Jeep Wrangler
SBV-10-WRA
Pre-loaded 10" Subwoofer System
Installation Manual
Model: 4-Door Wrangler Unlimited
Year: 2007-2018 JKU
* The specified vehicles have been tested and have met compatibility specs at the time of testing. Compatibility is
not guaranteed if the manufacturer has made production changes to the listed vehicles above.
Disconnect the battery before beginning the installation.
Failure to do so can lead to electric shock, injury or damage to equipment.
Mandatory
Introduction
Congratulations on purchasing the SBV-10-WRA. This installation manual is designed to take you through the
step-by-step installation of the SBV-10-WRA into a 2007 - 2018 Jeep Wrangler Unlimited. Please familiarize
yourself with the owners manual and if you still have additional questions please call 1-800-TECH-101.
Note
˜ Design and specifications are subject to change without notice for improvement.
To Ensure Safe Use, Always Follow These Precautions
˜ The installation of this product requires specialized skills and experience. We recommend that you have the
product installed by an Alpine authorized dealer.
˜ Before you use this product, be sure to carefully read this installation manual and the separate user's manual
so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as
a result of failure to follow the instructions in the manuals.
˜ This manual includes a number of symbols that are intended to help you use the product safely, to prevent
harm to you and others, and to protect against damage to property. These symbols and their meanings are
listed below. Make sure you fully understand these symbols before you begin reading the main text.
Explanations of Injury and Damage That May Result from Incorrect Use
Ignoring the content marked by this indication and using the product incorrectly may
Warning
lead to death or serious injury.
Ignoring the content marked by this indication and using the product incorrectly may
Caution
lead to injury or property damage.
UNLIMITED
Jeep
˜ 1/6
