Rotel RDV-985 Technical Manual
Hide thumbs Also See for RDV-985:

Advertisement

Quick Links

T echnical
Manual
Table of Contents
Specification......................................1
Information........................................2~17
Block Diagrams.................................18~22
Schematic Diagram ..........................23~33
PCB Assembly..................................34~36
Parts List...........................................37~47
Specifications
General
Readable Discs:
Video Fomat:
Video Output
VIDEO OUT (pin jack):
S-VIDEO OUT (S jack):
Y Output:
C Output:
Horizontal Resolution:
Signal to Noise Ratio:
Audio Output
ANALOG OUT (pin jack):
DIGITAL OUT (optical):
Audio Characteristics
Frequency Response:
CD: (sampling frequency 44.1 kHz):
DVD (sampling frequency 48 kHz):
DVD (sampling frequency 96 kHz):
Dynamic Range:
16 bit:
20 bit:
24 bit:
Wow and Flutter:
Total Harmonics Distortion:
Physical
Power Requirements:
USA Version:
European Version:
Power Consumption:
Weight:
Dimensions (W x H x D):
THE ROTEL CO., LTD.
SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU,
TOKYO 150-0045, JAPAN
Quality Uncompromised
DVD VIDEO, Audio CD, VIDE CD, SUPER VIDEO CD
PAL or NTSC selectable
1.0 Vp-p (75 ohms)
1.0 Vp-p (75 ohms)
286 mVp-p (75 ohms)
500 Lines
65 dB
2.0 Vrms (10 kohms)
- 21 to -15 dBm (peak)
2 Hz to 20 kHz
2 Hz to 22 kHz
2 Hz to 44 kHz
More than 100 dB
More than 108 dB
More than 108 dB
Unmeasurable (less than ±
Less than 0.002%
AC 120V, 60 Hz
AC 230V, 50 Hz
23 W (POWER ON), 2 W (STANBY mode)
4.7 kg (10.4 lbs)
445 x 112 x 338 mm
17
x 4
x 13
inch
1/2
7/16
5/16
®
DVD PLAYER
RDV-985
0.002%)
Serial. NO.
Beginning
Y-356A-0109/W

Advertisement

Table of Contents
loading

Summary of Contents for Rotel RDV-985

  • Page 1 23 W (POWER ON), 2 W (STANBY mode) Weight: 4.7 kg (10.4 lbs) Dimensions (W x H x D): 445 x 112 x 338 mm x 13 inch 7/16 5/16 THE ROTEL CO., LTD. Serial. NO. SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU, Beginning TOKYO 150-0045, JAPAN Y-356A-0109/W...
  • Page 2 Appearance...
  • Page 3: Main Adjustment

    Main Adjustment Adjustment and confirmation matter (1) Auto adjustment method If microprocessor (IC401, IC402, IC714, IC716) or servo board (LEA10047) is replaced, initialize the DVD player in the following matter: ref. separate sheet. (2) Confirmation of DVD RF level "12" "11"...
  • Page 4: Flap Adjustment Of The Pick-Up Guide Shaft

    (4)Flap adjustment of the Pick-up guide shaft Attention !! RDV-985 is adjusted from issue machine because of the FL display on the way. Please go in the adjustment method before changes according to the following procedures. Mode Measurement Disc Adjustment point CN104 pin"1"...
  • Page 5 Confirmation after adjustment. Confirm to reproduce video CD and CD after the DVD test disc is adjusted and to find abnormality. Fig.2 (5) About keeping the disc As for the DVD test disc, plane accuracy is demanded.Please note the keeping place on the disc. Please do not put the disc directly on the work desk etc.
  • Page 6: Check Points For Each Error

    Check points for each error (1) Spindle start error *Defective spindle motor Are there 10ohms resistance between each pin of CN101 "29~31"? (The power supply is turned off and measured.) *Hall element: Is sine wave output between CN101 "23" and "24", between "25" and "26", and between "27"...
  • Page 7 (3) Traverse movement NG * For automatic adjustment, traverse movement occurs only when the position is changed to retry judging the disc type after the 1st judgment resulted in an error. Therefore, traverse movement rarely occurs because, in most cases, disc judgment at the current position (1st time judgment) is executed successfully.
  • Page 8 (6) Spindle CLV NG * When the spindle cannot be shifted to CLV Servo, does not become "H" between IC301 "69" and IC201"37". * IC201 Is signal output from CN103 "1" (RFOP)? * IC201 Is signal output from CN103 "11" (DSLIP)? * IC201 Is signal output from CN103 "6"...
  • Page 9 (9) Neither picture nor sound is output * Cannot search a) Can the feed system be driven? Chec k the waveform of TRSDRV signal (R273). --- Waveform between R274 and C271. Search results in a change of duty (three v alues with 2.5V at the center) (The figure is e xaggerated.)
  • Page 10 (10) Picture is distorted or abnormal sound occurs at intervals of several seconds. Does JITOUT change periodically? Some system other than servo may be (2V or more in peak defective. value, except during kick) Feed system is defective (drive gain is defective: too large). Check the waveform according to a) in (9).
  • Page 11: Precautions For Service

    Precautions for Service Handling of Traverse Unit and Laser Pickup 1. Do not touch any peripheral element of the pickup or the actuator. 2. The traverse unit and the pickup are precision devices and therefore must not be subjected to strong shock.
  • Page 12: Troubleshooting

    Troubleshooting 1.Power-on processing Connect to outlet. F901 P.STAND-BY Return to A Replace Does fuse is blown indicating lamp and recheck. F901. the lamp lights up? goes out when Micro- POWER switch of computer remote control Volume. box is turned Press POWER switch. Is the AC Is energizing Voltage of...
  • Page 13: Specification

    2. Power Supply Volume With all the wiring removed, check unit power board. (1) Remove all flat wires and wire assemblies which are connected to CN801, CN805, CN806. (2) Short -circuit CN805"4" (POWER ON:B168) and "5" (B5V:B167). (Set each regulator to ON.) The load resistance is connected between CN805"5"(B5V:B167) and "8,9"(D.GND:B164).
  • Page 14: Information

    4. Microcomputer Volume Processing of Each Microcomputer IC714 System microcomputer (sub-microcomputer) After powering on, this microcomputer is continuously activated to control keys and remote control signals. According to key operations or remote control signals, it controls (turns on/off) the power for LSIs including IC401 (main microcomputer) and the audio/video output circuit.
  • Page 15: Audio Volume

    5. Audio Volume Power to Power Supply supplied correctly Volume to each IC? IC702 are supplied power from IC718. Check I/O voltage of IC718. Is sound signal output from J702 (pin jack)? Approx . 5V Is sound Is sound Voltage of IC714 is CN704 is output from...
  • Page 16 6. Video Volume Power to Power Supply +5V power for video section is supplied correctly Volume supplied from IC654. to each IC? Check I/O voltage of IC654. Is video Check the insertion of Is video signal output from signal output from IC621,IC622,L604 J603 composite J602 S terminal?
  • Page 17 7.Servo volume Press from A "OPEN/CLOSE" *only two layer disc (DVD) Is the jump between layers OK? Is the opening to OPEN/CLOSE (16) Jump between operation of Operation Section layers NG TRAY normal? After "FL" displays "Close", is "Reading" displayed? Was information on (15) Address the disk obtained?
  • Page 18: Block Diagrams

    Block diagrams (DVD SERVO CONTROL Section)
  • Page 19 Block diagrams (DC REGURATOR Section)
  • Page 20: Component Video Out

    Bloc k dia grams (VIDEO OUT & A UDIO OUT) CN601 LVA10054-A2 IC601 Pr,Pb AMP 4MHz LPF NJM2267D J601 L601 QQR0712-001 TO CN702 4MHz LPF LVA10047 COMPONENT L602 (DVD SERVO VIDEO OUT QQR0712-001 CONTROL 2) VIDEO SIGNAL IN 6MHz LPF L603 QQR0713-001 IC621...
  • Page 21 RDV-985 Block diagrams (SYSTEM CONTROL & FL DRIVER Section) LVA10054-A1 CN703 +5V REG. KEY MATRIX KEY00~KEY03 IC718 83,84,86~92 KEYI0~KEYI5 RESET IC717 TO CN801 OF EEPR OM RESET LVA10053-A1 IC715 PST574CMT - X NJM78M05 (POWER SUPPL Y ) KEY MATRIX TC75H08F-X...
  • Page 22 Meno...
  • Page 23 RDV-985 DVD Servo Control 1 K371 BLOCK A BLOCK B GNAL BLOCK D BLOCK C DIGT AL DAT A SIGNAL...
  • Page 24 RDV-985 RDV-985 Block A to Block B to Block C...
  • Page 25 RDV-985 Block B to Block A to Block D...
  • Page 26 RDV-985 Block C to Block A to Block D...
  • Page 27 RDV-985 Block D to Block B to Block C DIGTAL DATA SIGNAL...
  • Page 28 RDV-985 RDV-985 DVD Servo Control 2 ol 2 HY57V161610DTC8 HY57V161610DTC8 DIGTAL DATA SIGNAL VIDEO SIGNAL AUDIO SIGNAL...
  • Page 29 RDV-985 Display...
  • Page 30 RDV-985 RDV-985 RDV-985 RDV-985 RDV-985 RDV-985 RDV-985 RDV-985 Power Supply RDV-985 750K 750K QNZ0136-001Z QMF51U1-1R6-S 1000PF/AC250V 0.47(2W) 120uF/400V LE40597-001A 4700PF/AC250V 68K(2W) PC123F...
  • Page 31 RDV-985 Video & Jac AUDIO SIGNAL VIDEO SIGNAL...
  • Page 32 RDV-985 RDV-985 AUDIO SIGNAL...
  • Page 33 RDV-985 Connection...
  • Page 34 RDV-985 Printed circuit board Power supply board Display board...
  • Page 35 RDV-985 CPU & Video & Jack board S601 NTSC/PAL SW...
  • Page 36 Servo control board (BOTOM SIDE) (TOP SIDE) R374...
  • Page 37: Parts List

    PARTS LIST [RDV-985] * All printed circuit boards and its assemblies are not available as service parts.
  • Page 38 Parts List 1/8 SYMBOL PARTS NO. DESCRIPTION SYMBOL PARTS NO. DESCRIPTION POWER SUPPLY, FL DISPLAY BOARD LVA10053 D842 1SS199-02-T2 SI DIODE BK901 E409182-001SM GRAND TERMINAL D844 1SS199-02-T2 SI DIODE C832 QER61AM-476Z ELECTROLYTIC CAPACITOR 10V47uF D845 1SS199-02-T2 SI DIODE C833 QCBB1HK-101Y CERAMIC CAPACITOR 50V100PF D901 S1WB/A/60-4101...
  • Page 39 Parts List 2/8 SYMBOL PARTS NO. DESCRIPTION SYMBOL PARTS NO. DESCRIPTION R803 QRE141J-472Y CARBON RESISTOR 4.7K 1/4W C603 QETN1AM-108Z ELECTROLYTIC CAPACITOR 10V1000uF R804 QRE141J-472Y CARBON RESISTOR 4.7K 1/4W C604 QETN1AM-108Z ELECTROLYTIC CAPACITOR 10V1000uF R805 QRE141J-472Y CARBON RESISTOR 4.7K 1/4W C605 QETN1AM-107Z ELECTROLYTIC CAPACITOR 10V100uF R806...
  • Page 40 Parts List 3/8 SYMBOL PARTS NO. DESCRIPTION SYMBOL PARTS NO. DESCRIPTION C765 QCF11HZ-473 CERAMIC CAPACITOR 0.047uF R1005 QRE141J-103Y CARBON RESISTOR 10K 1/4 CN601 VMC0075-010N 10P PLUG ASSY TO MAIN R1006 QRE141J-273Y CARBON RESISTOR 27K 1/4 CN701 QGF1016C1-35 FFC/FPC CONNECTOR TO MAIN R1007 QRE141J-561Y CARBON RESISTOR 560 1/4...
  • Page 41 Parts List 4/8 SYMBOL PARTS NO. DESCRIPTION SYMBOL PARTS NO. DESCRIPTION R742 QRE141J-471Y CARBON RESISTOR 470 1/4 C120 NCB31CK-104X CERAMIC CAPACITOR 0.1uF R743 QRE141J-471Y CARBON RESISTOR 470 1/4 C121 NCB21CK-334X CERAMIC CAPACITOR 0.33uF R744 QRE141J-471Y CARBON RESISTOR 470 1/4 C122 NCS31HJ-121X CERAMIC CAPACITOR 1200PF R745...
  • Page 42 Parts List 5/8 SYMBOL PARTS NO. DESCRIPTION SYMBOL PARTS NO. DESCRIPTION C253 NCB31CK-104X CERAMIC CAPACITOR 0.1uF C501 NCB31CK-104X CERAMIC CAPACITOR 0.1uF C254 NCB31CK-104X CERAMIC CAPACITOR 0.1uF C502 NCB31CK-104X CERAMIC CAPACITOR 0.1uF C255 NEA70JM-226X ELECTROLYTIC CAPACITOR 6.3V22uF C503 NCB31CK-104X CERAMIC CAPACITOR 0.1uF C256 NCB31CK-104X CERAMIC CAPACITOR 0.1uF...
  • Page 43 Parts List 6/8 SYMBOL PARTS NO. DESCRIPTION SYMBOL PARTS NO. DESCRIPTION CN503 QGA2001C2-10X W TO B CONNECTOR VIDEO K559 NQR0007-002X FERRITE BEADS C.M. D201 1SS355-X DIODE C.M. K561 NQR0007-002X FERRITE BEADS C.M. D202 1SS355-X DIODE C.M. K562 NQR0007-002X FERRITE BEADS C.M. D203 1SS355-X DIODE C.M.
  • Page 44 Parts List 7/8 SYMBOL PARTS NO. DESCRIPTION SYMBOL PARTS NO. DESCRIPTION R131 NRSA63J-0R0X MG RESISTOR 0 R271 NRSA63J-243X MG RESISTOR 24K R151 NRSA63J-0R0X MG RESISTOR 0 R272 NRSA63J-103X MG RESISTOR 10K R152 NRSA63J-0R0X MG RESISTOR 0 R273 NRSA63J-103X MG RESISTOR 10K R153 NRSA63J-0R0X MG RESISTOR 0...
  • Page 45 Parts List 8/8 SYMBOL PARTS NO. DESCRIPTION SYMBOL PARTS NO. DESCRIPTION R505 NRSA63J-330X MG RESISTOR 33 R582 NRSA3J-0R0X MG RESISTOR 0 R506 NRSA63J-330X MG RESISTOR 33 R583 NRVA63D-471X CMF RESISTOR 470 R507 NRSA63J-330X MG RESISTOR 33 R584 NRVA63D-103X METAL FILM RESISTOR 10K R508 NRSA63J-330X MG RESISTOR 33...
  • Page 46: Block No. M2Mm

    DVD Mechanism Unit and Parts List Block No. M2MM FLM-V3 FOR MODULE BOARD MECHA LOADING BOARD REF. PARTS NO. PARTS NAME REMARKS SUFFIX Chassis GMVMD3270 Tray GMVMD3265 Pulley gear GMVDG1308 Drive gear 1 GMVDG1309 Drive gear 2 GMVDG1310 UP DOWN cam GMVDK0156 Belt GMVDV0373...
  • Page 47 DVD Mechanism Unit and Parts List Block No. M2MM FML-V3 FOR STEPPING MOTOR FOR MODULE BOARD FOR SPINDEL MOTOR REF. PARTS NO. PARTS NAM E REMARKS SUFFIX Spindle FFC GMVWJ1277 Spindle motor unit GMVEM0665 Stepping motor unit GMVEM0666 Tilt spring 1 GMVMB3278 Tilt spring 2 GMVMC1487...
