  • Page 1 G500 Cockpit Reference Guide...
  • Page 2 Garmin. Garmin hereby grants permission to download a single copy of this manual and of any revision to this manual onto a hard drive or other electronic storage medium to be viewed for personal...

  • Page 3: Aviation Limited Warranty

    fi re, or other acts of nature or external causes; (iv) damage caused by service performed by anyone who is not an authorized service provider of Garmin; or (v) damage to a product that has been modifi ed or altered without the written permission of Garmin.
  • Page 4 GDU 620 PFD or other pressure altimeters in aircraft. WARNING: Do not use outdated database information. Databases used in the G500 system must be updated regularly in order to ensure that the information remains current. Pilots using an outdated database do so entirely at their own risk.
  • Page 5 GDU 620. WARNING: Because of anomalies in the earth’s magnetic fi eld, operating the G500 within the following areas could result in loss of reliable attitude and heading indications. North of 70° North latitude and south of 70°...
  • Page 6 System and is solely responsible for its accuracy and maintenance. The GPS system is subject to changes which could affect the accuracy and performance of all GPS equipment. Portions of the Garmin GDU 620 utilize GPS as a precision electronic NAVigation AID (NAVAID). Therefore, as with all NAVAIDs, information presented by the GDU 620 can be misused or misinterpreted and therefore, become unsafe.
  • Page 7 WARNINGS, CAUTIONS, AND NOTES NOTE: All visual depictions contained within this document, including screen images of the G500 bezel displays, are subject to change and may not refl ect the most current G500 system. Depictions of equipment may differ slightly from the actual equipment.
  • Page 8 Garmin to SVT™. 10/26/09 Updated subscription information for FliteCharts and ChartView. 11/30/10 Added software version 4.00 and 5.00 functionality. 8/23/11 Added software version 6.00 functionality. 2/14/12 Minor edits. 12/21/12 Added software version 6.10 functionality. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 9: Table Of Contents

    Default Map Page ............................26 MFD Soft Key Map ............................27 Map Group ..................... 28 Navigation Map 1 and Navigation Map 2 Pages ..................28 Decluttering (DCLTR) the Map Pages ......................29 Split Screen Page (Optional) ........................32 G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 10 XM Weather Map Pages ..........................40 Customizing the Weather Map ........................40 Displaying Surface Data and Winds Aloft .....................42 Garmin Flight Data Services (GFDS) Map Pages ...................43 Weather Radar (Optional) ................45 Weather Radar Map Page ...........................45 Airborne Color Weather Radar ........................46 Aux Group ......................

  • Page 11: Introduction

    G500 Avionics Display System. The G500 Avionics Display System is an avionics suite that combines primary fl ight instrumentation, navigational information, and a moving map all displayed on dual 6.5 inch color screens. The G500 system is composed of sub-units or Line Replaceable Units (LRUs). LRUs have a modular design and can be installed directly behind the instrument panel or in a separate avionics bay if desired.

  • Page 12: Primary Flight Display (Pfd)

    NAV Status Window: (NAV Style 2 Shown) Displays which GPS is selected as the Active Source, Active Waypoint (WPT), and Distance to Waypoint (DIS). NAV Style 1 (Not Shown) displays Active Source, WPT, DIS, Desired Track (DTK), and Current Track (TRK) at top of screen. G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 13 The indicator moves with the roll pointer and laterally away from the pointer to indicate lateral acceleration (slip/skid). Altitude Tape: Displays Current Altitude, Altitude Trend, Altitude Bug, Altitude Minimums Bug, and BARO setting. Marker Beacon: Marker Beacon Indicator G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 14: Airspeed Tape

    , the pointer changes to red with white text. NOTE: Airspeed tape markings are dependent upon confi guration at the time of installation. Reference the AFM, POH or latest revision of the G500 Pilot’s Guide for more details. Groundspeed Trend Indicator...

  • Page 15: Reference Speeds

    Glide Reference Marker Reference Marker Reference Marker Reference Marker Reference Speeds The labels for the reference markers may vary as confi gured during installation. Reference Marker Reference Marker Reference Marker Reference Marker Alternate Reference Speeds G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 16: Altitude Tape

    To change the BARO setting, press the BARO key and turn the PFD knob to the desired pressure. To select standard pressure (29.92in, 1013 mb), press the PFD knob. To return to the previous setting, press the PFD knob again. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 17: Minimums Bug (Barometric Or Radar Altimeter)

    Alerting is inhibited while the aircraft is on the ground and also, if a value has been set for altitude alerting, until the aircraft reaches 150 feet above the setting for the alert. G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 18 3) Press the ENT key to move to enter altitude. Turn the small MFD knob to enter the desired altitude. Press the ENT key to confi rm selection. Radar Altimeter Value Brown band represents the ground. Minimums Annunciations using RAD ALT for Source G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 19: Altitude Bug

    The Fast/Slow indication from an external system may be optionally displayed on the left side of the PFD. Refer to the Airplane Flight Manual for instructions on using the Fast/Slow indications. Pointer Fast/Slow Scale Fast/Slow Scale and Pointer G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 20: Wind Vectors

    Vertical Speed Maximum and Minimum ranges will be shown on the left side of the Vertical Speed tape. Vertical Speed Maximum Vertical Speed Bug Current Vertical Speed Vertical Speed Minimum Vertical Speed Bug Setting Vertical Speed Vertical Speed Warning Indication G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 21: Vertical Deviation Indicator (Vdi)

    DME information is displayed in a window in the lower left corner of the PFD. The distance to the station and the NAV source used are shown. DME Information DME Hold Annunciation Selected DME Set Hold for Selected DME DME Indication G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 22: Attitude Indicator

    Roll Pointer Roll Scale G500 Attitude Indicator with a Ground Pointer Confi guration in a Left Turn In an aircraft with an Attitude Indicator that has a Sky Pointer, the pointer below the roll scale shifts with the roll or bank angle of the aircraft to keep the Roll Pointer pointing towards the sky.

  • Page 23: Horizontal Situation Indicator (Hsi): Aircraft Heading

    (3°/sec) rate. Current Heading Turn Rate Markings Current GPS Track Heading Trend HSI Heading Markings NOTE: If magnetic heading is lost, GPS ground track will be displayed in place of heading. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 24: Adjusting The Course Pointer

    GPS source is available. Additionally, ADF is available if an ADF source is installed. Bearing 2 Pointer GPS Level Current Navigation of Service Source Bearing 1 Pointer Bearing 1 Source Bearing 2 Source Bearing 1 Bearing 2 Pointer Icon Pointer Icon Bearing Pointers on the HSI G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 25 MSG: Displays when a new advisory message is displayed on the GNS. LOI (Loss of Integrity): Displays when GPS integrity is lost. Suspend OBS: Displays when OBS mode is activated. SUSP: Displays when automatic waypoint sequencing on the interfaced GPS unit is suspended. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 26: Marker Beacon Annunciations

    Beacon Inner Marker Middle Marker Outer Marker Miscompare Annunciations For complete description and conditions of miscompare annunciations, see the G500 Pilot’ s Guide, P/N 190-01102-02. Pitch and Roll Miscompare Pitch Miscompare Roll Miscompare Miscompare Annunciations G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 27 NOTE: Verify the navigation source by the indication on the HSI. NOTE: The selected navigator is the source for all PFD and MFD functions, except for bearing pointers and external TAWS PFD annunciations. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 28: Autopilot (Ap)

    PRIMARY FLIGHT DISPLAY (PFD) Autopilot (AP) The G500 is able to interface to certain autopilot systems to provide the functions described in this section. Please refer to your particular Airplane Flight Manual and autopilot documentation for specifi c information and operating instructions.

  • Page 29: Heading

    1) Set your navigation source and HSI to the desired course. 2) Engage your autopilot in navigation mode. 3) Control your autopilot navigation through the navigation source and the HSI. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 30: Gpss

    NOTE: The GDU 620 has the ability to emulate GPSS roll steering for autopilots that do not support GPSS. The GDU 620 emulates GPSS by sending headings to the autopilot that guide turn anticipation. GPSS OFF GPSS ON GPSS Mode Control G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 31: Flight Director Display

    NAV Status Style 1 GPSS Mode Annunciations Flight Director Display Flight director commands are presented as a single cue fl ight director on the PFD. SVT Off SVT On Flight Director Bars Showing Aircraft Pitch G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 32: Vertical Speed Control

    When autopilot annunciations are displayed at the top of the PFD, the Nav Status information will be located to the left of the HSI (NAV STATUS Style 2). Autopilot Status Roll Modes Pitch Modes Active Mode Active Mode Armed Mode Armed Mode Autopilot Annunciations G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 33: Additional Features

    SVT are unavailable (generating a GDU DB ERR or SVT DISABLED alert) or AHRS or GPS data is unavailable. SVT may be restored once the fail conditions are removed by following the steps in “Displaying SVT Terrain.” G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 34: Displaying Garmin Svt Terrain

    PRIMARY FLIGHT DISPLAY (PFD) The following features are part of the Synthetic Vision Technology. For more details refer to the G500 Pilot’ s Guide, Rev. C or later. • Flight Path Marker • Airport Signs • Horizon Heading Marks • Runway Display •...

  • Page 35: Multi-Function Display (Mfd)

    Page Group Clear Page Labels Menu SD Card Slots Range Select Soft Key Labels Map Scale Soft Keys Map Orientation Large MFD Knob (Select Page Group) Wind Vector Small MFD Knob (Select Page) G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 36: Page Navigation - Moving Between Pages

    5) Press ENT to accept displayed value or press the small MFD knob to cancel selection or exit the editing mode. Default Map Page Press and hold the CLR key to return to the fi rst page of the MAP group. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 37: Mfd Soft Key Map

    Send Hang Up DBASE Keys 1234 5678 90*# Active Fpl Wpt Info Charts Rwy/Freq Header Info ALERTS NOTAM Apt Dir Plan Detail Profi le TRND/ACK Minimums CAPTURE Select BACK MFD Soft Key Map G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 38: Map Group

    3) Press the INFO soft key (if available) to view more information about the highlighted waypoint. 4) Press the WX soft key (if available) to view TAF and METAR information. Press the small MFD knob again to return to the map. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 39: Decluttering (Dcltr) The Map Pages

    Distance, Bearing and Coordinates Display Measuring Map Pointer 4) Press ENT to reset the distance and bearing values. 5) Press the small MFD knob to stop measuring. G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 40 8) Repeat the above steps to set preferences for the remaining groups. NOTE: In the Map Options Setup section, the selected range is defi ned as the map range below which the display feature will be visible. G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 41 • Restricted (Range: Off to 500 • MOA (Military) (Range: Off to 500 • Other/Adiz (Range: Off to 500 • TFR (Range: Off to 2500 • Airways (Off, All, LO Only, HI Only) G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 42: Split Screen Page (Optional)

    Display of External Video Source Map Display External Video 2) The External Video page will show the external video on the top half of the MFD and a Navigation Map will be shown on the lower half. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 43: Traffi C Map Page (Optional)

    The traffi c pop-up window will be removed when the traffi c alert is no longer active. Traffi c Traffi c Annunciation Traffi c Pop-Up PFD Traffi c Display MFD Traffi c Pop-Up Window G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 44 Displaying and Operating Traffi c Advisory Systems (TAS) Traffi c Map - TAS NOTE: Depending on your traffi c confi guration, the OPERATE and STANDBY soft keys may not be available. Traffi c Mode Field Altitude Mode Field G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 45 MFD. After a few seconds, test mode is exited automatically by the traffi c system. Traffi c Annunciation Traffi c Annunciation on PFD G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 46 NOTE: TIS is disabled when a Traffi c Advisory System (TAS) is installed. Operating Mode Proximity Advisory Traffi c 5000 feet Advisory, above and aircraft is descending. 1200 feet above and ascending. Non-Threat, 5000 feet above and ascending. Traffi c Map - TIS G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 47: Terrain Page

    (SVT) option is installed. NOTE: TAWS alerts will be generated by the GPS TAWS unit on the PFD if an external TAWS unit is installed and interfaced to the G500. • TERRAIN-PROXIMITY - is a non-TSO-C151b certifi ed terrain awareness system.
  • Page 48 Pressing the INHIBIT soft key deactivates the TERRAIN-SVT PDA/FLTA aural and visual alerts. Inhibit Soft Key Press MENU for selections to hide or show Aviation Data Overlay on the Terrain page. Aviation Data Overlay G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 49: Terrain Pop-Up Alerts

    MFD. To acknowledge the pop-up alert and return to the currently viewed page, press the CLR key. To acknowledge the pop-up alert and go to the TERRAIN-SVT page, press the ENT key. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 50: Wx Group

    MFD knob to set the preference of the weather feature option. 3) Press ENT to confi rm your selection. 4) To return to the XM Weather Map page, press the small MFD knob. G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 51 NEXRAD Data and Echo Top Data at the same time. NOTE: Due to similarities in color schemes, it is not possible to display Echo Top Data and Cloud Top Data at the same time. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 52: Displaying Surface Data And Winds Aloft

    WINDS ALOFT DATA VIEWING RANGE, the WIND DOWN and WIND UP soft keys will be available. To view winds aloft, press the WIND DOWN or WIND UP soft keys to cycle through (up or down) the winds aloft altitudes. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 53: Garmin Flight Data Services (Gfds) Map Pages

    Prior to requesting GFDS information, an access code and system ID will need to be assigned. For more information on GFDS and how to register, see the latest revision of the G500 Pilot’ s Guide, P/N 190-01102-02. After registering you are able to display GFDS data: 1) While viewing any one of the three pages of the WX Group, press the MNU button.
  • Page 54 3) Turn the large MFD knob to the Manual Request box and press ENT to either send request or cancel current request. 4) Press the small MFD knob to return to the GFDS page. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 55: Weather Radar (Optional)

    Weather Radar (Optional) Weather Radar Map Page Soft Keys Found on Weather Radar Map Page Operating Stabilization Mode On/Off Weather Alert (GWX only) Radar Beam Scan Line Precipitation Scale Control Window Weather Radar G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 56: Airborne Color Weather Radar

    Monitor the displayed tilt value in the TILT fi eld. The range of tilting the antenna is DN 15° to UP 15°. 2) Press the small MFD knob to confi rm selection. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 57: Adjusting Gain

    The line pointer is a reference depicting the calibrated position. 3) Press the ENT key to remove the cursor. 4) To restore the gain to the calibrated position, press the GAIN CAL soft key. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 58: Antenna Stabilization

    Press the WATCH soft key again to deactivate. Automatic Standby When the weather radar system is in the Weather or Ground Map Mode, upon landing the system automatically switches to Standby Mode. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 59: Aux Group

    2) Press the RNG (Range) keys to zoom in and out. The range of the zoom feature is 1x up to 10x. 3) Press the small MFD knob to exit. Video Soft Keys Setup Soft Key External Video Setup G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 60: System Setup Page

    V Speed References on Airspeed Tape Airspeed References NOTE: At any time during the setting of your airspeed references, pressing the DFLT SPD soft key will restore the unit to its initial confi guration. G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 61 MFD knob and turn the large MFD knob to move to the NAV Status fi eld in the PFD OPTIONS box. 2) Turn the small MFD knob to select the style and press ENT. G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 62 MFD knob to move to the BARO setting. Turn the small MFD knob to turn the synchronization of the barometer ON or OFF. 3) Press ENT to move to the DATE/TIME box or press the small MFD knob to exit the editing mode. Synchronization Option G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 63 -3 hours Eastern -5 hours -4 hours Central -6 hours -5 hours Mountain -7 hours -6 hours Pacifi c -8 hours -7 hours Alaskan -9 hours -8 hours Hawaiian -10 hours -9 hours G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 64 1) While viewing the System Setup Page of the Aux Page Group, press the small MFD knob and turn the large MFD knob to move to the desired fi eld of the SYSTEM DISPLAY UNITS box. G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 65 Press the RA TEST soft key (if available) to activate the radar altimeter test. An RA TEST annunciation will be displayed on the PFD. For more information on the Radar Altimeter and its settings, see the latest revision of the G500 Pilot’ s Guide, P/N 190-01102-02.

  • Page 66: Xm ® Information Page (Optional)

    XM Information screen. This page contains the Data Radio and Audio Radio IDs. The only option on this page is to LOCK in your information once your subscription has been activated. Subscription information is available at http://www.garmin.com/xm/. XM Information Page G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 67: Xm ® Radio Page (Optional)

    MFD knob to the category and press ENT. 3) Turn the small MFD knob to move to the desired channel. 4) Press ENT to make that channel the active channel. 5) Press the small MFD to end editing. G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 68 While viewing the XM Radio page, press the PRESETS soft key and press the preset soft key for the desired stored channel, such as PS1. To move to the next group of presets, press the MORE soft key. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 69: Position Reporting Page

    Settings Window 1) While viewing the Position Reporting page, press the small MFD knob. 2) Turn the large MFD knob to change the report type to either AFF (Automatic Flight Following) or Standard. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 70: Iridium® Phone Page

    Icon Volume Level Iridium Phone Page For detailed use of the Iridium Phone system, see the latest revision of the G500 Pilot’ s Guide, P/N 190-01102-02. Call Suppression 1) While viewing the Iridium Phone page, press the small MFD knob.

  • Page 71: Making A Phone Call

    Press the KEYS soft key and enter the number. When fi nished entering the number you want to call, press the DIAL key. 2) After completing the call, press the HANG UP key. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 72: System Status Page

    LRU. Press the small MFD knob to exit. 2) Press the DBASE soft key and turn the small MFD knob to view the list of the databases loaded into the GDU 620. Press the small MFD knob to exit. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 73: Flight Plan Group

    MFD knob and then turn the large MFD knob to highlight waypoints in the fl ight plan. 2) Press the INFO soft key to view information about the highlighted waypoint. 3) Press the small MFD knob to return to the Active Flight Plan page. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 74: Waypoint Information Page

    Press the small MFD knob to scroll down the page. 4) Press the WX soft key (if available) to view METARs or TAFs for the waypoint. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 75: Charts Page (Optional)

    3) Turn the large MFD knob to move around the chart horizontally and turn the small MFD knob to move vertically. 4) Press the small MFD knob to cancel the scroll bars and exit panning. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 76: Viewing Notams

    4) Press ENT to display the desired chart. NOTE: The chart for the selected destination airport or approach is automatically loaded. If the destination airport is in the fl ight plan, the chart page will default to the nearest airport. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 77: Viewing Details Of Chartview™ Charts

    3) Turn the small MFD knob to show FPL, NRST, or RECENT. 4) Turn the large MFD knob to highlight the desired airport, then press ENT. Display Charts From Display Charts Of Display Charts From Flight Plan Nearest Airport Recent Choices G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 78: Chart Information

    Airport Moving Map Display (AMMD). SafeTaxi and ChartView are intended to improve pilot situational awareness during ground operations and should only be used by the fl ight crew to orient themselves on the airport surface. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 79: Alerts

    ALERTS Alerts NOTE: Contact your Garmin dealer for service if any of the following alerts appear. On Screen Alerts Alert Description ADC Altitude Error Correction is unavailable. ADC1 ALT EC GDC is reporting that altitude correction is unavailable. AHRS 1 or AHRS 2 is not receiving any GPS information.
  • Page 80 GWX confi guration error. Confi guration service required. GWX SERVICE GWX need service. Return unit for repair. HDG FAULT AHRS 1 magnetometer fault has occurred. HDG LOST HDG features disabled or defaulted to GPS1 TRK. G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 81 TRF STBY Traffi c device is in standby mode while airborne. TRK LOST GPS1 TRK lost. HSI defaulted to GPS2 TRK. WX ALERT Possible severe weather ahead. WX RADAR Weather radar has failed. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 82: Terrain-Svt ™ Alerts

    Terrain awareness display unavailable. Terrain SVT System Test “Terrain System Failure” Fail FLTA Terrain Caution “Caution, Terrain, Terrain” FLTA Terrain Warning “Warning, Terrain, Terrain” FLTA Obstacle Caution “Caution, Obstacle, Obstacle” FLTA Obstacle Warning “Warning, Obstacle, Obstacle” G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 83: Symbols

    Non-towered, Serviced Airport Towered, Serviced Airport Soft Surface, Serviced Airport Soft Surface, Non-serviced Airport Private Airport Heliport Intersection LOM (compass locator at outer marker) NDB (Non-directional Radio Beacon) VOR/DME ILS/DME or DME-only VORTAC TACAN G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 84: Safetaxi ® Symbols

    Under Construction Zones Unpaved Parking Areas Traffi c Symbols Description Symbol (Highest to Lowest Priority) Traffi c Advisory (TA), In Range Traffi c Advisory (TA), Out of Range Proximity Advisory (PA) Other Traffi c G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 85: Terrain Obstacle Symbols

    Map Toolbar Symbols Symbol Description Maximum Zoom Indicator Terrain Proximity Enabled and Available Indicator Terrain Proximity Enabled and Not Available Indicator Traffi c Enabled and Available Indicator Traffi c Enabled and Not Available Indicator G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 86: Xm ® Wx Weather Symbols And Product Age

    NOTE: Product age is not displayed for individual reports of AIRMETs, SIGMETs, City Forecasts, County Warnings, Cell Movement and TFRs. Product generation time is displayed for Freezing Level and Winds Aloft instead of valid time. G500 Cockpit Reference Guide 190-01102-03 Rev G...

  • Page 87: Miscellaneous Symbols

    Default Aircraft (Ownship) High Wing Aircraft Jet Aircraft Default Map Pointer Elevation Map Pointer User Waypoint Parallel Track Waypoint TFR (Temporary Flight Restrictions) Restricted/Prohibited/Warning/Alert Class B Airspace Class C Airspace Class D Airspace G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 88 This page intentionally left blank G500 Cockpit Reference Guide 190-01102-03 Rev G...
  • Page 90 © 2009-2012 Garmin Corporation Garmin International, Inc. 1200 East 151 Street, Olathe, Kansas 66062, U.S.A. Tel. 913/397.8200 or 866.739.5687 Fax 913/397.8282 Garmin AT, Inc. 2345 Turner Rd., SE, Salem, Oregon 97302, U.S.A. Tel. 503/581.8101 or 800/525.6726 Fax. 503/364.2138 Garmin (Europe) Ltd.
