Cine Reflector as open face reflector
When the Cine Reflector is used without lenses, it is recommended to use a FROSTED glass
cover for the lamp/flash head.
1. Fit a FROSTED glass cover in place on the lamp/flash head.
2. Unlock the Locking Clasp [2] on the Cine Reflector.
3. Slide the lamp/flash head into the reflector. Use the zoom scale on the lamp/flash head
to place the head in the position for the desired beam angle (35-105°).
4. Secure the lamp/flash head by locking the Locking Clasp [2] on the reflector.
Cine Reflector in combination with PaR reflector attachment and lenses
10
When the Cine Reflector is used with lenses, it is recommended to use the PAR reflector
attachment and a CLEAR glass cover for the lamp/flash head.
1. Fit a CLEAR glass cover in place on the lamp/flash head.
2. Open the Locking Bracket [6] on the Cine Reflector by first pushing the spring loaded
pin on the side of the bracket and then raising the bracket.
3. Fit the PAR reflector in place:
a. Orientate the PAR reflector with its loop [5] towards the Locking Bracket [6] and then
slide the reflector into the innermost position in the Accessory Brackets [7].
b. Turn the PAR reflector anti-clockwise until the loop is directed straight upwards.
4. Close the Locking Bracket [6]. Ensure that the bracket in locked in place by the spring.
5. Unlock the Locking Clasp [2] on the Cine Reflector and slide the lamp/flash head all the
way into the reflector until it firmly stops. Secure the head by locking the Locking Clasp
[2].
6. Open the Locking Bracket [6] again, see step 2.
7. Slide the desired accessories in place in the Accessory Brackets [7]. For recommended
accessory combinations, see section Accessory Combinations above.
8. Ensure that all the Accessory Loops [5] are orientated upwards and to the left of the
Locking Bracket [6], to allow the accessories to be turned if needed.
9. Close the Locking Bracket [6], see step 4.
