Swann SWN-SWWHD-PTCAM-AU Quick Start Manual

Security Made Smarter
1080p Pan & Tilt
Wi-Fi Camera
Quick Start Guide
Limited Warranty Terms & Conditions
Swann Communications warrants this product against defects in workmanship and material for a period of one (1) year
from its original purchase date. You must present your receipt as proof of date of purchase for warranty validation. Any
unit which proves defective during the stated period will be repaired without charge for parts or labour or replaced at
the sole discretion of Swann. The end user is responsible for all freight charges incurred to send the product to Swann's
repair centres. The end user is responsible for all shipping costs incurred when shipping from and to any country other
than the country of origin.
The warranty does not cover any incidental, accidental or consequential damages arising from the use of or the
inability to use this product. Any costs associated with the fitting or removal of this product by a tradesman or other
person or any other costs associated with its use are the responsibility of the end user. This warranty applies to the
original purchaser of the product only and is not transferable to any third party. Unauthorized end user or third party
modifications to any component or evidence of misuse or abuse of the device will render all warranties void.
By law some countries do not allow limitations on certain exclusions in this warranty. Where applicable by local laws,
regulations and legal rights will take precedence.
For Australia: Our goods come with guarantees which cannot be excluded under Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and
the failure does not amount to major failure.
FCC Notice
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) This device must accept any interference received, including interference
that may cause undesired operation.

NEED HELP?

USA & Canada 1800 627 2799
UK & Europe 0808 168 9031
tech@swann.com
QSGPTCAMVER1E | © Swann Communications 2017
Australia 1800 788 210
New Zealand 0800 479 266
support.swann.com
Getting to know your Pan & Tilt Wi-Fi Camera
Light Sensor
Detects ambient light
and turns on the infrared
LEDS for night vision, if
necessary
Speaker
Power LED
OFF
ON
Threaded
Mounting Hole (Bottom)
Prefer to mount your camera?
Just attach the included
mounting bracket to the wall,
then line the threaded hole on
the bottom of the camera up
with the threaded stud on the
mounting bracket and tighten
the knob to secure the camera
Reset Button
Hold for 10 seconds
to perform a factory
reset. This will reboot
the camera and clear
all settings to factory
defaults, including
previously configured
Wi-Fi settings, so you
can set up your camera
again, if needed
Ethernet Port
Used for wired
connection/setup
Infrared LEDS
Microphone
Wi-Fi LED
Unconnected state
Connected state
Dual-Band
Wi-Fi Antenna
USB Power Port
Restarting your camera
can sometimes quickly
resolve a problem—just
disconnect the USB cable,
and then plug it back in
MicroSD Card Slot
Never miss the moment—Put in a
microSD card to record and save
motion-activated events
