTRUCTIONS Charging Instructions Connect the charger plug to the charging jack or hole on the side of the sweeper. Plug the charging adapter into the wall outlet. (120V., 60Hz.) Use only charger KA12D075015023U. (Fig. 2) Charging Indicator This cordless sweeper is powered by Ni-Cd batteries. Before first use, they must be charged for a minimum 20 hours.
-
Page 7: Cleaning The Dust Container
OPERATING INSTRUCTIONS Cleaning The Dust Container To achieve the best performance, empty the dust container after each use. Press the dust cup release lever with your foot. (Fig. 9) Note : Be careful not to accidentally turn the unit “On” Fig. - Page 8 OPERATING INSTRUCTIONS Carefully lift out the battery pack and disconnect the wire terminals by pulling apart the wire terminal connectors. Remove the battery pack from the unit. (Fig. 5) Wire Terminal Connector Connect the wire terminal connector from the unit to the wire terminal connector of the new battery pack, and replace the battery pack into the unit.
