- Page 1 Business Solutions User Manual ENS202v2 / ENS202EXTv2 version 1.0 N300 2.4GHz Outdoor AP...
- Page 2 IMPORTANT To install this Access Point please refer to the Quick Installation Guide included in the product packaging.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Product Overview..............4 Chapter 7 2.4 GHz Wireless................34 Key Features/Introduction..............5 Wireless Settings..................35 System Requirements................6 2.4 GHz Wireless Network..............36 Package Contents..................6 Wireless Security..................39 Software Features................7 Fast Roaming..................42 Physical Interface...................8 Wireless Traffic Shaping..............44 Chapter 2 Before You Begin............... 9 Wireless MAC Filteing.................43 Computer Settings................ -
Page 4: Chapter 1 Product Overview
Chapter 1 Product Overview... -
Page 5: Key Features/Introduction
Introduction Key Features • Supports IEEE802.11b/g/n wireless standards with up to 300 Mbps data rate on 2.4GHz band • Two detachable 5 dBi 2.4 GHz Omni-dipole antennas with ENS202EXT. • Can be used with included power adapter or via PoE with Proprietary 24V. -
Page 6: System Requirements
System Requirements Package Contents The ENS202/ENS202EXT package contains the following The following are the Minimum System Requirements in order to configure the device. items:* • ENS202/ENS202EXT Access Point • Computer with an Ethernet interface or wireless network capability. • 2 detachable 5 dBi 2.4 GHz Omni Antenna-ENS202EXT only •... -
Page 7: Software Features
Software Features Multicast Supported Standard: Auto Reboot IEEE802.11b/g/n on 2.4 GHz Obey Regulatory Power IEEE802.3u(100BASE-TX)/IEEE802.3(10BASE-T) Security Operation Modes WPA2 Personal Access Point WPA2 Enterprise Client Bridge Hides SSID in beacons MAC address filtering, up to 32 MACs WDS Detail Wireless STA (Client) connection list WDS AP Https Support WDS Bridge... -
Page 8: Physical Interface
Physical Interface Dimensions and Weights With Antenna:100mm(4”)*37.5mm(1.375”)*205mm(8”)(W*D*H) Weight: 242g Without Antenna:100mm(4”)*37.5mm(1.375”)*189mm(7.375”) (W*D*H) Weight: 275g 1 2.4 GHz Antennas: Detachable 5 dBi 2.4 GHz Omni-ENS202EXT only 2 LAN Port (Proprietary 24V PoE Input): Ethernet port for RJ-45 cable. 3 LED Indicators: LED lights for Power, LAN Port, 2.4 GHz Connection 4 Mounting Holes: Using the provided hardware, the ENS202EXT can be attached to a wall or pole. -
Page 9: Chapter 2 Before You Begin
Chapter 2 Before You Begin... -
Page 10: Computer Settings
Computer Settings Windows XP/Windows 7/Windows 8/Windows 1b. Move your mouse to the lower right hot corner to display the Charms Bar and select the Control Panel in Windows 8 OS. In order to use the Access Point, you must first configure the TCP/IPv4 connection of your Windows OS computer system. - Page 11 4. Select Internet Protocol Version 4 (TCP/IPv4) and then 2a. In Windows XP, click Network Connections. select Properties. 2b. In Windows 7/Windows 8/Windows 10, click View Network Status and Tasks in the Network and Internet section, then select Change adapter settings. 3.
- Page 12 Note: Ensure that the IP address and Subnet mask are on the same subnet as the device. For example: ENH220EXT IP address: 192.168.1.1 PC IP address: 192.168.1.2 – 192.168.1.255 PC Subnet mask: 255.255.255.0...
- Page 13 Apple Mac OS X 4. In Configure IPv4, select Manually. 1. Go to System Preferences (Which can be opened in the 5. Enter an IP address that is different from the Access Applications folder or selecting it in the Apple Menu). Point and Subnet mask then press OK.
-
Page 14: Hardware Installation
Hardware Installation 1. Connect one end of the Ethernet cable into the LAN port This diagram depicts the hardware configuration. (PoE) of the AP/ Bridge and the other end to the PoE port on the PoE adapter. 2. Connect the Power cord with the PoE Adapter and plug the other end into an electrical outlet. -
Page 15: Mounting The Ap
Mounting the ENS202/ENS202EXT Using the provided hardware, the ENS202EXT can be attached to a wall or a pole. The height should not exceed 2 meter. 1. Wall Mounting Kit 2. Pole Mounting Strap (Φ66*12.6 mm) (Anchors: Φ5.5*18 mm & Bolts: Φ8*25mm) Bolts Anchors... - Page 16 To attach the ENS202EXT/ENS202EXT to a wall To attach the ENS202EXT to a pole using the using wall mounting kit. provided pole mounting kit: A. Determine where the Access Point to be placed and A. Thread the open end of the Pole Strap through the two stick the Adhesive label on the surface.
-
Page 17: Chapter 3 Configuring Your Access Point
Chapter 3 Configuring Your Access Point... -
Page 18: Default Settings/Web Configuration
Configuring Your Access Point This section will show you how to configure the device 2. The default username and password are admin. using the web-based configuration interface. Once you have entered the correct username and password, click the Login button to open the web-base Default Settings configuration page. -
Page 19: Chapter 4 Building A Wireless Network
Chapter 4 Building a Wireless Network... -
Page 20: Access Point
Before starting to configure this Access Point, you may realize the used scenario under varied operating modes.The AP has the ability to operate in various modes. This chapter describes purpose of different operating modes and lists down the operating modes for outdoor Access Points. Access Point Mode In Access Point Mode, AP behaves likes a central connection for stations or clients that support IEEE 802.11ac/a/b/g/n networks. -
Page 21: Clien Bridge Mode
Client Bridge Mode The AP can be used as a centralized Outdoor Access Point with which other EnGenius Wireless 2.4 or 5 GHz Outdoor Client Bridges can associate; leveraging the long-range capability of their internal high-gain directional antennas, resulting in a very cost-effective solution to expand a company network over a multiple building campus. -
Page 22: Wds Ap Mode
WDS AP Mode The AP also supports WDS AP mode. This operating mode allows wireless stations to connect with Access Point via using WDS technology. In this mode, configure the MAC addresses or SSIDs in both Access Points to enlarge the wireless area by enabling WDS Link settings. -
Page 23: Wds Bridge Mode
WDS Bridge Mode In WDS Bridge Mode, the Accesss Point can wirelessly connect different LANs by configuring the MAC address and security settings of each Access Points. Use this operating mode when two wired LANs located a small distance apart want to communicate with each other. -
Page 24: Wds Station Mode
WDS Station Mode WDS station (WDS STA) mode expands the WDS by receiving a wireless signal/service and sharing it through the Ethernet port. With WDS STA mode. Access Point WDS AP on both 5 GHz or 2.4 GHz Access Point Access Point WDS Station WDS Station... -
Page 25: Chapter 5 Status
Chapter 5 Status... -
Page 26: Overview
Overview Save Changes Device Status Clicking the Change on the right top,this page lets you save Clicking the Device Status link under the Overview menu and apply the settings shown under Unsaved changes list, shows the status information about the current operating or Revert the unsaved changes and revert to the previous mode. - Page 27 The Memory Information section shows usage of memory Note: Profile Settings are only applicable in Access Point such as Total Available, Free, Cached, Buffered and WDS AP modes. • The LAN Information section shows the Local Area Network settings such as the LAN IP Address, Subnet mask, Primary DNS Address, Secondary DNS Address, status of DHCP client, and status of Spanning Tree protocol (STP).
- Page 28 The Statistics section shows Mac information such as • SSID, MAC address, RX and TX.
-
Page 29: Connection
Connection Realtime 2.4 GHz Connection List Realtime The Realtime section contains the following options: Click the connection link under the Overview menu displays the connection list of clients associated to the ENS202EXT CPU Loading: 3 minutes CPU loading percentage 2.4 GHz, along with the MAC addresses and signal strength information, it displays current loading, average loading for each client. - Page 30 Traffic Loading: 2.4GHz and Ethernet port inbound and outbound traffic by current, average and peak time. Realtime Connection (Pkts): Overview on current active network connections. It displays UDP and TCP packets information and other connection status. UDP connections curve is in blue; TCP connection curve is in green;...
-
Page 31: Chapter 6 Network
Chapter 6 Network... -
Page 32: Basic Ip Settings
Basic-IP Settings IPv4/IPv6 Settings IP Network Settings: Select whether the device IP address will use a static IP address specified in the IP address field This page allows you to modify the device’s IP settings. or be obtained automatically when the device connects to a DHCP server. -
Page 33: Spanning Tree Protocol Setting
Spanning Tree Protocol (STP) Settings Spanning Tree Status: Enables or disables the Spanning Tree function.Default is Disable. This page allows you to modify the Spanning Tree settings. Enabling the Spanning Tree protocol will prevent network Hello Time: Specifies Bridge Hello Time in seconds. This loops in your LAN network. -
Page 34: Chapter 7 2.4 Ghz Wireless
Chapter 7 2.4 GHz Wireless... -
Page 35: Wireless Settings
Wireless Wireless Settings *The model name will be varied by different models. Device Name: Enter a name for the device. The name you type appears in SNMP management. This name is not the SSID and is not broadcast to other devices. -
Page 36: 2.4 Ghz Wireless Network
Client Bridge on Client Premise Equipements (CPE). to obey regulartory power of each country. Meanwhile, EnGenius outdoor devices also support WDS Bit Rate: 2.4GHz is default 1 Mbps, the range can modes for peer to peer or peer to multi-peer connections. - Page 37 Client Limits: Limits the total number of clients on this radio. Once setting the ceiling of client numbers, the maximum assocaited client devices will be restricted at this number. Multicast to Unicast Stream Converison: Stream conversion is default enable and multicast AP Detection: AP Detection can select the best channel to use by scanning nearby areas for Access Points.
- Page 38 2.4 GHz SSID Profile Client Isolation: Click the appropriate radio button to enable this function for allowing or preventing communication between client devices. VLAN Isolation: Restrict clients communicating with different VIDs by selecting the radio button. Current Profile: You can configure up to four (4)different ID: Specifies the VLAN tag for each profile.
-
Page 39: Wireless Security
Wireless Security The Wireless Security section lets you configure the AP’s security modes Secuirty Mode: Including WPA2-PSK, WPA2-Enterprise. We strongly recommend you to use WPA2-PSK mode. - Page 40 * Setting of WPA2-PSK: * Setting of WPA2-Enterprise (Pre-Shared Key): Encryption: Default is AES.Please ensure that your wireless clients use the same settings. Encryption: Default is AES.Please ensure that your wireless clients use the same settings. Passphrase: Wireless clients must use the same Key to associate the device.
- Page 41 Radius Settings NAS-ID: Enable or disable accounting feature. NAS-Port: Enable or disable accounting feature. NAS-IP: Enable or disable accounting feature. Radius Accounting Radius Accounting: Enable or disable accounting feature. Radius Accounting Server: Enter the IP address of the Radius accounting server. Radius Accounting Port Enter the port number used for connections to the Radius accounting server.
-
Page 42: Fast Roaming
Fast Roaming Enable the function to serve mobile client devices that roam from Access Point to Access Point. Some applications running Enable Fast Roaming: Enable or disable fast roaming on Client devices require fast re-association when they roam feature. to a different Access Point Please enter the settings of the SSID and initialize the Security mode to WPA2 enterprise, as well as to set the Radius Server firstly. -
Page 43: Wireless Mac Filteing
Wireless MAC Filtering Wireless MAC Filtering is used to allow or deny network ACL (Access Control List) Mode: Determines whether access to wireless clients (computers, tablet PCs, NAS, network access is granted or denied to clients whose MAC smartphones, etc.) according to their MAC addresses. You addresses appear in the MAC address table on this page. -
Page 44: Wireless Traffic Shaping
Wireless Traffic Shaping Traffic shaping regulates the flow of packets leaving an interface to deliver improved Quality of Service. Enable Traffic Shaping: Default is disable. You may check this option to enable Wireless Traffic Shaping per SSID. Download Limit: Specifies the wireless transmission speed used for downloading. -
Page 45: Guest Network Settings
Guest Network Settings Adding a guest network allows visitors to use the Internet without giving out your office or company wireless security key. You can add a guest network to each wireless network in the 2.4 GHzb/g/n frequencies. IP address: The IP Address of this device. Subnet Mask: The IP Subnet mask of this device. -
Page 46: Rssi Threshold
RSSI Threshold Enable : Enable the Fast Handover feature by ensuring that each client is served by at least one Access Point at any time. Access Points continuously monitor the connectivity quality of any client in their range and efficiently share this information with other Access Points in the vincinity of that client to coordinate which of them should serve the client best. -
Page 47: Manegement Vlan Settings
Management VLAN Settings This page allows you to assign a VLAN tag to packets sent Save: Click Save to confirm the changes. over the network. A VLAN is a group of computers on a network whose software has been configured so that they behave as if they were on a separate Local Area Network (LAN). -
Page 48: Chapter 8 Management
Chapter 8 Management... -
Page 49: Advanced Settings
Advanced SNMP Settings Location: Specifies the location of the device. Port: Specifies the port of the device. This page allows you to assign the Contact Details, Location, Community Name, and Trap Settings for a Simple Network Community Name (Read Only): Specifies the Name for Management Protocol (SNMP). -
Page 50: Cli/Ssh/Https Settings/Email Alr
-Private Protocal: Selects the private protocol type: securely. The Hypertext Transfer Protocol over SSL (Secure Socket Layer) is a TCP/IP protocol used by web servers to DES or None. transfer and display web content securely. -Private Key: Specifies the private key. -Engine ID: Specifies the engine ID. - Page 51 Email Account Username: Enter the username for the email account that will be used to send emails. Password: Enter the password for the email account that will be used to send emails. SMTP Server: Enter the IP address or hostname of the outgoing SMTP server.
-
Page 52: Time Zone
Time Zone Date and Time Setting Time Zone Time Zone: Choose a time zone to implement the This page allows you to set the internal clock of the AP. service for this AP. Enable Daylight Saving: Check whether daylight savings applies to your area. Start: Select the day, month, and time when daylight savings time starts. -
Page 53: Auto Reboot Settings
WiFi Scheduler Auto Reboot Settings You can specify how often you wish to reboot the AP. Status: Enables or disables the Auto Reboot function. Timer: Select the day and enter the time you would like to reboot automatically. Save: Click Save to apply the changes. -
Page 54: Wi-Fi Scheduler
Wi-Fi Scheduler list for the desired days. Duration: The Start Time is entered in two fields. The first The Wi-Fi Scheduler can be created for use in enforcing box is for hours and the second box is for minutes. The End rules. -
Page 55: Tools
Tools Ping Test Parameters Start : Click Start to begin the trace route operation. This page allows you to analyze the connection quality of the AP and trace the routing table to a target in the network. Nslookup Test Parameter Target IP/Domain Name:Enter the IP address or domain name you wish to do Nslookup test. - Page 56 Speed Test Parameters LED Control This page allows you to analyze the connection quality Control LED on/off for Power, LAN interface, or 2.4 GHz of the AP and trace the routing table to a target in the WLAN interface. network. *The LED Control will be varied by different models.
-
Page 57: Account/Firmware
Firmware Account Account Settings Firmware Upgrade This page allows you to change the AP username and This page allows you to upgrade the firmware of the password. By default, the username is admin and the password is admin. The password can contain from 0 to 12 alphanumeric characters and is case sensitive. -
Page 58: Backup/Restore Setting
Backup/Restore Setting Backup Setting: Click Export to save the current This page allows you to save the current device configured settings. configurations. When you save your configurations, you also can reload the saved configurations into the Restore New Setting: To restore settings that have device through the Restore Saved Settings from a file been previously backed up, click Browse, select the section. - Page 59 User Setting The function allows you to backup the current device configurations into the AP as the default value. If Back Up Setting as Default: Click Backup to backup extreme problems occur, or if you have set the AP the user settings you would like to the device’s memory incorrectly, you can push the Reset button to revert all for the default settings.
-
Page 60: Log
System Log Remote Log The AP automatically logs (records) events of possible This page allows you to setup the Remote Log functions interest are in its internal memory. To view the logged for the AP. information, click the Log link under the System Manager Remote Log: Enable/disable this function. -
Page 61: Logout/Reset
Logout Reset Logout: Click Logout in Management menu to logout. In some circumstances, it may be required to force the device to reboot. Click on Reset to reboot the AP *The model name will be varied by different models. Once you click reset button, you will see the options for reboot or restore this AP. -
Page 62: Appendix
Appendix... -
Page 63: Fcc Interference Statement
Appendix A Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 64: Ic Interference Statement
Appendix B - IC Interference Statement Industry Canada statement This device complies with ISED’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d’... - Page 65 DETACHABLE ANTENNA USAGE This radio transmitter IC: 10103A-ENS202EXTv2 / Model: ENS202EXTv2 has been approved by ISED to operate with the antenna type listed below with maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
-
Page 66: Ce Interference Statement
- If the DoC should be a simplified version, please take below as reference – Hereby, EnGenius Networks declares that the EWS550AP/EWS510AP/EWS511AP are in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: Importer: EnGenius Networks Europe B.V. Importer Address: ESP 240, 5633 AC Eindhoven, The Netherlands Manufacturer : EnGenius Networks. Inc. Manufacturer Address: No.500, Fusing 3rd Rd., Hwa-Ya Technology Park Kuei-Shan Dist., Taoyuan City, Taiwan (R.O.C.) CE DoC Link: https://www.engeniusnetworks.eu/ens500ext-ac-ens500-ac-enstation5-accedoc...
