Specifications

Mic Offset Range
-12 to 21 dB (In 1 dB steps)
Battery Type
Shure SB920 Rechargeable Li-Ion
Battery Runtime
@ 10 mW
Shure SB920 up to 9 hours
See Battery Runtime Chart
Dimensions
254 mm x 51 mm (10.0 in. x 2.0 in.) L x Dia.
Weight
179 g (6.3 oz.), Without Battery
Housing
Cast Aluminum
Operating Temperature Range
-18°C (0°F) to 63°C (145°F)
Note: Battery characteristics may limit this range.
Storage Temperature Range
-29°C (-20°F) to 74°C (165°F)
Note: Battery characteristics may limit this range.

Audio Input

Configuration
Unbalanced
Maximum Input Level
1 kHz at 1% THD
145 dB SPL (SM58), typical
Note: Dependent on microphone type
RF Output
Antenna Type
Dual Band Helical
Occupied Bandwidth
<200 kHz
Modulation Type
Shure Axient Digital Proprietary
Power
2 mW, 10 mW, 40 mW
See Frequency Range and Output Power table, varies by region
ShowLink
Network Type
IEEE 802.15.4
Antenna Type
Zigbee Dual Conformal
Frequency Range
2.40 to 2.4835 GHz (24 Channels)
RF Output Power
10 dBm (ERP)
varies by region

Frequency Bands and Transmitter RF Power

Frequency Range
Band
(MHz)
G53 470 to 510
G54 479 to 565
G55† 470 to 636
G56◇ 470 to 636
G57△ 470 to 616*
G62 510 to 530
H54 520 to 636
K53† 606 to 698
K54△ 606 to 663**
K55 606 to 694
K56 606 to 714
K57 606 to 790
K58 622 to 698
L54 630 to 787
R52† 794 to 806
JB 806 to 810
X55 941 to 960
*with a gap between 608 to 614 MHz.
**with a gap between 608 to 614 MHz and a gap between 616 to 653 MHz.
***power delivered to the antenna port.
†operation mode varies according to region. In Brazil, High Density mode is used.
△Output power limited to 10 mW above 608 MHz.
◇Korea defines power as conducted (ERP) which is 1dB less then declared in table.
13
RF Power (mW)***
2/10/40
2/10/20
2/10/40
2/10/40
2/10/40
2/10/40
2/10/40
2/10/40
2/10/40
2/10/40
2/10/40
2/10/40
2/10/40
2/10/40
2/10/40
2/10
2/10/40
