SGH-Z800 User's Guide
• Read Health and safety information before using your device.
• The program screens and your device may appear different from the
screen images and the illustrations in this guide.
• Depending on the software installed or your service provider, the
descriptions in this guide may differ, and may change without notice.

Advertisement

Table of Contents
loading

Related Manuals for Samsung SGH-Z800

Summary of Contents for Samsung SGH-Z800

  • Page 1 SGH-Z800 User’s Guide • Read Health and safety information before using your device. • The program screens and your device may appear different from the screen images and the illustrations in this guide. • Depending on the software installed or your service provider, the...

  • Page 2: Health And Safety Information

    Health and safety information Copyright © 2007 Samsung, Inc. All rights reserved. This guide may not be copied, reproduced, translated, or converted to any electronic or machine-readable form in whole or in part without written approval from Samsung, Inc. This is for users’ safety and property protection.
  • Page 3 Do not disassemble or modify the device • Samsung is not liable for any damages caused by users disassembling or modifying the device. Health and safety information Do not subject the device to shocks •...
  • Page 4 • The temperature in a car can reach 80° C, which can permanently damage your device. Use only Samsung-approved components and accessories • Unapproved components and accessories are not guaranteed. Use the device carefully to prevent damages •...
  • Page 5 • Use only the specified voltage. Non- specified voltages may cause the device to catch fire, give off an electrical shock, or damage the device. • Do not disconnect the device while initialising the modem, as it may cause the HSDPA Connection Manager to malfunction.

  • Page 6: Table Of Contents

    Contents Getting started Unpack ... 6 Overview ... 6 Inserting the USIM card... 7 Removing the USIM card ...7 Inserting an optional memory card ... 8 Inserting the HSDPA USB dongle into your PC ... 9 Installing the USB driver and HSDPA Connection Manager program...
  • Page 7 Using Phonebook... 18 Adding a new contact...18 Finding a contact ...19 Copying or moving contacts...19 Importing or exporting contacts...20 Using the inserted memory card... 21 Opening the electronic version of the user’s guide... 21 Customising the settings General settings ... 22 Configuring Internet settings...

  • Page 8: Getting Started

    Getting started Unpack HSDPA USB Dongle Program CD User’s Guide Extension Cable Overview Status light Cover connector...

  • Page 9: Inserting The Usim Card

    Inserting the USIM card Open the cover and insert the USIM card in the slot. The gold-coloured contacts on the card are face down. Important USIM card information • The USIM card and its contacts can be easily damaged by scratches or bending, so be careful when handling the card.

  • Page 10: Inserting An Optional Memory Card

    Getting started Inserting an optional memory card 1. Pull the HSDPA USB dongle out of the cover completely. 2. Insert an optional memory card into the slot. The gold-coloured contacts on the card are face up. Important memory card information •...

  • Page 11: Inserting The Hsdpa Usb Dongle Into Your Pc

    Inserting the HSDPA USB dongle into your PC 1. Insert the USIM card into the HSDPA USB dongle. 2. Open the cover and rotate the USB connector. 3. Close the cover and insert the HSDPA USB dongle into the USB port of your PC. If necessary, connect the dongle and your PC with the supplied extension cable.

  • Page 12: Installing The Usb Driver And Hsdpa Connection Manager Program

    Getting started Installing the USB driver and HSDPA Connection Manager program 1. Insert the supplied CD into the CD-ROM drive of your PC. The program launches automatically. 2. Click [Install Driver]. • The USB driver is installed. 3. Click [Finish]. 4.

  • Page 13: Checking The Usb Driver

    1. Insert the HSDPA USB dongle into the USB port of your PC. 2. Click [Start] and select [Settings] - [Control Panel] - [System] - [Hardware] - [Device Manger]. After the successful installation of the USB driver, Samsung USB Composite Device appears on the Device Manager window. Getting started...

  • Page 14: Using Basic Functions

    Using basic functions Running the HSDPA Connection Manager program From the Start menu Click [Start] and select [All programs] - [Samsung] - [Connection Manager] - [Connection Manager]. From the desktop Double-click the [Connection Manager] icon on the desktop. Using the tray icon 1.

  • Page 15: Connecting To The Internet

    • Convert Modem mode: change to Modem mode which allows you to connect to the Internet, and send or receive text messages. • Minimize: minimize the open window. • Exit: exit the program. Connecting to the Internet Click [Connect to net] in the HSDPA Connection Manager window to connect to the Internet using the HSDPA network.

  • Page 16: Using Additional Functions

    Using additional functions Using messages Send a text message and view the received messages. The EMS (Enhanced Messaging Service) and multimedia messages are not supported. Creating and sending a text message 1. Click [Text message] in the HSDPA Connection Manager window. 2.

  • Page 17: Checking Messages

    Using additional functions Checking messages Access messages you have received, sent, or saved to send at a later time. To view the messages you have received: 1. Click [Text message] in the HSDPA Connection Manager window. 2. Click [Inbox] from SIM or PC. 3.

  • Page 18: Managing A Text Template

    Using additional functions To view the messages that the device has failed to send or you have saved to send at a later time: 1. Click [Text message] in the HSDPA Connection Manager window. 2. Click [Drafts] or [Outbox] from SIM or PC. 3.

  • Page 19: Using My Folder

    Using additional functions 3. Enter the text. • Click [ ] to enter emotions. 4. Click [ ] to save the template. Using My folder Create new folders and organise your messages. To create a new folder: 1. Click [Text message] in the HSDPA Connection Manager window. 2.

  • Page 20: Using Phonebook

    Using additional functions Using Phonebook Store phone numbers and search for them in Phonebook. Adding a new contact Add new contacts to Phonebook. 1. Click [Phonebook] in the HSDPA Connection Manager window. 2. Click [New]. 3. Select a location and enter the contact information. •...

  • Page 21: Finding A Contact

    Finding a contact Search for contact information stored in Phonebook. 1. Click [Phonebook] in the HSDPA Connection Manager window. 2. Enter the first few letters of the name you want to find and click [ 3. Check the contact you want. •...

  • Page 22: Importing Or Exporting Contacts

    Using additional functions Importing or exporting contacts Export contacts stored in the PC in digital files. Also, import contacts stored as digital files to the PC. To export contacts: 1. Click [Phonebook] in the HSDPA Connection Manager window. 2. Select contacts you want to export. 3.

  • Page 23: Using The Inserted Memory Card

    Using additional functions Using the inserted memory card 1. Click [Mass Storage] in the HSDPA Connection Manager window. 2. Select the inserted memory card and use it as you would an external memory disk. Opening the electronic version of the user’s guide Click in the HSDPA Connection Manager window.

  • Page 24: Customising The Settings

    Customising the settings General settings Customise various settings to use the program. 1. Click [Settings] in the HSDPA Connection Manager window. 2. Click the [General] tab. 3. Select the options you want. Configuring Internet settings Select a profile or enter information to connect to the Internet. 1.

  • Page 25: Changing The Network

    Customising the settings Changing the network Change the network, if necessary. If you select the wrong network, your device may not work correctly. 1. Click [Settings] in the HSDPA Connection Manager window. 2. Click the [Network] tab. • Select [Auto] or a network band from Network mode. •...

  • Page 26: Locking The Usim Card

    Customising the settings Locking the USIM card Lock the USIM card to keep it safe from unauthorised use. You must enter PIN (Personal Identification Number) to connect to the Internet when the USIM card is locked. 1. Click [Settings] in the HSDPA Connection Manager window. 2.

  • Page 27: Accessing Information

    5. Enter the new PIN again in Confirm New PIN. 6. Click [Change]. Note If you enter an incorrect PIN three times, the USIM card is blocked. To unlock it, you need to enter your PUK (Personal Unblocking Key). The codes are supplied by your service provider.

  • Page 28: Appendix

    Appendix Frequently asked questions About the device and services What is HSDPA? Will my HSDPA USB dongle work without a USIM card? Is it okay to insert another type of USIM card when using the HSDPA USB dongle? HSDPA, short for High-Speed Downlink Packet Access, is a new protocol for mobile phone data transmission.
  • Page 29 Why do I get a slow connection while I am using HSDPA? Why won’t my computer recognise my USB devices when I plug two of them together? I connected the HSDPA USB dongle to my computer, but the Internet does not work. Can I connect the HSDPA USB dongle to a printer or fax?

  • Page 30: About The Hsdpa Connection Manager Program

    Appendix About the HSDPA Connection Manager program Why do I get the error message when I start the HSDPA Connection Manager program? Will I still receive messages when the modem is offline? The program disappeared while I was using it. The program is not supported in Windows ME or 98.
  • Page 31 How can I avoid losing the data on my USIM card? I entered the wrong PIN a few times. Why can't I use my device anymore? Can I connect to the Internet using Dial-up Networking? If you disconnect the HSDPA USB dongle from your computer while the device is on, you may lose the data on your USIM card.
  • Page 32 Appendix How many messages can I save on my USIM card? How many contacts can I save on my USIM card? Can I make voice calls with the HSDPA Connection Manager program? Can I use SIM Application Toolkit menus? Can I register my USIM card using a configuration message? The number of messages you can save depends on...

  • Page 33: Warranty And Parts Replacement

    Warranty and parts replacement Samsung warrants this product as free of defects in material, design and workmanship for the period of one year from the original date of purchase. (Depending on your country or service provider, the length of warranty may vary.)
  • Page 34 • Specifically exempt from any warranty are limited-life consumable components such as batteries and other accessories • Samsung will not assume any responsibility for any loss or damage incurred in shipping. All repair work on Samsung products by unauthorised third parties voids...
  • Page 36 Printed in Korea Code No.:GH68-16306A World Wide Web English. 12/2007. Rev. 1.0 http://www.samsungmobile.com...
