INPUT SELECTS
Select your TV or VCR manufacturer from the list below. It will show you the common locations of
that manufacturer's input select options.
If you are still not able to see your footage, you may need to verify that all your hookup connections
are correct. Please select which system you are connecting to from the main customer service page.
Admiral
Funai
Bell and Howell
General Electric
Broksonic
Goldstar
Citizen
Hitachi
Craig
JC Penney
Crosley
JVC
Curtis Mathis
LXI / Sears
Daewood
Magnavox
Electrohome
Magnasonic
Emerson
Memorex
Fisher
MGA
Mitsubishi
RCA
Montgomery Ward
Realistic
NEC
Samsung
Optimus
Sansui
Orion
Sanyo
Panasonic
Scott
Philco
Sears / LXI
Philips
Sharp
Proscan
Shintom
Quasar
Signature 2000
Radio Shack
Sony
Sylvania
Symphonic
Teac
Teknika
Toshiba
Westinghouse
XR1000
Zenith
Other Brands
1
Advertisement
Related Manuals for Swann SW211-DSC
Summary of Contents for Swann SW211-DSC
- Page 1 INPUT SELECTS Select your TV or VCR manufacturer from the list below. It will show you the common locations of that manufacturer’s input select options. If you are still not able to see your footage, you may need to verify that all your hookup connections are correct.
- Page 2 Admiral -------------------------------------------------------------------------------- Admiral TV’s 1 .Aux channel located below channel 2 (might have to auto-program channels with Nintendo 64 ON) 2. Press MENU, choose SOURCE, switch the source to AUX 3. SOURCE INDEX button on remote 4. Channel 91 Admiral VCRs 1.
- Page 3 Citizen VCRs 1. Input switches automatically to the AV inputs when in VCR mode 2. Aux or Line channel below channel 2 Citizen TVVCR Combos • Automatically switches or Aux channel below channel 2 Craig -------------------------------------------------------------------------------- Craig TVs • Either TV/VIDEO or TV/AV button on the front of the TV Craig VCRs •...
- Page 4 Daewood VCRs 1. INPUT button on remote. 2. INPUT or TV/LINE button on TV or remote. 3. Press MENU, select SOURCE, choose AUXILIARY. Daewood TV/VCR Combos • TV/LINE on remote. Electrohome -------------------------------------------------------------------------------- Electrohome TVs • INPUT or EXT button in front panel of TV. Electrohome VCRs 1.
- Page 5 3. Input switches automatically when AV cables are plugged in and it’s in VCR mode 4. Aux channel below 2 5. VCR must be on channel 3 Funai -------------------------------------------------------------------------------- Funai TVs • Aux channel below 2 Funai VCRs 1. Aux channel below 2 2.
- Page 6 Goldstar VCRs 1. TU/AV or TV/AV on remote 2. Press MENU, choose either TUNER or TUNING BAND, then choose SOURCE SELECT, then choose AV. 3. Either a TUNER/LINE or TV/LINE switch in the front panel. 4. Input switches automatically when the AV cables are plugged in and it’s in VCR mode 5. Line or AV button in front panel or on remote Goldstar TV/VCR Combos 1.
- Page 7 -------------------------------------------------------------------------------- JVC TVs 1. TV/VIDEO button either on the TV or remote 2. Press FUNCTION until you reach TV/VIDEO and switch to VIDEO 3. Press MENU until you reach INPUT and switch to either VIDEO or VHS 4. INPUT button on remote JVC VCRs •...
- Page 8 Magnasonic -------------------------------------------------------------------------------- Magnasonic VCRs 1. Aux channel below 2. 2. TV/AV or TUNER/LINE in front panel or on remote. Magnavox -------------------------------------------------------------------------------- Magnavox TVs • The majority of Magnavox TVs use the Volume up and down keys to select menu options. 1.
- Page 9 -------------------------------------------------------------------------------- MGA TVs • TV/EXT button inside front panel or on remote. MGA VCRs • TV/VIDEO or TUNER/EXT button inside front panel or on remote Mitsubishi -------------------------------------------------------------------------------- Mitsubishi TVs • Some models have a HOME THEATER setting which will lock out the inputs. Turn the HOME THEAT- ER setting OFF to allow the inputs to be used.
- Page 10 -------------------------------------------------------------------------------- NEC TVs 1. TV/VIDEO on TV or remote. 2. INPUT SELECT button on remote. NEC VCRs 1. Press INPUT or AUX on the front of the VCR or remote. 2. TV/SIMUL/LINE switch in front panel. Switch to LINE. Optimus -------------------------------------------------------------------------------- Optimus VCRs 1.
- Page 11 Panasonic VCRs • On some VCRs you have to setup the VCR before it will allow the INPUT to work. To do this, press channel down on the VCR, then select LANGUAGE, then the VCR will automatically go through a chan- nel setup selecting certain signals.
-
Page 12: Radio Shack
Quasar -------------------------------------------------------------------------------- Quasar TVs 1. TV/VIDEO, INPUT, or VIDEO MODE button on the front of the TV or remote. 2. On TV or remote, press ACTION, choose INPUT SELECT, then select VIDEO. Quasar VCRs 1. INPUT, AUX, or LINE button in front panel or on remote. 2. - Page 13 Realistic -------------------------------------------------------------------------------- Realistic TVs • TV/VIDEO button on the TV or remote Realistic VCRs 1. TUNER/AV button or switch inside front panel or on the remote. 2. INPUT or AUX button inside front panel or on the remote. 3. Aux channel below 2. Samsung -------------------------------------------------------------------------------- Samsung TVs...
- Page 14 Sanyo VCRs 1. On the remote, press the VCR button (this is a universal Sanyo remote), then press INPUT. 2. Input switches automatically when it‘s in VCR mode 3. TU/AV button or switch in front panel or on remote 4. AV channel below 2 5.
- Page 15 Shintom -------------------------------------------------------------------------------- Shintom VCRs 1. Aux channel below 2. Using the remote for this will not always work. 2. Possibly channel 28. Signature 2000 -------------------------------------------------------------------------------- Signature 2000 TVs 1. TV/AUX button on TV or remote 2. Aux channel below 2 Signature 2000 VCRs 1.
- Page 16 Sylvania TV/VCR Combos • INPUT button on remote Symphonic -------------------------------------------------------------------------------- Symphonic TVs • Press the TV/VCR button on the remote Symphonic VCRs 1. Aux or Line channel below 2 2. TUNER/AUX or TUNER/SCEXT button or switch. Set to either AUX or EXT. 3.
- Page 17 Toshiba VCRs 1. INPUT SELECT, LINE SELECT, or TV/LINE button usually on remote (sometimes in panel up front) If you are only getting sound, look for a SIMUL button or switch and turn it OFF. 2. Aux or Line channel below 2 3.
- Page 18 3. Line or Aux channel below 2 4. TUNER(SC)AUX button in front panel or on remote Zenith TV/VCR Combos 1. Aux channel below 2 2. INPUT, SOURCE, or TV/CATV/AV button on remote 3. Press MENU, choose INPUT, switch to AV Other Brands -------------------------------------------------------------------------------- Other TVs, VCRs, or Combo Units...
